Technical information

41
team
server
G700
i
The
team
server G700
i
is a flexible family of servers designed for use by small to medium-sized departmental
workgroups. With Intel’s Pentium II inside, the
team
server G700
i
server systems are targeted to high-end file & print
LAN servers and low-end database server market in terms of their power and functionality. All
team
server G700
i
server systems are upgradeable from single to dual processor operation.
Available as two models based on 300MHz and 333MHz Pentium II technology. Both models can be
upgraded from single to dual processor operation. The 300MHz and 333MHz come with 512KB ECC
Cache.
PCI and ISA bus technology for optimum performance, with Ultra-Wide SCSI Backplane, dual on-board
Ultra-Wide SCSI and PCI-Ethernet as standard.
Contains 64MB DIMM and 4GB 7200rpm Ultra-Wide Disk Drive.
Highly upgradeable and expandable - up to 512 MB ECC EDO RAM, 72 GB disk space in the System
Cabinet and an additional 72GB with the G-type Expansion Cabinet.
Upgradeable to Dual Redundant Power Supply.
Processor
team
server G780
i: Pentium II 300 MHz with 512KB ECC integral L2 cache
team
server G790
i: Pentium II 333 MHz with 512KB ECC integral L2 cache
Intel 440FX Chipset
Memory
512MB ECC EDO Maximum from 4 DIMM slots
Memory as standard
64 MB DIMM (leaving 3 DIMM slots free)
I/O buses
•
5 x dedicated PCI slots
•
2 x dedicated ISA slots
I/O subsystems as
standard
•
Dual Channel on-board Ultra-Wide SCSI Adaptec 7880
•
10/100 Mbit PCI Ethernet on board with RJ45 connector Intel PRO 100B compatible
Storage bays
•
Up to 8 hot-swap disks on Ultra-Wide SCSI Backplane
•
3 x 5.25 inch format, half height externally accessible device bays (one occupied by a
CD-ROM drive in standard configuration) plus a 3.5” diskette drive
Storage in standard
configuration
•
1 x 4GB 1” 68 pin 7200rpm Ultra-Wide SCSI fixed disk drive
•
1 x 1.44MB 3.5 inch diskette drive
•
1 x IDE CD-ROM drive
Graphics as standard
On-board 1MB PCI SVGA (ATI 264VT)
Hardware options
All options separately orderable and will be delivered unconfigured:
•
4GB, 9GB 1” and 18GB 1.6” 68 pin 7200rpm Ultra-Wide SCSI fixed disk drives
•
32, 64 and 128MB RAM upgrades (DIMM)
•
10/100 MBit PCI Ethernet cards
•
4-8GB (DDS-2) & 12-24GB (DDS-3) DAT Drives (internal)
•
60-120GB DDS-3 DAT Stackers (internal & external)
•
7-14GB Exabyte Eliant 820 & 20-40GB Exabyte Mammoth Tape Drive (internal)
•
20-40GB DLT4000 Tape Drive (internal & external)
•
4-8GB Tandberg SLR5 QIC (internal), 1.2GB CMT drive (internal & external)
•
Mylex High Performance RAID Controller
•
ISA SIO Asynchronous Adapter
•
FDDI Adapters
•
UK models come complete with mouse, keyboard and power cable.
European and United States mains power leads must be ordered separately
(not included as standard with the base server package)
Operating system
software
•
IntranetWare 4.11
•
Windows NT Server 4.0
•
SCO UnixWare 2.1.2
•
WinFrame 1.7
Security
Disk bay, exchangeable bay and logic bay are all separately lockable
BIOS controls password access and access to disks and exchangeables
Dimensions & Weight
Height, Width (exc. Feet), Depth (580 x 180 x 590mm)
Weight: 24kg
Expansion
team
server G-
type expansion cabinet (maximum of 3)
Standard warranty
Contact Fujitsu Sales in your country for further details of the warranty that is offered
