Technical information

39
team
server C7X1
i
The
team
server C7X1
i
is a dual capable server designed for use by small to medium-sized departmental workgroups,
building on the success of the
team
server C
i
range. With the Pentium II inside, the
team
server C7X1
i
server systems
are targeted to mid-range through high-end file & print market and low-end application server market in terms of their
power and functionality.
The
team
server C7X1
i
server is available based on 266MHz Pentium II (with 512KB Cache). It is upgradeable from
single to dual processor operation, thus enabling the user to meet changing workload requirements.
PCI and ISA bus technology for optimum performance, on-board Ultra-Wide SCSI and on-
board PCI-Ethernet as standard
Contains 32MB DIMM and 4GB 5400rpm Ultra-Wide Disk Drive
Highly upgradeable and expandable - up to 512 MB ECC EDO RAM, 16GB disk space in the
System Cabinet and an additional 72GB with the G-type Expansion Cabinet.
Processor
•
team
server C771
i: Pentium II 266 MHz with 512KB integral L2 cache
Intel 440FX Chipset
Memory
512MB ECC EDO Maximum from 4 DIMM slots
Memory as standard
32 MB DIMM (leaving 3 DIMM slots free)
I/O buses
•
5 x dedicated PCI slots
•
2 x dedicated ISA slots
I/O subsystems as
standard
•
Single Channel on-board Ultra-Wide SCSI Adaptec 7880
•
10/100 Mbit PCI Ethernet on board with RJ45 connector Intel PRO 100B compatible
Storage bays
•
2 x 3. 5 inch format (one occupied by a fixed disk drive in standard configuration)
•
3 x 5.25 inch format (one occupied by a CD-ROM drive in standard configuration) plus a
3.5” diskette drive
Storage in standard
configuration
•
1 x 4GB 1” 68 pin 5400rpm Ultra-Wide SCSI fixed disk drive
•
1 x 1.44MB 3.5 inch diskette drive
•
1 x IDE CD-ROM drive
Graphics as standard
On-board 1MB PCI SVGA (ATI 264VT)
Hardware options
All options separately orderable and will be delivered unconfigured:
•
4GB 1” 68 pin 5400rpm Ultra-Wide SCSI fixed disk drive
•
32, 64 and 128MB RAM upgrades (DIMM)
•
10/100 Mbit PCI Ethernet cards
•
4/16 Mbit Token Ring card
•
4-8GB (DDS-2) & 12-24GB (DDS-3) DAT Drives (internal)
•
60-120GB DDS-3 DAT Stackers (external)
•
7-14GB Exabyte Eliant 820 Tape Drive & 20-40GB Exabyte Mammoth Tape Drive
(internal)
•
20-40GB DLT4000 Tape Drive (external)
•
4-8GB Tandberg SLR5 QIC (internal), 1.2GB CMT drive (external)
•
Mylex PCI RAID Controller
•
ISA SIO Asynchronous Adapter
•
FDDI Adapters
•
UK models come complete with mouse, keyboard and power cable.
European and United States mains power leads must be ordered separately
(not included as standard with the base server package)
Operating system
software
•
IntranetWare 4.11
•
Windows NT Server 4.0
•
SCO UnixWare 2.1.2
•
WinFrame 1.7
Security
Disk bay, exchangeable bay and logic bay are all lockable
BIOS controls password access and access to disks and exchangeables
Dimensions &
Weight
Height, Width (exc. Feet), Depth (440 x 200 x 515mm)
Weight: 12kg
Expansion
team
server G-
type expansion cabinet
Standard warranty
Contact Fujitsu Sales in your country for further details of the warranty that is offered
