Technical information

35
MSCS Mylex Ultra2/LVD Kits What to order
Windows NT Server What to
order
Windows NT Server, Enterprise Edition 4.0
(including 25 Client Access Licences)
SV564085
One copy required per server
The Fujitsu LVD Disk Node can contain up to eight disks.
The rack-mount Disk includes a power supply and two fans. A redundant power supply can be
added without decreasing the number of drive bays. The redundant fan is already provided.
Disk Node Options What to order
LVD Disk Node SV657042
Redundant PSU for Disk node (Each PSU requires a separately orderable mains cable) SV657013
Hot Swap Replacement Fan SV578136
ECC SDRAM What to order
(64MB or 128MB DIMM as standard)
64MB SV578093
128MB SV578094
256MB SV578095
1 or 2 CPU(s) require a minimum of 128MB memory.
team
server G800
i
configurations
What to
order
Rack-mount
team
server G820
i
0MB
,
400MHz/512KB Pentium II CPU, LVD,
no
HDD
, no
RAM
SV661027
Rack-mount
team
server G840
ie
0MB
,
450MHz/512KB Pentium III CPU, LVD,
no
HDD
, no
RAM
SV661027
Rack-mount
team
server G870
i
0MB
,
500MHz/512KB Pentium III CPU, LVD,
no
HDD
, no
RAM
SV578170
team
server G800
i
rack fitting kit –
Consists of rack-mounting brackets,
replacement side panels and front bezel. It
is only needed if an existing tower
G800
i
is
to be converted so it can be fitted in a rack.
SV578140
Two
team
server G800
i
are required.
It is recommended that two identical servers are
configured to run mission critical applications.
System Disk Options What to
order
4 GB 1” 7200rpm SCA Ultra2/LVD SCSI SV642054
9 GB 1” 7200rpm SCA Ultra2/LVD SCSI SV565060
18 GB 1” 7200rpm SCA Ultra2/LVD SCSI SV565061
9 GB 1” 10000rpm SCA Ultra2/LVD SCSI SV565063
18 GB 1” 10000rpm SCA Ultra2/LVD SCSI SV565064
36 GB 1.6” 10000rpm SCA Ultra2/LVD SCSI SV565065
One system disk required per server.
Minimum system disk size > (3 * memory) + 2GB
This is for operating system files & page file.
MSCS Mylex Ultra2/LVD Kit for 800i Range Servers* SV520062
MSCS Mylex Ultra2/LVD Upgrade Kit for 800i Range
Servers#
SV520063
*If it is required to upgrade an existing rack-mount
team
server C800
i
into an MSCS configuration then the MSCS Kit must be ordered (as well
as an additional server).
For information, the above SV520062 MSCS Mylex Ultra2/LVD kit for
team
server
800 comprises:
1 of MSCS SCSI Kit – needed to cable up configuration
1 of MSCS Cluster Installation Instructions
2 of Mylex eXtremeRAID 1100 (DAC1164) Controller – one per server
2 of Intel PRO/100+ Server Adapters – for interconnect LAN
#Allows the addition of an extra Mylex eXtremeRAID controller in each
server to which one or two additional disk nodes may be attached.
Disks for LVD Disk Node What to
order
9 GB 1” 7200rpm SCA Ultra2/LVD SCSI SV565060
18GB 1.6” 7200rpm SCA Ultra2/LVD SCSI SV565056
18GB 1” 7200rpm SCA Ultra2/LVD SCSI SV565061
9GB 1” 10000rpm SCA Ultra2/LVD SCSI SV565063
18GB 1” 10000rpm SCA Ultra2/LVD SCSI SV565064
36GB 1.6” 10000rpm SCA Ultra2/LVD SCSI SV565065
Maximum 8 x 36GB 1.6” disks in disk node.
Do not mix 10,000 and 7200 rpm disks on the same RAID
controller. NB. For RAID 5 configurations it is
recommended that the disks are all of the same capacity
e.g. All 9GB, 18GB or 36GB disks.
Mylex
eXtremeRAID
Controller
Mylex
eXtremeRAID
Controller
Private Interconnect LAN
Public LAN
G800
i
System 1
G800
i
System 2
Disk
Node 1
Disk
Node 2
SCSI
Ch 1
SCSI
Ch 2
MSCS on Rack-mount G800
i
with LVD Disk Node
