Mains Connection: With a UPS
A UPS must be hard-wired into the building’s mains supply. Order the following:
•
UPS – this has 8 power outlets; includes one UPS-to-server signal cable
•
UPS mains distribution kit (unterminated external mains cable, pack of 8 internal mains cables, shutdown module)
•
Share UPS module if more than one server is to be connected to the UPS
•
Signal cable for each server except the first one (because one cable is included with the UPS)
•
If necessary, mains splitter cables so the UPS can power more than 8 pieces of equipment
PRODUCT
REFERENCE
DESCRIPTION HEIGHT
SV537035 SU3000RMi 3kVA UPS (220–240V)
– Worldwide except
North America and Japan; has 8 mains outlets. Includes a
PowerChute Signal Cable
3U
SV642063 UPS Mains Distribution Kit
– Includes an external mains
cable for connecting the supply to the UPS, a kit of 8 internal
cables (2 metres) for connecting equipment to the UPS, and
a Shutdown Module.
1
–
SV616061 Power supply splitter cable, 3-way
– Needed if more than 8
mains devices must be powered from the UPS. One end
connects to an output socket on the UPS or to an internal
mains cable; the other ends can then power up to three
pieces of equipment (from the plug to the furthest socket is
1.5 metres).
–
SV537020 Share UPS Module
– One Share UPS Module is needed per
rack if the UPS will drive more than one server. It allows up to
eight servers to be driven from one UPS.
–
SV537034 PowerChute Signal Cable
– One of these cables is needed
for the second server and one for each subsequent server
that is connected to the Share UPS Module.
–
1
The Shutdown Module is used for shutting off the power output of the UPS in an emergency
Please refer also to
PD-SR-0007
for rack UPS information. At present, full support for a UPS is not available
if UnixWare 7 is used.
The 3kVA rack-mount unit (SV537035) powers the equipment in one rack. It must be mounted at the bottom
of the rack.
If a UPS is required, the following products must be ordered:
•
a UPS which is appropriate for the local mains supply
•
an appropriate UPS Mains Distribution Kit
•
a Share UPS Module and one or more PowerChute Signal Cables, if the UPS is to power more than one
server
The number of Processor and/or Disk Nodes that can be driven by one UPS is influenced by the power
consumption of the components which are installed. The hold-up time must be long enough (eg 10 minutes) to
permit the system to shut down completely if the mains supply fails for a lengthy period of time.
