Technical information

19
PRODUCT
REFERENCE
DESCRIPTION
HEIGHT
SV642115 Rack for M700i, C800i, G800i, L800i and T800i – Includes
front glazed door, rear door, side panels, castors and rack
User Guide.
42U
SV642112 Replacement back door for M700i rack
– Required if a
rack-mounted
M800i server will be accommodated in an
existing
M700i rack (SV642033).
–
Mains connection
– See “Mains Connection: Without a
UPS” or “Mains Connection: With a UPS”
SV642037 General Purpose Shelf
– Used for mounting a 15" or 17"
monitor or can accommodate up to 2 external DAT Stackers,
1 external DLT or 2 external DLT tape drives if they are
mounted on their side. Heights include the shelf.
Monitor: 10U
2 DAT: 4U
1 DLT: 4U
2 DLT: 6U
SV642038 Keyboard Shelf
– The keyboard and mouse are supported
by this sliding shelf.
2U
SV642034 1U Rack Blanking Plates (pack of three)
– Blanking plates
fill areas of unused equipment space within the rack. They
are optional and are not required for thermal management.
1U/2U/3U
SV642035 4U Rack Blanking Plates (pack of three)
– as above
4U/8U/12U
SV642036 Rack Coupling Kit
– Used for bolting two adjoining racks
together. In this configuration, side panels are removed,
allowing cables to be run horizontally between racks.
–
SV642049 Rack User Guide
– This is supplied with each rack but is
available for order separately if required
–
PD58M093 Ergo Pro e155 SVGA Monitor –
Requires a General
Purpose Shelf to mount. See the Rack Hardware section.
10U
PD53K0E3 Ergo Pro e176 SVGA Monitor –
Requires a General
Purpose Shelf to mount. See the Rack Hardware section.
10U
PK040852 Keyboard
– Requires a Keyboard Shelf
2U or 3U
1
PK080133 Mouse
– Requires a Keyboard Shelf
–
SV642045 Rack console switch
– A console switch can switch a
monitor, keyboard and mouse between each of up to 4
servers. By cascading two console switches together, the
console may be switched between a total of 7 servers. If two
switches are cascaded, a Console Switch Cascade cable
(see below) is required.
A second switch can be mounted behind the first switch and
so does not consume any additional rack height.
1U
SV616060 Server-to-Switch Cable Set
– One set of these cables is
needed for each server which is connected to a Rack console
switch
–
SV616074 Switch-to-Switch Cascade Cable
– Needed if two 4-way
console switches are cascaded to allow the console to be
switched between up to seven servers.
–
SV616053 Console Extension Cable kit, 7.5m
– Needed if the monitor,
keyboard and mouse will be mounted outside the rack. This
includes extension cables for monitor, keyboard and mouse.
–
SV616052 Long printer cable (5 metres)
– For connection to a printer
outside the rack.
–
1
With a conventional keyboard, the shelf occupies 2U. An ergonomic keyboard requires 3U.
