Technical information
16
team
server T800
i
team
server
T800
i
is a datacentre server utilising the latest Pentium
III Xeon
processor technology from Intel.
Targeted at the high-end server market for large-scale datacentre applications,
T800
i
offers vast headroom for expansion
with exceptional levels of resilience.
•
High-performance Pentium III Xeon 550MHz processors with 1MB or 2MB L2 cache all at full core speed
•
Upgradeable to 8-way
•
72GB internal disk, up to 5.2TB external disk
•
10 dedicated 64-bit hot-swap PCI slots
•
ECC SDRAM, up to 32GB support
Processor
•
team
server
T880
ie
:
Single Pentium III Xeon 550MHz with 1MB integral L2 cache
•
team
server
T890
ie
:
Single Pentium III Xeon 550MHz with 2MB integral L2 cache
Upgradeable from single to 8-way processing. Intel Profusion Chipset.
The profusion carrier provides connectors for two processor mezzanine boards.
Each mezzanine board provides four Slot 2 connectors.
One processor mezzanine board supplied as standard.
Memory
32GB 100MHz ECC SDRAM maximum (when two memory carrier boards fitted).
Interleaved mode supported when two memory carriers installed. The memory carriers interface
to the profusion carrier through the midplane. One memory carrier supplied as standard.
Disks (internal max)
•
2 x SCA Ultra2/LVD SCSI hot-swap disks in CPU node
Maximum internal storage is 72GB from 2 x 36GB 1.6” disks
With optional Ultra2/LVD Disk Nodes the maximum storage rises to 5.2TB
I/O buses
•
4 x dedicated 66MHz 64-bit hot-swap PCI slots
•
6 x dedicated 33MHz 64-bit hot-swap PCI slots
(1 slot occupied with Intel PRO/100+ Server Adapter)
On-board I/O
subsystems
•
Dual channel PCI Ultra2/LVD Symbios SYM53C896 SCSI controller integrated on to the
motherboard. One channel is used internally to provide support for the internal SCSI drives
(connected to the LVDS hot-swap disk backplane) and CD-ROM or tape drive. The second
LVDS channel is routed to the rear of the chassis to support external devices.
•
I
2
O-ready architecture
Storage bays
•
1 x 5.25 inch format occupied with a CD-ROM drive
•
1 x 3.5 inch format occupied with a 3.5 inch diskette drive
Storage in standard
configuration
•
1 x 1.44MB 3.5 inch diskette drive
•
1 x IDE CD-ROM drive
Server Management
Suite of products focused on managing server hardware remotely using the standard SNMP
protocol. Integrates with existing network management systems.
Graphics as standard
Integrated SVGA Cirrus Logic CL-GD5446 PCI graphics controller with 2MB Video RAM
Operating system
software
•
Windows NT Server 4.0 Enterprise Edition
•
SCO UnixWare 7.1 *
* Additional SMP licences may be needed for multi-processor systems.
Memory Upgrades
Two dual plug-in carriers containing interleaved pathway to main memory supporting PC100
registered SDRAM. Each memory carrier supports from 128 MB to 16 GB of error correction
code (ECC) memory using sixteen 72-bit dual inline memory modules (DIMMs).
•
128, 256, 512 and 1024MB ECC SDRAM upgrades
Storage Devices
•
9GB 1”, 18GB 1” and 36GB 1.6” SCA 10,000rpm Ultra2/LVD SCSI hot-swap disk drives
•
60-120GB DDS-3 4mm external DAT Stacker
•
35-70GB DLT7000 external tape drive
•
280-560GB DLT7000 Autoloader external tape drive
Network Controllers
•
Intel PRO/100+ Server Adapter as standard
•
Intel PRO/1000 Gigabit Server Adapter
•
Olicom Token-Ring PCI 16/4 Adapter (OC-3140)
•
SXPCI Asynchronous Host Adapter
•
Specialix High Connectivity RIO RS-232 Asynchronous Adapter
Disk Controllers
•
Adaptec AHA2940U2W Single-Channel Single-Ended PCI SCSI Adapter
•
Adaptec AHA2944UW Single-Channel Differential PCI SCSI Adapter
•
Mylex eXtremeRAID 1100 Ultra2 SCSI PCI RAID Adapter
UPS
•
3kVA UPS from APC (American Power Conversion)
PSU
•
Ability to upgrade configuration with additional PSU to support redundancy.
Dimensions & Weight
Height, Width (exc. Feet), Depth (311 x 445 x 711mm),
Weight: 51.4kg minimum, 60kg maximum load
Standard warranty
Contact Fujitsu Sales in your country for further details of the warranty that is offered.
