Technical information

14
team
server L800
i
The
team
server L800
i
range are enterprise level servers utilising the latest Pentium III Xeon
processor technology
from Intel. Targeted at the consolidated LAN server market for high performance enterprise applications,
L800
i
offers
fast, reliable performance, flexibility and ample headroom for growth.
High-performance Pentium III Xeon 500MHz processors with 512KB or 1MB L2 cache and Pentium III Xeon
550MHz processors with 512KB, 1MB or 2MB L2 cache at full core speed
I
2
O-ready Architecture
Hot-swap disk, max of 252GB in system cabinet
Hot-swap redundant Power Supply Units & Fans
ECC EDO RAM, up to 4GB
Rack-mount capability
Upgradeable to quad processing
Processor
team
server L870
i: Pentium III Xeon 500MHz with 512KB integral L2 cache
team
server L880
i: Pentium III Xeon 500MHz with 1MB integral L2 cache
team
server L870
ie: Pentium III Xeon 550MHz with 512KB integral L2 cache
team
server L880
ie: Pentium III Xeon 550MHz with 1MB integral L2 cache
team
server L890
ie: Pentium III Xeon 550MHz with 2MB integral L2 cache
Upgradeable to dual or quad processing. Intel 450NX Chipset.
Memory
4GB 100MHz ECC EDO RAM maximum from 16 DIMM slots (four way interleaved)
Disks (internal max)
Eight disks maximum:
8 x 4GB or 9GB 1 or 18GB 1 SCA Ultra2/LVD SCSI disks or
6 x 36GB 1.6 and 2 x 9GB or 18GB 1" SCA Ultra2/LVD SCSI disks
Maximum storage is 252GB from 6 x 36GB 1.6 disks and 2 x 18GB 1 disks
I/O buses
5 x dedicated PCI slots
1 x shared PCI/ISA slot (full length PCI or half length ISA)
NB: this is not physically shared, use of one slot prevents use of the other.
1 x half length PCI slot (occupied by Intel PRO/100+ Management Adapter)
On-board I/O
subsystems
Dual channel PCI Ultra2/LVD Symbios SYM53C896 SCSI controller integrated on motherboard
Single channel Symbios SYM53C810AE SCSI controller integrated onto motherboard.
I
2
O-ready architecture
Storage bays
4 x 5¼- inch format half-height exchangeable device bays, two bays occupied with a CD-ROM
drive and a horizontally mounted 3½ inch diskette drive fitted as standard
8 x 3½-inch format hot-swap capable disk bays (6 bays can take disks which are 1 or 1.6
high; the other 2 bays can only take 1 disks)
Storage in standard
configuration
1 x 1.44MB 3.5 inch diskette drive
1 x IDE CD-ROM drive
Server Management
Suite of products focused on managing server hardware remotely using the standard SNMP
protocol. Integrates with existing network management systems.
Graphics as standard
Integrated SVGA Cirrus Logic CL-GD5480 PCI graphics controller with 2MB video RAM
Operating system
software
Windows NT Server 4.0
SCO UnixWare 7 .1 *
IntranetWare 4.11 *, NetWare 5 *
* Additional SMP licences may be needed for multi-processor systems.
Memory Upgrades
128, 256, 512 and 1024MB ECC EDO RAM upgrades
Storage Devices
4GB 1, 9GB 1 and 18GB 1.6 SCA 7200rpm Ultra2/LVD SCSI hot-swap disk drives
9GB 1, 18GB 1 and 36GB 1.6 SCA 10,000rpm Ultra2/LVD SCSI hot-swap disk drives
4-8GB DDS-2 and 12-24GB DDS-3 4mm internal DAT drives
20-40GB DLT4000 internal and external tape drives
35-70GB DLT7000 external tape drive, 4-8GB SLR5 QIC internal tape drive
60-120GB DDS-3 4mm external DAT Stacker, 280-560GB DLT7000 Autoloader
Network Controllers
Intel PRO/100+ Management Adapter as standard
Intel EtherExpress PRO/10+ PCI and PRO/1000 Gigabit Ethernet adapters
Intel PRO/100+ Server Adapter
Olicom Token-Ring PCI 16/4 Adapter (OC-3140)
P92 PCI Adapter: dual port WAN Adapter
FDDI PCI Adapter: Dual-Attach Station (DAS) (SK5544)
SXPCI Async Host Adapter
Specialix High Connectivity RIO RS-232 Asynchronous Adapter
Intel Server Management Module
Disk Controllers
Adaptec AHA2940UW Single-Channel Single-Ended PCI SCSI Adapter
Adaptec AHA2944UW Single-Channel Differential PCI SCSI Adapter
eXtremeRAID 1100 Ultra2 SCSI PCI RAID Adapters
UPS
1.4kVA and 2.2kVA UPS from APC (American Power Conversion)
PSU
Two PSUs supplied as standard, an additional PSU is required for hot-swap redundancy
Dimensions & Weight
Height, Width (exc. Feet), Depth (474 x 307 x 700mm), Weight: 55kg (max)
Standard warranty
Contact Fujitsu Sales in your country for further details of the warranty that is offered.
