QuickSpecs

Storage Controller 4HDD Models HP Smart Array B110i SATA RAID
NOTE: To enable RAID on Embedded SATA, use the HP Smart Array
B110i SATA RAID Controller, To enable use of the B110i, enter the ROM
based setup utility(RBSU). The option for enabling RAID can be found in
the Advanced section of the RBSU.
NOTE: Embedded SATA controller support transfer rate up to 3Gb/s
NOTE: A diskette drive or virtual FDD using LO100 Advanced Pack is
needed to install storage controller drivers during a Windows operating
system installation from a CD.
8HDD Models HP Smart Array P410/256MB Controller (RAID 0/1/1+0/5/5+0)
NOTE: Support transfer rate up to 6Gb/s SAS or 3Gb/s SATA
12HDD Models HP Smart Array P212/256MB Controller (RAID 0/1/1+0/5/5+0)
NOTE: Available upgrades: P410 with FBWC, 256MB with BBWC, 512MB
with FBWC, Battery kit upgrade (for the 256MB cache), and Smart Array
Advanced Pack (SAAP).
NOTE: Support transfer rate up to 3Gb/s SAS or 3Gb/s SATA
25HDD Models HP Smart Array P410/256MB Controller (RAID 0/1/1+0/5/5+0)
NOTE: Available upgrades: P410, 512MB with FBWC, Battery kit upgrade
(for the 256MB cache), and Smart Array Advanced Pack (SAAP).
NOTE: Support transfer rate up to 6Gb/s SAS or 3Gb/s SATA
NOTE: A minimum of 256 MB cache, battery kit, and Smart Array Advanced Pack License Key
upgrade (P/N: 516471-B21) is required to enable RAID 6, 6+0
NOTE: To achieve highest possible stated transfer rate please make sure the firmware on the drive
bays (backplanes) and HP Smart Array controller up to date. Latest firmware are available to download
from HP support web site.
NOTE: All Hard drive bay options except 4LFF require HP Smart Array P410 or P212 controller.
NOTE: Full Height/ Full Length Riser Option is not available when the Rear 2LFF drive bays is
selected for the system.
Internal Storage Devices Diskette Drives Via USB only
Optical Drives Optional HP Slim SATA DVD-ROM Optical Drive
Optional HP Slim SATA DVD RW Optical Drive
NOTE: Support in 4, 8, and 12 drive models. Optical drives can only be
installed in 12 drive model and 25SFF drive bay system with rear option kit
(P/N 515826-B21).
Drive Bays Up to 14 Hot Plug SAS/SATA 3.5" drives
Up to 25 Hot Plug SAS/SATA 2.5" drives
NOTE: 4 Drive Models are Non-Hot Pluggable. Smart Array Controller must
be added for Hot Plug drive capability. 4 Drive Models can be upgraded
with the addition of a Smart Array Controller and a SAS/SATA Multi-lane
cable (496013-B21).
NOTE: The addition of a Smart Array Controller requires the addition of a
SAS/SATA Multi-lane cable (P/N 496013-B21).
Maximum Internal
Storage
Hot Plug 3.5" SATA 28.0TB (14 x 2TB)
Hot Plug 3.5" SAS 28.0TB (14 x 2TB)
Hot Plug 2.5" SATA 12.5TB (25 x 500GB)
Hot Plug 2.5" SAS 15.0TB (25 x 600GB)
QuickSpecs
HP ProLiant DL180 Generation 6
Standard Features
DA - 13248 Worldwide QuickSpecs — Version 31 — 3-4-2011 Page 5
