QuickSpecs

DIMM Type -> Registered DIMMS (RDIMMs)
Unbuffered with ECC DIMMs
(UDIMMs)
DIMM Rank ->
Single
Rank (1R) Dual Rank (2R) Quad Rank (4R)
Single
Rank (1R) Dual Rank (2R)
DIMM Capacity -> 4GB 2GB 4GB 8GB 16GB 4GB 16GB 1GB 2GB 4GB
DIMM Native Speed
(MHz) ->
1333 1333 1333 1333 1333 1066 1066 1333 1333 1333
Voltage LV/Std Std Std LV/Std LV/Std Std Std Std Std Std
SLOTS THAT CAN BE POPULATED
12 slot servers 12 12 12 12 12 12 12 12 12 12
MAXIMUM CAPACITY (GB)
12 slot servers 48 24 48 96 192 48 192 12 24 48
POPULATED DIMM SPEED (MHz)
1 DIMM Per Channel 1333 1333 1333 1333 1333 1066 1066 1333 1333 1333
2 DIMM Per Channel 1333 * 1333 * 1333 * 1333 * 1066/
1033 **
800 800 1066 1066 1066
* Supported with BIOS update via ROM Based Setup Utility (RBSU). UDIMM support is on 12-slot server.
**2DPC: LV runs at 1066, Std voltage runs at 1333
NOTES:
PC3-10600 DIMMs have a maximum speed of 1333MHz. PC3-8500 DIMMs have a maximum speed of 1066MHz
Mixing DIMM speeds is allowed, but the system processor speed rules always override the DIMM capabilities.
If you do mix DIMM speeds, the memory bus will default to the minimum clock rate of all DIMMs in the system - even if the
slower DIMM is on the other processor.
If you install 1x 1066MHz DIMM in channel 1 and 1x 1333MHz DIMM in channel 2, the maximum speed will be 1066MHz.
If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the other
channels, the maximum speed will be 1066MHz.
If you install 3DPC in one channel (if applicable) and 1DPC in all other channels, you run at 800MHz.
Maximum memory speed will also depend on the processor installed.
References to the above MHz speeds are for the various speeds of DDR3 DIMMs; 1333 refers to DDR3-1333, etc.
DIMM slot and configuration diagrams
Basic memory slot & population diagram
Population order; start with "A" first, "B" second, "C" third, etc.
12 DIMM SLOTS (6 per CPU node)
CPU1 CPU2
slot # population order slot # population order
Chnl 1 1 D 1 D Chnl 1
2 A 2 A
Chnl 2 3 E 3 E Chnl 2
4 B 4 B
Chnl 3 5 F 5 F Chnl 3
6 C 6 C
QuickSpecs
HP ProLiant DL180 Generation 6
Memory
DA - 13248 Worldwide QuickSpecs — Version 31 — 3-4-2011 Page 42
