QuickSpecs

HP Rack Series HP Rack 10000 G2 Series (Carbon/Graphite Metallic)
HP 10642 G2 1200mm deep Shock Rack AF092A
HP 10647 G2 1200mm deep Shock Rack AF094A
HP 10642 G2 Pallet Universal Rack AF001A
HP 10642 G2 Shock Universal Rack AF002A
NOTE: It is mandatory to use a shock pallet when shipping racks with equipment
installed.
NOTE: Please see the Rack 10000 G2 QuickSpecs for Technical Specifications
such as height, width, depth, weight, and color:
http://h18000.www1.hp.com/products/quickspecs/12402_div/12402_div.html
(Worldwide)
NOTE: For additional information regarding Rack Cabinets, please see the
following URL: http://www.hp.com/go/rackandpower .
NOTE: The increasing power of new high-performance processor technology
requires increased cooling efficiency for rack-mounted servers. The 10000 G2
Series Racks provide enhanced airflow for maximum cooling, allowing these
racks to be fully loaded with servers using the latest processors.
CAUTION: If a third-party rack is used, observe the following additional
requirements to ensure adequate airflow and to prevent damage to the
equipment:
Front and rear doors: If your 42U server rack includes closing front and
rear doors, you must allow 830 square inches (5,350 sq cm) of hole evenly
distributed from top to bottom to permit adequate airflow (equivalent to the
required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side
panels of the rack must be a minimum of 2.75 inches (7 cm).
CAUTION: Always use blanking panels to fill all remaining empty front panel U-
spaces in the rack. This arrangement ensures proper airflow. Using a rack
without blanking panels results in improper cooling that can lead to thermal
damage.
NOTE: HP ProLiant DL rack models have fixed rails which provide support for
racks with round mounting holes and tool-free support for racks with square
mounting holes (including Compaq/HP 7000, 9000, 10000 and HP series), with
an adjustment range of 26" - 36".
NOTE: Support for all 2 and 4 post Telco racks and threaded hole racks requires
an additional option kit from Rack Solutions. The Rack Solutions brackets can be
purchased at: www.hp.com/go/rackandpower .
QuickSpecs
HP ProLiant DL180 Generation 6
Additional Options
DA - 13248 Worldwide QuickSpecs — Version 31 — 3-4-2011 Page 39
