QuickSpecs

HP Power Distribution
Units
Monitored PDUs
HP Monitored Power Distribution Unit: Full Rack Version
HP 8.6 kVA S1324 Monitored PDU- single input, 3Ø, 24A (NA/JPN) AF504A
HP 16.6 kVA S2140 Monitored PDU- dual input, 1Ø, 40A (NA/JPN) AF505A
HP 8.3 S1140 Monitored PDU- single input, 1Ø, 40A (NA/JPN) AF506A
HP 11 kVA S1316 Monitored PDU- single input, 3Ø, 16A (INTL) AF508A
HP 7.3 kVA S1132 Monitored PDU- single input, 1Ø, 32A (INTL) AF510A
HP Monitored Power Distribution Unit: Half Rack Version
HP 4.9 kVA S124 Monitored PDU- single input, 1Ø, 24A (NA/JPN) AF914A
HP 7.3 kVA S132 Monitored PDU- single input, 1Ø, 32A (INTL) AF915A
Modular PDUs 1U/0U (Up to 28 outlets)
4.9 kVA Modular PDU, 24A, NA/JPN 252663-D72
8.3 kVA Modular PDU, 40A, NA/JPN 252663-D73
3.6 kVA Modular PDU, 16A, INTL 252663-B24
7.3 kVA Modular PDU, 32A, INTL 252663-B31
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/12118_div/12118_div.html
(Worldwide)
HP Intelligent Power Distribution Units (iPDU)
4.9kVA iPDU Core, 24A Single phase L6-30 input NA/JPN AF520A
8.6kVA iPDU Core, 24A Three phase L15-30 input, NA/JPN AF522A
7.3kVA iPDU Core, 32A Single Phase IEC332P6 input, INTL AF525A
11kVA iPDU Core, 16A Three phase IEC516P6 input, INTL AF526A
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/12118_div/12118_div.html
(Worldwide)
NOTE: Please see the UPS and PDU cable matrix's on the HP Power Protection
and Management page. Under Power Cords, click on the "HP Power Cord
Matrix" link. That link will list cable descriptions, requirements, and specifications
for UPS and PDU units. Please see the following link:
www.hp.com/products/powercords .
QuickSpecs
HP ProLiant DL180 Generation 6
Additional Options
DA - 13248 Worldwide QuickSpecs — Version 31 — 3-4-2011 Page 38
