QuickSpecs

NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed
memory configuration rules and guidelines, please use the Online DDR3 Memory
Configuration Tool: www.hp.com/go/ddr3memory-configurator
NOTE: Kits described as LP include Low Power DIMMs. For more information on
ProLiant Energy Efficient Features, see:
http://h18004.www1.hp.com/products/servers/platforms/energyefficient/
HP Optical Drives HP Slim SATA DVD-ROM Optical Drive 481041-B21
HP Slim SATA DVDRW Optical Drive 481043-B21
NOTE: Optical drives can be installed in front, on 4 & 8 bay hard drive models.
NOTE: Optical drives can be installed in 12 and 25 drive model with the addition of
rear option kit (P/N 515826-B21).
HP Hard Drives NOTE: The components of a storage subsystem (e.g. the drive, the HBA/controller,
and the server backplane) should operate at the same data transfer rate or the
system bandwidth will be negotiated down to an acceptable level for all components.
NOTE: Hard drives have either a one year or three year warranty; refer to the
specific hard drive QuickSpecs for details.
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
581286-B21
HP 450GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
581284-B21
HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
507127-B21
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
512547-B21
HP 146GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
507125-B21
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
512545-B21
SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
NOTE: 3G Hard Drives will operate at up to 3.0 Gb/s in 4 drive models that use the
embedded controller.
HP 600GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
516828-B21
HP 450GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
516816-B21
HP 300GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
516814-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information:
http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html
(Worldwide)
NOTE: If selecting more than 4 hard drives or if using SAS hard drives, a Smart
Array controller and two SAS/SATA cables (P/N 464830-B21) are required.
SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives
HP 500GB 6G SAS 7.2K rpm SFF (2.5-inch) Dual Port Midline 1yr Warranty Hard
Drive
507610-B21
QuickSpecs
HP ProLiant DL180 Generation 6
Core Options
DA - 13248 Worldwide QuickSpecs — Version 31 — 3-4-2011 Page 28
