COMPALCOMM Pen g u i n Li t e CAP8 User Guide
Contents Your Phone ................................ 3 Home Screen ........................... 12 Text Entry ................................ 17 Calls ......................................... 23 Contacts ................................... 26 Messaging ............................... 31 Email ........................................ 36 Gmail ........................................ 41 Google Talk .............................. 44 Photos & Videos ...................... 46 Music .............................
Your Phone Phone Overview 1. Earpiece Listen to the phone conversation from here. 2. Camera Use for video calls. 3. LED indicator See “LED Indicator” on page 7. 4. Touch screen 5. Home key Touch to go to the Home screen. 6. Search key Touch to use Google search. 7. Menu key Touch to open menu options. 8. Back key Touch to go back the previous screen. 9.
1. Power button 1 - Press and hold to turn the device on. - When the device is turned on, press and 3 hold, then select Power off to turn the device off. 4 - Press to turn the screen backlight on or off. 2. Earphone jack (3.5mm) Connect the earphone for a hands-free conversation or to listen to music. 3. Camera 6 See “Photos & Videos” on page 46. 4. Volume buttons - Press up to raise or press down to lower sound volume. 5. Back cover 7 6. Memory card slot Insert a memory card to increase device memory.
Package Contents • • • • Phone USB cable Wall/USB charger Battery Battery Your device comes with a Lithium-ion battery. Battery consumption depends on the signal strength, running applications, and settings used. Note: Use only the supplied battery or batteries recommended by the manufacturer. Before installing the battery, you must remove the back cover first. To remove the back cover 1. Hold the device face down. 5 Your Phone 2. Place your fingernail on the grip then lift the back cover.
3. To replace the back cover. Remove the battery 1. Make sure the device is turned off. 2. Remove the back cover. 3. Place your fingernail on the grip then lift to remove the battery. 2. Plug the Wall/USB charger into a wall outlet. Note: You can also charge your phone by plugging the USB cable into your computer and the mini-USB side into the device. Warning: • • Charge the Battery 1.
LED Indicator The LED indicator on your device shows the battery charging status. LED Indicator Status Red Battery is charging. Green Battery full. SIM Card Your SIM card contains your subscription information, phone number and contacts. Install the SIM Card 1. Remove the back cover. 2. Remove the battery. 3. Insert the SIM card into the slot with the metal contacts facing the front of the device. Remove the SIM Card 1. Remove the back cover. 2. Remove the battery. 3.
2. Insert the microSD™ card into the slot with the metal contacts facing the front of the device. 3. Push the microSD™ card until it snaps into place. Remove the Storage Card 1. Open the memory card slot cover. 2. Push the microSD™ card into the slot to eject card. Note: Do not remove the memory card while downloading or saving files to it. Doing so may damage the card and cause data loss. Turn Device On and Off • • Press and hold the Power button to turn on the device.
To undo airplane mode, repeat the above steps. Note: For safety reasons, some functions do not work in airplane mode. Sleep and Wake Device To set the device to sleep mode, press the Power button. The backlight turns off. To wake the device, press the Power button again. The backlight turns on, and the screen is locked. To manually lock the touch screen, press the Power button to set device to sleep mode and lock the screen. Unlock the Touch Screen 1. Press the Power button to turn the backlight on. 2.
Adjust the Volume Your device has the following system volumes: • Ringer: Sounds when there is an incoming call or when a message is received. Press the volume up / down buttons to increase/ decrease volume. • Media: Sounds when music or video is played. During music or video playback, press the volume up/down buttons to increase/ decrease volume. • In-call volume: The volume level of a phone conversation. During a call, press the volume up/down buttons to increase/decrease volume.
• • Drag: Touch and hold an item then drag to move it on the screen. Swipe or slide: Touch and slide your finger across the screen! quickly. This action can be done vertically such as scrolling through a list or horizontally such as browsing through pictures. Rotate the Screen By default, holding the device 90º clockwise or counter-clockwise automatically rotates the screen. To disable this feature, disable the Autorotate screen settings. Access it: Menu > Settings > Display > Auto-rotate screen.
Home Screen View notifications and access widgets, shortcuts and all other applications from the Home screen. Access it: Home Search Bar Use to search information on your device or the Internet. See “Search” on page 16. Widgets Tap a widget to open application. See“Widgets” on page 15. Shortcuts Touch an icon to access the application. See “Shortcuts” on page 15. Phone Icon Touch to open Phone. See “Phone” on page 23. Status Bar Displays the time, battery and signal status, and notification icons.
Move Items • Touch and drag an item to its new location. • Remove Items Touch and drag an item to the Trash icon . Screen Panels The home screen has five screen panels. Slide your finger left or right to view the next or previous screen panel. To clear the notifications, touch Clear. To close the notifications panel, touch Back or touch and drag the bottom of the notifications panel upward. Status Bar Icons The following icons may appear on your device. Icon Indication Alarm is set.
Icon Indication Icon Indication 3G is connected. Wi-Fi in range. Android Manager available. Wi-Fi signal level indicator. New email notification. Roaming in home network. New message notification. Bluetooth is enabled. Missed call notification. Bluetooth connection is active. Synchronization is active. Synchronization error. Voicemail notification. Battery is full. Battery is empty. Battery is charging. Network signal level. USB is connected. Headset is connected.
Icon Indication Download in progress. Upload in progress. Error notification. Shortcuts You can add more application shortcuts to the home screen. 1. Touch the Launcher icon . 2. Touch and hold an application icon until the device vibrates. Or, do the following to add shortcuts: Access it: Menu > Add > Shortcuts > an application. Widgets You can add a widget, such as a music or news and weather widget. 15 Home Screen To open a widget, touch it. To add widgets, touch Menu Add > Widgets.
Multiple Applications Your device allows you to open multiple applications at the same time. When an application is already open, do the following to open another application: 1. Touch Home . 2. Touch the Launcher icon . 3. Touch an application to open. Switch applications When multiple applications are opened, do the following to switch applications: 1. Touch and hold Home to view the Recent applications screen. 2. Touch an icon to return to that application.
2. Touch . 3. Say the information to search. Android Keyboard The Android Keyboard looks similar to a standard keyboard. Text Entry Alphabet Keyboard On-Screen Keyboard Use the on-screen keyboard to enter text, numbers and symbols. To activate the keyboard, touch a text field. To close the keyboard, touch Back . Numeric and Symbols Keyboard Change Input Method 1. Touch and hold a text field. 2. Touch Input method. 3. Touch either Penpower Input Method, XT9 Text Input, and Android Keyboard.
• • • • • • • • • • To toggle upper case, lower case, and all caps text entry, touch , , or . To delete a character, touch . To delete an entire word, touch and hold . To go to the next field, touch . To switch keyboard language, touch the spacebar. To enter text by speaking the word, touch . To insert a smiley, touch . To switch to numeric keyboard, touch . To switch to symbols keyboard, touch . To switch to alphabet keyboard, touch .
punctuation is added, check Auto-complete. XT9 Keyboard The XT9 keyboard has three keyboard layout: Standard keyboard, Reduced keyboard, and Phone keypad. Touch and hold or , then touch XT9 Text Input settings > Keyboard layouts, then select desired keyboard layout. Standard Keyboard Touch the keys to enter text just like a standard keyboard. 19 Text Entry Reduced Keyboard and Phone Keypad Reduced keyboard and Phone keypad has two modes: XT9 and ABC.
• Phone Keypad • • • • • • • To toggle upper case, lower case, and all caps text entry, touch , , or . To delete a character, touch . To delete an entire word, touch and hold . To switch to numeric keyboard, touch . To switch to symbols keyboard, touch . To switch to alphabet keyboard, touch . To switch keyboard language, touch . To change the keyboard language, touch and hold then select the language.
• • • • • • • • To enter letters, write the letter on the Abc area. To enter numbers or symbols, write the number in the 12# area. To hide the Penpower input method screen, touch . To add space, touch . To toggle Android keyboard and Penpower Input, touch . To toggle numeric and symbols keyboard and Penpower Input, touch . To delete an entry, touch . To go to the next line (email), touch .
Edit Text menu, then select either Cut or Copy. Select, Cut, or Copy To select, cut, or copy an entire text field entry, touch and hold the text box to open the Edit text pop-up menu, then touch either Select All, Cut All, or Copy All. To select the current word only or a portion of text, do the following: 1. Touch the area to place the cursor. 2. Touch and hold the text box to open the pop-up menu. 3. Touch Select text. 4. Swipe your finger across the text that you want to select. 5.
Calls Phone Use Phone to make calls. Access it: or > Phone Phone Touch to display the dialpad. Call Log Touch to open Call log. See “Recent Calls” on page 25. Call Enter a phone number then touch this to dial the number. 23 Calls Contacts Touch to open Contacts. See “Call Contacts” on page 25. Favorites Touch to open Favorites. See “Call Favorite Contacts” on page 25.
Make and Answer Calls Make a Call 1. Enter a phone number. 2. Touch . Answer a Call To answer a call, drag to the right. • Reject a Call To reject a call, drag to the left. • End a Call To end a call, touch Menu call. > End In-Call Options During a call, touch Menu access the call menu. • • • to To enter numbers during a call, touch Show dialpad. When the call menu is hidden, drag the Dialpad tab upwards. To place a call on hold, touch Hold. To mute the call, touch Mute.
Recent Calls Access it: • • • • > Phone > Call log To call an entry, touch the corresponding icon. To send a message, add to contacts, and view call details, touch the entry. To remove from call log and other options, touch and hold an entry, then touch an option. To clear the call log, touch Menu > Clear call log. Call Contacts Access it: > Phone > Contacts. Touch and hold a contact, then touch Call contact.
Contacts Access it: > Contacts Create Contacts Access it: > Contacts > Menu > New contact Add field button Remove field button • • To scroll through the list, slide your finger up or down the screen or drag the scroll bar. To search for a contact, touch Search , then type the name. • • • Enter contact information. To add a field for entry, touch Add field button. To remove a field, touch Remove field button. To change the field label, touch the Field label button.
• • Scroll up and down to view more contact details. To save the contact, touch Done. Edit Contacts Access it: > Contacts Touch and hold a contact, then touch Edit contact. Delete Contacts Access it: > Contacts Touch and hold a contact, then touch Delete contact. View Contact Access it: Call Contacts Access it: > Contacts Touch and hold a contact, then touch Call contact. > Contacts Touch a contact to view.
Email Contacts Access it: 1. 2. 3. 4. > Contacts Touch a contact. Touch . Select an email account. Complete your email then send. See “Email” on page 36 for more information. Assign Contact Ringtone Access it: > Contacts 1. Touch a contact. 2. Touch Menu > Options > Ringtone. 3. Touch a ringtone. 4. Touch OK. Divert Call to Voicemail Add Contact to Favorites Access it: > Contacts 1. Touch a contact. 2. Touch to add contact to favorites.
Send Contact Information Your device allows you to send contact information via Bluetooth or email. Access it: > Contacts 1. Touch a contact. 2. Touch Menu > Share. 3. Touch a sharing application to send contact detail. Merge Contact Information Access it: 1. 2. 3. 4. > Contacts Touch and hold a contact. Touch Edit contact. Touch Menu > Join. Touch a contact to join.
To enable the function, click the following boxes: • Background data: Allows applications to sync, send, and receive data at any time. • Auto-sync: Allows applications to sync data automatically. Add Account to Sync • • • To display only contacts with phone numbers, touch Only contacts with phones. To change sorting list, touch Sort list by. To change how you want to view contact names, touch View contact names as. 1. Touch Add account. 2. Touch an application to sync your contacts with. 3.
Messaging Your device can send and receive text and multimedia messages. The Messaging screen groups and displays messages exchanged between you and another person together as a message thread. Access it: > Messaging • • • • To create a new message, touch Menu > Compose. See “Create New Messages” below. To delete all messages, touch Menu > Delete threads. To search a word from in your messages, touch Menu > Search. To change message settings, touch Menu > Settings. See “Message Settings” on page 35.
3. Enter your message. See “Text Entry” on page 17 on using the keyboard. 4. Touch Send to send your message. Add Subject and Smileys To add a message subject, touch Menu > Add subject. Your message is automatically converted to a multimedia message. To insert smileys, touch Menu > Insert smiley, then touch a smiley. Attach Files You can attach media files from your device or the memory card or record picture, video, or audio to attach to your message.
action takes you back to the Messaging screen and saves your current message as draft. Read and Reply to Messages Access it: > Messaging 1. Touch the message to open. 2. On the Type to compose field, enter your message. 3. Touch Send. Forward Messages Access it: > Messaging 1. 2. 3. 4. Touch the message to open. Touch and hold a message. Touch Forward. Enter the recipient and complete your message. 5. Touch Menu > Send. 33 Messaging Copy and Paste Message Text Access it: 1. 2. 3. 4.
4. Touch Delete to confirm. Delete a Message Thread Access it: > Messaging 1. Touch and hold a message thread. 2. Touch Delete thread. 3. Touch Delete to delete the message thread. • • • • • Delete All Message Threads Access it: > Messaging • 1. Touch Menu > Delete threads. 2. Touch Delete to delete all messages. • Message Options Access it: message > Messaging > a • To call the sender, touch Menu > Call. To reply with a message subject, touch Menu > Add subject.
• then touch Lock message or Unlock message. To view the message details, touch and hold a message, then touch View message details. Note: Depending on the type of message, some options may not be available. Message Settings Access it: > Messaging > Menu > Settings. • • • 35 To automatically delete old messages when the limit is reached, check Delete old messages. To set the limit of a text message, touch Text message limit. To set the limit of a multimedia message, touch Multimedia message limit.
• To set vibrate mode when a message is received, touch Vibrate. Email You can send and receive emails from corporate Exchange server accounts, POP/IMAP accounts, or Internet based email accounts. Access it: > Email Set Up Email Accounts Access it: > Email When setting up an email account for the first time, the setup wizard is automatically displayed. 1. Enter your Email address and Password, then touch Next. 2. Read the notice, touch OK. 3.
Note: To set up more accounts, touch Menu > Accounts > Menu > Add account. View Email Accounts Access it: > Email When you open Email, the last screen you have viewed is displayed. To view other accounts on the Email screen, touch Menu > Accounts. The Combined Inbox contains received emails from all your email accounts. The Starred and Drafts folders are displayed only if there are emails saved in the folders. To view the inbox of an account, touch the email account.
Compose and Send Emails Access it: Other Options • > Email The default account is used to compose emails. To use other accounts, select the account first. 1. Touch Menu > Compose. 2. Enter your recipient and type the subject and your email. TIP: To send to multiple recipients, separate the email address with a comma. 3. Touch Send to send email. • To save email as draft, touch Menu > Save as draft. Emails are saved in the Drafts folder. To cancel email, touch Menu > Discard.
Unread messages are highlighted in gray. To load more messages, touch Load more messages or touch Menu > Refresh. To open an email, touch the email. Forward Emails View Attached Files Access it: 1. Open the email and scroll through the end of the email to see the file. 1. Touch an email to open. 2. Touch Menu > Forward. 3. Enter the recipient and complete your email. 4. Touch Send. 2. Touch Open. Delete Emails Reply to Emails Access it: > Email > an account 1. Touch an email to open. 2.
Mark Emails as Read or Unread Access it: > Email > an account 1. Touch and hold an email. 2. Touch Mark as read or Mark as unread. Add Star to Emails Access it: > Email > an account You can group important or favorite emails by adding a star to it. When a star is added, the email is saved in the Starred folder. You can access that email via its account Inbox or the Starred folder. To add a star, touch of an email.
• • • • 41 To set the ringtone when an email is received, touch Select ringtone. To set vibrate mode when an email is received, touch Vibrate. To change the incoming server settings, touch Incoming settings. To change the outgoing server settings, touch Outgoing settings. Gmail Gmail Gmail comes preinstalled on your device. You can synchronize your Google account on the web with your device.
Sign In to Gmail Access it: > Gmail 1. When setting up the account on your device for the first time, touch Next. 2. Touch Sign in. 3. Enter your Username and Password. 4. Touch Sign in and follow the wizard to complete setup. Refresh Gmail Access it: Refresh. > Gmail > Menu Create and Send Emails Access it: > Gmail 1. Touch Menu > Compose. 2. Enter the recipient. TIP: To send to multiple recipients, separate the email address with a comma. 3. Type the subject and your email.
• To cancel email, touch Menu Discard. > Reply to Emails Access it: > Gmail Delete Emails Access it: > Gmail 1. Touch and hold an email. 2. Touch Delete. 1. Touch an email to open. 2. Touch Reply to reply to the sender or Reply all to reply to the sender including all the email recipients. 3. Compose your email. 4. Touch Send. Mark Emails as Read or Unread Forward Emails Gmail Account Settings Access it: > Gmail 1. Touch an email to open. 2. Touch Menu > Forward. 3.
• • • • • • • To change the name that is displayed to your emails, touch Your name. To add a signature to your emails, touch Signature. To set the frequency of checking emails, touch Email check frequency. To set the current account as the default account, check Default account. To display email notification icons on the status bar, check Email notifications. To set the ringtone when an email is received, touch Select ringtone. To set vibrate mode when an email is received, touch Vibrate.
Start a Chat > Talk 1. Touch a friend on the Friends list. 2. Type your message on the text box, then touch Send. > 3. To close the chat, touch Menu End chat. Menu Options • • • • • 45 To add new friends, touch Menu > Add friend. To view your invitations, touch Menu > Invites. To accept or decline an invite, touch Menu > Accept or Cancel. To change your online status, touch the online status icon, then touch desired status. To access Google Talk settings, touch Menu > Settings.
Photos & Videos Zoom images Take Photos Touch the zoom controls or drag the slider to zoom in or zoom out an image. Access it: > Camera Photo Size and Quality Access it: > Camera Select either 4:3 or 3:2 size and photo quality. Note: To send photo via messaging, reduce its size. Zoom controls / slider • • • To take photos, touch . Photos are automatically saved in Gallery. To change to camcorder mode, touch . To view Gallery, touch . 1. Touch Menu > 2. Touch an option. 3. Touch Done. .
2. Touch an option: • Auto: The device automatically adjusts the white balance setting. • Daylight: Ideally used outdoors for sunny conditions. • Cloudy: Ideally used for outdoors for cloudy condition. • Fluorescent: Ideally used indoors with fluorescent lighting. • Incandescent: Ideally used indoors for incandescent lighting. 3. Touch Done. Brightness Setting Access it: > Camera 1. Touch Menu > . 2. Drag the slider to adjust the setting. 47 Photos & Videos 3. Touch Done.
• Reset to default: Touch to reset camera to default settings. Preview Photos Access it: > Camera You can preview a photo right after capturing it if the Review duration setting is not turned off. • • • • • • To share the photo, touch . To set photo as a contact icon or wallpaper, touch . To view the location information of the photo, touch . To enlarge or shrink the photo, touch or . To go back to camera mode, touch . To delete the photo, touch .
Record Videos Access it: > Camcorder Zoom images Touch the zoom controls or drag the slider to zoom in or zoom out an image. Video Size and Quality Access it: > Camera 1. Touch Menu > 2. Touch an option. 3. Touch Done. Zoom controls / slider • • • 49 To start recording videos, touch . To stop recording, touch again. To change to camera mode, touch . To view Gallery, touch . Photos & Videos . White Balance Setting Access it: > Camera 1. Touch Menu > . 2.
• Cloudy: Ideally used for outdoors for cloudy condition. • Fluorescent: Ideally used indoors with fluorescent lighting. • Incandescent: Ideally used indoors for incandescent lighting. 3. Touch Done. 4. Reset to default: To reset the camcorder to default settings. Preview Videos Access it: > Camcorder After recording a video, the video player automatically plays the recording.
• • • To go back to camcorder mode, touch . To delete the video, touch . To share the video, touch . View Photos Access it: Gallery Access it: > Gallery Thumbnail View Touch a folder to view thumbnails. View Switch > Gallery Use Gallery to view photos, and play slideshows and videos saved on your device or the memory card. Video File To open Camera • • • 51 Photos & Videos To toggle thumbnail and folder view, slide the View Switch. To scroll left or right, touch the arrows or slide .
Full Screen View To stop the slideshow, touch the screen. To go back the previous screen, touch Back . Share Photos Access it: > Gallery > a folder 1. Touch and hold a photo. Zoom controls When viewing in full screen mode, swipe your finger to the right or left to view the next or previous photo. To enlarge or shrink the photo, touch the zoom controls. Play Slideshow Access it: a photo > Gallery > a folder > Touch Slideshow to start the slideshow.
photos to check the thumbnails, or touch Select All. 2. Touch Delete. 3. Touch Confirm Delete. Crop Photos Access it: > Gallery > a folder 1. Touch and hold a photo. 2. Touch More > Crop. 3. Touch and hold an edge of the frame to display sizing arrows, then drag the arrows to change the crop size. 4. Touch and drag the frame across the screen to select the portion of the photo that you want to crop. 5. When done, touch Save. Set Photo as Contact Icon or Wallpaper Access it: > Gallery > a folder 1.
Note: To rotate more than one photo at one time, touch the photos to check the thumbnails, or touch Select All. Touch the screen to display the playback controls and the progress bar. 2. Touch More > Rotate Left or Rotate Right. Play Videos Access it: a video file.
Music • Browse Songs Access it: • To randomly play songs, touch Menu > Party shuffle. To shuffle all songs, touch Menu > Shuffle all. > Music Play Songs Access it: playlist > Music > a song or Song details • • • 55 Touch a category to browse songs. To play songs, touch the song or playlist. To play all songs, touch Menu > Play all. Music Progress bar • To view the Now Playing screen, touch .
• • • • • • To toggle shuffle on or off, touch . To scroll among the repeat modes: Repeat all, Repeat current song, and Repeat off, touch . To play/pause, touch / . To go to the previous or the next track, touch / . To rewind or fast-forward, touch and hold / , or drag the progress bar to the left or right. For menu options, touch Menu . Remove Songs From Playlist Access it: a playlist > Music > Playlists > Touch and hold a song, then touch Remove song from playlist.
Delete Playlists Access it: > Music > Playlists Touch and hold a playlist, then touch Delete. 1. Touch and hold a song, then touch Delete. 2. Touch OK to confirm. Search for Song Info Access it: Rename Playlists Access it: > Music > Playlists 1. Touch and hold a playlist, then touch Rename. 2. Enter the new name. 3. Touch Save. Use Song as Ringtone Access it: > Music Touch and hold a song, then touch Use as phone ringtone. Delete Songs Access it: 57 Music > Music > Music 1.
Wireless Connections Add Wi-Fi Networks Wi-Fi Access it: Menu > Settings > Wireless & networks > Wi-Fi settings Use Wi-Fi connections if you are within 100 meters of a wireless access point. Turn Wi-Fi On or Off Access it: Menu > Settings > Wireless & networks > Wi-Fi Tip: To save battery power, turn off Wi-Fi when not in use. Scan for Wi-Fi Networks Access it: Menu > Settings > Wireless & networks > Wi-Fi settings 1. Turn on Wi-Fi. 2. Touch Menu > Scan. 1. Touch Add Wi-Fi network. 2.
Note: When Wi-Fi is turned on and you are in range of Wi-Fi network you have connected to before, your device automatically reconnects to that Wi-Fi network. Bluetooth™ Connection Use Bluetooth if you and another Bluetooth-enabled device are within a 10-meter range. Turn Bluetooth On or Off Access it: Menu > Settings > Wireless & networks > Bluetooth To make your device discoverable to other devices for 120 seconds, check Discoverable.
unsuccessful, check the headset documentation. Reconnect to Devices Access it: Menu > Settings > Wireless & networks > Bluetooth settings Turning off Bluetooth automatically disconnects Bluetooth from a paired device. To manually disconnect, touch and hold a paired device, then touch Unpair. Turning on Bluetooth and making your device discoverable automatically reconnects your device to a paired device. To manually reconnect to a device, touch a device name on the Bluetooth devices list.
USB Connections You can transfer photos, videos, music, and other files from your computer to your device and vice versa. 1. Ensure that the memory card is inserted into the device. 2. Connect the micro USB cable to the USB connector on your device and the other end to the USB port on your computer. 3. When connected, the USB notification icon is displayed on the status bar. 4. Touch Menu > Notifications > USB connected > Turn on USB storage.
Internet Your device can connect to the Internet using a 3G or EDGE connection or a wireless network connection. Note: Check with your network provider for the availability of these services. Additional charges may be incurred when surfing or downloading data from the Internet. To connect to the Internet using a Wi-Fi network, turn on Wi-Fi. See “Turn Wi-Fi On or Off” on page 58.
• • To view the page information, touch Menu > More > Page info. To close Browser, touch Menu > Exit. • • • Using Browser Zoom Page Touch and hold the screen to display the zoom controls on the lower-right corner of the screen. To zoom in or zoom out the page, double-tap on the screen or touch the zoom controls. Work With Links Touch a link to go to that web page. Touch and hold the link to open the pop-up menu, and touch: • Open: To go to that web page.
Find Text on Page Downloads Access it: > Browser > Menu > More > Find on page View the download history and saved pages. Enter the text you want to find. As you type, the match is displayed on screen. Access it: > Browser > Menu > More > Downloads Select Text Access it: > Browser > Menu > More > Select Text Swipe your finger across the text that you want to select. Text is copied to the clipboard. To paste the text, touch and hold a text field, then touch Paste.
• • • • • • • • • 65 Default zoom: Touch to set zoom when the screen is touched twice. Open pages in overview: Check to view the overview of a new page Text encoding: Touch to set text encoding. Block pop-up windows: Check to block pop-ups. Load images: Check to display images on web page. Auto-fit pages: Check to format the web page to fit the screen. Landscape-only display: Check to display pages only in landscape screen orientation. Enable JavaScript: Check to enable Java script.
• • • • • • Clear location access: Touch to clear location access for all websites. Remember passwords: Check to save your usernames and passwords for websites. Clear passwords: Touch to clear all saved passwords. Show security warnings: Check to show warning if there is a problem with a site’s security. Website settings: Touch to set advanced settings for individual websites. Reset to default: Touch to restore browser to default settings.
• • • Touch and hold an area on the map to view the address. Slide your finger on the screen to scroll through the map. Touch the zoom controls to zoom in or zoom out the map. Set Your Location Before you start using Google Maps™, set your location first. Your device can determine your location using GPS satellites or by identifying your mobile network. Do the following to enable this function: 1. From the Home screen, touch Menu > Settings > Location & security. 2.
Get Directions Access it: > Maps 1. Touch Menu > Directions. 2. Type a starting point address or touch , then touch an option: • My current location: To set your current location as the starting point. • Contacts: To select a contact address. • Point on map: To touch a starting point on the map. 3. Type an ending point address or touch , then touch an option: • Contacts: To select a contact address. • Point on map: To touch an ending point on the map. 4.
• Satellite: Touch to view map on aerial photo from Google Earth™. The images are not real-time and are approximately one to three years old. • Terrain: Touch to view the map with 3D imagery and terrain from Google Earth. • Map: This is the default view. This mode is used when Traffic, Satellite, or Terrain are unchecked. You can add layers to view additional information on the map. • Buzz: Touch to view map with comments posted by users about a location.
Latitude • Add via email address, then enter the email address. 3. Touch Add friends. Latitude allows you to view your friends’ location and share your location with them on Google Maps™. Share Your Location Access it: Latitude Join Latitude Access it: > Maps > Menu Join Latitude > Read and accept the privacy policy, then touch Allow & Share. Add Friends Access it: Latitude > Maps > Menu > 1. Touch Menu > Add friends. 2. Touch one of the following: • Select from Contacts, then touch a contact.
Set Your Location Access it: Latitude > Maps > Menu Show Friends on Map > Touch a friend, then touch Show on map. 1. Touch Menu > Privacy. 2. Touch one of the following: • Detect your location: Select to automatically update your location. • Set your location: Select to manually set your location. You can either enter an address, choose address from contacts, or point location on the map. Remove Friends Managing Friends Touch a friend, then touch Send email.
Set Shared Location Use this function to set how you want to share your location to a particular friend. 1. Touch a friend. 2. Touch Sharing options. 3. Touch one of the following options: • Share best available location: To allow this friend to see your detailed location. • Share only city level location: To allow this friend to see your city level location. • Hide from this friend: This friend cannot see your location.
Navigation Android Market™ Google Maps Navigation is an Internet based GPS satellite which allows you to search for destinations by speaking it. Android Market™ allows you to buy and download games and other applications to your device. Access it: > Navigation. Android Manager Agent Android Manager Agent allows you to wirelessly synchronize your device data, such as contacts, messages, photos, videos, music, applications, and calendar, with your computer via Wi-Fi technology.
Download Applications Access it: > Market 1. Touch the application that you want to download. 2. Touch Install. 2. Touch and hold an application, then touch Update to download its updates. Remove Applications Access it: > Market 1. Touch the application that you want to download. 2. Touch Uninstall. 3. Touch OK to confirm. 4. Touch a reason for removing the application, then touch OK. Update Applications Access it: > Market 1. Touch Menu > Downloads.
YouTube™ To see more video categories, touch Menu > Categories. YouTube™ allows you to access and watch instant videos and download or upload videos to YouTube. Search Videos Note: Additional charges may be incurred when using this feature. Check with your network provider. Access it: > YouTube You do not need an account to browse and watch videos. However, you need an account to upload videos. If you do not have a YouTube account, visit http://www.youtube.com.
Share Video Links Access it: > YouTube 1. Touch and hold a video, then touch Share. 2. Touch an application for sharing. Add or Remove Favorite Videos Access it: > YouTube Touch and hold a video, then touch Favorite or Unfavorite. Note: You must sign in to YouTube to use this function. View Videos Details Access it: > YouTube Touch and hold a video, then touch Details. Rate Videos Access it: > YouTube 1. Touch and hold a video, then touch Rate. 2. Touch a number of stars to rate the video.
Sign In or Create Account 3. When done, touch Upload. Access it: > YouTube > Menu !?!My account. Delete Uploaded Videos If you have an existing YouTube account, enter your username and password to sign in. Otherwise, follow the instructions on the screen and create an account. Upload Videos Access it: > YouTube > Menu !?!My account. 1. To upload videos saved in Gallery, touch Menu > Upload, then browse and touch the video you want to upload. To record video to upload, touch . 2. Enter a video title.
Facebook Use Facebook Access it: Facebook is a social networking site that comes preinstalled on your device. Login to Facebook Access it: > Facebook 1. Enter your username and password. 2. Touch Login. Note: If you do not have a Facebook account, touch Sign Up. When using Facebook for the first time, you may be prompted to synchronize your contacts with Facebook, touch desired option, then touch Next. Read the helpful tips, then touch Finish.
Update Your Status Access it: > Facebook > On the What’s on your mind? text box, type your thoughts, then touch Share. Write on Friends’ Wall Access it: > Facebook > Friends 1. Touch a friend to open his/her profile screen. 2. On the Write something... text box, type your thoughts, then touch Share. Manage Photos Access it: > Facebook > Photos 1. Touch an album to view. 2. Touch a photo to enlarge it. 3. Touch the screen to display view control icons.
Upload Photos Access it: > Facebook > Photos 1. Touch an album to upload photos. 2. Touch . 3. Touch one of the following: • Choose from Gallery, then touch a photo. • Capture a photo, then take a photo. 4. Touch Upload. • Facebook Settings Access it: > Facebook > Menu > Settings • • • receive: Messages, Friend requests, Event invites. • Touch Vibrate to set device to vibrate when notifications are received. • Touch Phone LED to flash LED when notifications are received.
Twitter™ synchronize your contacts with Twitter, touch desired option, then touch Done. Twitter™ comes preinstalled on your device Note: Additional charges may be incurred when using this feature. Check with your network provider. Access it: Using Twitter Access it: • > Twitter • Login to Twitter Access it: > Twitter 1. Enter your username or email and password. 2. Touch Sign in. Note: If you do not have a Twitter account, touch Sign up now, then follow the instructions on screen.
Update Tweets Access it: • > Twitter > On the What’s happening? text box, type your thoughts, then touch Update. Twitter Settings Access it: > Settings • • > Twitter > Menu Sync Contacts: Touch to sync Twitter contacts with your device contacts. Sync Twitter data: Check to automatically sync Twitter data. Note: The following settings are available only when Sync Twitter data is checked. • Refresh interval: Touch to set the refresh interval time.
News and Weather News and Weather allows you to view the weather in your location and read the latest stories, sports, and entertainment news headlines on your device. Access it: • • • > News and Weather Swipe your finger to the right or left to browse the categories. Touch a headline to open Browser and view the complete story. To refresh News and Weather, touch Menu > Refresh.
• • Prefetch articles: Check to prefetch articles for faster access. Prefetch images: Check to prefetch images for faster access. • Refresh interval: Select to set the refresh interval time. Note: Prefetching articles or images increases data and battery usage. • • Display images: Check to display images when reading stories. News terms of service: Select to view news terms of service.
Quickoffice Quickoffice allows you to open and view Word files, Excel spreadsheets, Power Point presentations, and PDF files saved in your memory card or downloaded from emails. Access it: • • • • • • > Quickoffice To browse for files in the memory card, touch Browse. To search for files, touch Search. To add remote accounts, touch Accounts. To check for Quickoffice updates, touch UPDATE. To open the support web page, touch SUPPORT. For an overview of Quickoffice, touch EXPLORE.
2. Type the text to search on the Search box, then touch . Other Options • • • • To open another document, touch Menu > Open. To view the document properties, touch Menu > Properties. To check for updates, touch Menu > Updates. To view help, touch Menu > More > Help. Quicksheet Access it: Quicksheet View Worksheets Zoom View Touch the screen twice to display the zoom controls. Touch the zoom control icons to zoom in or zoom out view. Other Worksheet 1. Touch Menu > Worksheet. 2.
Other Options • • • • To open another file, touch Menu > Open. To view the file properties, touch Menu > Properties. To check for updates, touch Menu > More > Updates. To view help, touch Menu > More > Help. Quickpoint Access it: Quickpoint > Quickoffice > Browse and touch the file to view. View Slides Zoom View Touch the screen twice to display the zoom controls. 87 Quickoffice Touch the zoom control icons to zoom in or zoom out view. Go 1. 2. 3. To Slides Touch Menu > Go To Slide.
• • • To view the file properties, touch Menu > Properties. To check for updates, touch Menu > Updates. To view help, touch Menu > More > Help. QuickPDF Access it: QuickPDF > Quickoffice > Browse and touch the file to view. View PDF Zoom View Touch the screen twice to display the zoom controls. Touch the zoom control icons to zoom in or zoom out view. View Page Scroll up or down to view the next or previous page. To go to a specific page, do the following: 1. Touch Menu > Go To Page. 2.
Calendar Use Calendar to view and schedule events and set reminder alerts. Access it: > Calendar Create Events 4. Access it: > Calendar > Menu > More > New event. 5. 1. On any Calendar screen, touch Menu > New event. 2. On the What box, type the event name. 3. Do one of the following to set the date and time. • To set the date and time, touch the From and To date and time boxes. Touch the + or - buttons to adjust the date and time, then touch Set. 89 Calendar 6. 7.
View Events Access it: > Calendar By default, the calendar is displayed in month view mode. To view the calendar by day, touch Menu > Day. To view the calendar by week, touch Menu > Week. To view listed events, touch Menu > Agenda. To go to today’s date, touch Menu > Today. Edit Events Access it: > Calendar 1. Touch a date to view scheduled events. 2. Touch an event. 3. Touch Menu > Edit event. 4. Modify the necessary information. 5. Touch Done. Delete Events Access it: > Calendar 1.
2. Touch the email account icon to scroll through the sync options: • sync, visible • synced, not visible • not synced, not visible. 3. Touch OK. 4. Touch an event. 5. Touch Menu > Edit event. Calendar Settings Access it: > Calendar > Menu > More > Settings The following settings are available: • Hide declined events: Check to hide declined events. • Set alerts & notifications: Touch to set alerts and notifications. • Select ringtone: Touch to set the event notification ringtone.
Clock > Clock Access it: Alarm is set. Touch the icons to open its application. • Touch or off. 2. Touch Add alarm. 3. Touch the + and - icons to set the alarm time. 4. Touch Set. 5. To set repeat mode, touch Repeat. Touch one or more options, then touch OK. 6. To set the ringtone, touch Ringtone, touch an option, then touch OK. 7. To vibrate when alarm sounds, check Vibrate. 8. To enter an alarm label, touch Label. 9. Touch Done. to turn the backlight on Add Alarm > Clock Access it: 1. Touch .
Turn On or Turn Off Alarm Access it: > Clock > 4. Touch Done. Delete Alarm Access it: > Clock > 1. Touch and hold an alarm time. 2. Touch Delete alarm. 3. Touch OK. Alarm icon Alarm is on. Clock Settings Touch to return to Desk Clock screen. Access it: Touch the alarm icon to toggle alarm on or off. Edit Alarm Access it: > Clock 1. Touch and hold an alarm time. 2. Touch Edit alarm. 3. Modify the necessary details. 93 Clock > Clock > Touch Menu > Settings.
FM Radio buttons are pressed during an alarm. Dock Settings You can dock your phone to serve as a desk clock. Note: The dock is an optional accessory, contact your dealer to purchase one. Use only the dock recommended by the manufacturer. Access it: > Clock > Menu Dock settings • • > Audio: Configure audio settings when the phone is docked. Dock insertion sound: Check to play sound when inserting or removing the phone from the dock.
Scan For Stations • • Touch << or >> to scan for the preceding or succeeding radio station. Touch Menu > Scan to automatically scan for stations. Calculator Access it: > Calculator Touch the keys to enter numbers and symbols as you would do on a standard calculator. Add Station to Favorites Basic vs. Advanced Touch + to add the current station to favorites. Touch |< or >| to tune in to the previous or next favorite station. For advanced calculations, touch Menu > Advanced panel.
Sound Recorder Access it: > Sound Recorder To start recording, touch . To stop recording, touch . To play recording, touch . To save recording, touch Use this recording. To discard recording, touch Discard. Speech Recorder Access it: > Speech Recorder Speech Recorder allows you to record voice commands, such as “Call Bill”. When you utter these voice commands the device will execute the command, see “Voice Dialer” on page 97. To record voice commands, do the following: 1. Touch Record. 2.
Voice Dialer Access it: > Voice Dialer 1. Say a command. 2. The application recognizes the command and prompts you for confirmation. Touch an option to confirm. Settings Access it: Menu > Settings Wireless & Networks Airplane mode Check to disable all wireless connections. Wi-Fi See “Wi-Fi” on page 58. Bluetooth See “Bluetooth™ Connection” on page 59. Tethering & Portable Hotspot Touch to share your phone’s mobile data connection via USB or as a portable Wi-Fi hotspot.
• • USB tethering: Check to share data connection via USB. Portable Wi-Fi hotspot: Check to share data connection as a portable Wi-Fi hotspot. • Portable Wi-Fi hotspot setting: Touch to configure Wi-Fi hotspot. • • • • 2G Network selection: Check to activate 2G network to save battery power. Access Point Names: Touch to select an access point. Network operators: Touch to select a network operator. Select radio band: Touch to set the radio band. VPN Settings Touch to setup VPN.
• • Change PIN2: Touch to change the SIM PIN2 code. FDN list: Touch to view the list. SMS Service Center Touch to enter the SMS service center number. Cell Broadcast SMS DTMF Tones • Touch to set the length of DTMF tones. • • Cell Broadcast SMS: Check to enable cell broadcast SMS. Channel list management: Touch to add, remove, or edit channel list. Language: Touch to select cell broadcast language. Voicemail Service Touch to set the voicemail service.
• • • outgoing, Outgoing international, Outgoing international roaming, All incoming, or Incoming when roaming, then enter the password to enable call barring. To disable call barring, touch Deactivate all. To change the password, touch Change password. Caller ID: Touch to display or hide your phone number to the recipient of your call. Call waiting: Check to activate call waiting. Importing SIM contacts: Touch to import one or all contacts from the SIM card to your phone.
Notification Ringtone Touch to set the notification ringtone. Audible Touch Tones Check to enable sound when touching keys on the keypad. Audible Selection Display Brightness Touch to adjust the brightness setting. Auto-rotate Screen Check to enable sound when making screen selections. Check to automatically change screen orientation when the device is rotated. Screen Lock Sounds Animation Check to enable sound when locking and unlocking the screen.
Location & Security Visible Passwords Use Wireless Networks Check to show password as you type. Check to determine the location by Wi-Fi or mobile network. Select Device Administrators Use GPS Satellites Touch to add or remove device administrators. Check to use GPS satellites to locate location accurately. Use Secure Credentials AGPS Touch to configure AGPS settings. Check to allow applications to access secure certificate and other credentials.
Screen Lock Sounds Development Check to enable sound when locking and unlocking the screen. Touch to set options for application development. Clear Storage Screen Lock Sounds Touch to clear credential storage of all contents and resets the password. Check to enable sound when locking and unlocking the screen. Applications Accounts & Sync Unknown Sources Check to allow installation of nonMarket applications. Manage Applications Touch to manage and remove installed applications.
Privacy Back Up My Data Check to back up my settings and other application data. Automatic Restore Check to automatically restore settings and data when an application is reinstalled. Factory Data Reset Touch to erase all data on your device. SD Card & Phone Storage Displays the SD card and phone storage capacity. Unmount SD card: Touch to safely remove the SD card from your device. Format SD card Touch to format the SD card. Search Touch to configure web and phone search settings.
Searchable items User Dictionary Touch to select searchable items on your device. Touch to add words to the dictionary. Touch Menu > Add. Language & Keyboard Voice Input & Output Select Language Voice Recognizer Settings Touch to select the on-screen display language. • Penpower Input Method See “Penpower Input Method Settings” on page 21. XT9 Text Input See “XT9 Keyboard Settings” on page 20. Android Keyboard See “Android Keyboard Settings” on page 18.
Accessibility Set Time Zone Accessibility Touch to set the time zone manually. This option is available only when Automatic is disabled. Check to enable accessibility services. Power Button Ends Call Check to end a call by pressing the power button instead of using the screen. Date & Time Automatic Check to automatically set the date and time based on network values. Set Time Touch to set the time manually. This option is available only when Automatic is disabled.
Safety & Regulatory charged. This may cause an electric shock or serious damage to the phone. Safety Information On General Use • Avoid using the phone near electromagnetic sources such as TVs, radios, and microwave ovens. • Unplug the power adapter from the wall outlet during lightning storms to avoid electric shock or fire. • Do not expose the phone or the battery to direct sunlight. • Do not use harsh chemicals or detergent to clean your phone. • Do not rub or tap the screen with hard objects.
compatible, contact customer support. • Do not use deformed or damaged batteries. • Do not remove the battery while the phone is charging. • Keep the battery away from children. • Avoid dropping the phone or battery. • If the battery emits a foul odor, discontinue use. • Do not short circuit a battery or allow metal conductive objects to contact with the battery terminals. • • Do not disassemble, crush, puncture, or shred the battery.
such as gas stations and fuel depots. Sparks from these areas could cause explosion or fire and result in injury or even death. • Do not use your phone while driving. Use hands-free devices as an alternative. Onboard Aircraft • Do not use your phone onboard an aircraft at all times. FCC Notice This mobile phone complies with part 15 of the FCC Rules.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The highest SAR value for the model phone as reported to the FCC when tested for use at the ear is 1.3 W/kg and when worn on the body, as described in this user guide, is 0.729 W/kg (Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements.) While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement.
Android, Android Market, Google Maps, Gmail, Google Talk are trademarks of Google, Inc. The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance. The Wi-Fi Alliance Member Logo is a logo of the Wi-Fi Alliance. All other trademarks are the property of their respective owners.
