Optionally assembling your own Rox
You can optionally assemble your own Rox System cabinet seal. If you are not assembling your Rox System
cabinet seal, you can skip this section.
With this option, Airvana provides the Rox System cabinet seal and related components, but you must
provide the antenna cables and cable connectors.
CAUTION
!
If you assemble the Rox System cabinet seals, you are responsible for any damage
resulting from improper assembly. Ensure that only qualified personnel perform
the assembly.
Airvana Rox kits
This Airvana Rox Kit consists of the following:
• RoxTec Frame Kit, ES-CF-16, quantity: 1
• RoxTec Module Kit, ES-CM-20 w40, quantity: 8
• Mounting Plate with gaskets, quantity: 1
For more additional information about the Rox Kit, you can contact RoxTec. The Rox Kit is identified by
part number 6000-004652-100
Assembly requirements
When assembling Rox System cabinet seals, you must adhere to the following requirements. These
requirements are for installation in the top rear antenna access panel opening.
Requirements:
• Internal connectors: N-type, male, straight, hex
• External connectors: site specific, defined by customer
• Length of internal cables: 21 inches, measured from inside edge of Rox System to the end of connector
• Overall cable length: site specific, defined by customer (21 inches internal length + 1.5 inches Rox
thickness + user defined external length)
• Cable size: maximum overall diameter (OD) of 14.5mm (0.571 inches) including sheath; minimum OD
of 4 mm (0.157 inches) of cable screen
• Cable type: defined by customer (suggested type: Andrew Corporation Part #FSJ4-50B, 1/2 inch 50
ohm Superflex or Times Microwave LMR400DB with EZ connectors)
