Table 18 The standard Rox System cabinet seal assembly
Type Sector Use label
Connector
(both ends)
RF
alpha Receive antenna cable α RX1 male N-type
Transmit and receive antenna cable α TX/RX0 male N-type
beta Receive antenna cable β RX1 male N-type
Transmit and receive antenna cable β TX/RX0 male N-type
gamma Receive antenna cable χ RX1 male N-type
Transmit and receive antenna cable χ TX/RX0 male N-type
GPS
not applicable primary GPS antenna cable GPS_P male N-type
secondary GPS antenna cable GPS_R male N-type
