4. Set aside the 10 antenna access panel screws and washers.
The screws and washers will be required for installing the Rox System cabinet seal.
The antenna access panel cover that you just removed will not be required for this installation. Save it
for later use as appropriate.
5. Locate the surge protection access panel.
6. Remove 15 of the 16 screws holding the surge protection access panel in place. Leave the top middle
screw in place.
7. Hold the surge protection access panel firmly in place and remove the final screw using the tamper
resistant screw driver.
WARNING
The surge protection access panel is heavy. Take all necessary precautions to avoid injury and
to avoid damaging the access panel. Do not allow it to be bent. Do not allow the seal around the
inside edge to be damaged.
8. Set aside all 16 screws and washers from the surge protection access panel.
These screws will be used to re-install the access panel after all antennas are connected.
This procedure is complete. Go to Installing the Rox System cabinet seal
on page 107.
Surge protection access panel
Cabinet back view
Take care. The access panel is
heavy and requires support
