Comfort Digisystem User manual Comfort Digisystem Programmer DT05 North America / English
User manual Table of contents Page 1) Introduction Comfort Digisystem 3 2) Regulatory information 3 3) Functions Programmer DT05 - professional tool 4 4) Included accessories 4 5) Programmer DT05 5 6) Menu Programmer DT05 5 7) Instructions HA scanner in Programmer DT05 6 8) Battery maintenance 8 9) Technical data 8 10) Radio range and channels 8 11) Trouble shooting 9 12) Service and warranty 9 13 Important safety instructions 10 Programmer DT05 2
1) Introduction to the Comfort Digisystem Thank you for choosing Comfort Digisystem. Our products are easy to use and give you crystal clear sound. Before using the product, please read this manual carefully. The Comfort Digisystem products feature SecureStream Technology – a unique, patented digital technology allowing eavesdrop-secure radio transfer in real time. Comfort Digisystem Programmer DT05 The optional professional tool Programmer DT05 can be used to configure the Receiver DT10.
3) Functions Programmer DT05 - optional professional tool Function indicator Volume button Socket for neckloop Volume button + On / Off Pairing button Menu control Charging socket Socket for headphones / earphones 4) Included accessories • • Volume indicator Headphones Charger A11 Europlug socket Programmer DT05 4
) Programmer DT05 The Programmer DT05 is an optional professional tool that can be used both for configuring and test-listening of the DT10. 6) Menu in the Programmer DT05 The Programmer DT05 can also be used to configure all settings at the same time in a DT10. To do this, adjust all parameters in the DT05 and then select Send all on the DT05 menu. The Receiver DT10 must be set to pairing mode. R enable R R+M enable R+M Tone ind.
Pairing When Pairing is selected, the DT10 can be set to pairing mode by pressing the push-button for two seconds. If Pairing isn’t selected, pairing mode cannot be enabled with the push-button. To override this, (if the Receiver DT10 needs to be reconfigured or if new pairing information needs to be received), press and hold the pushbutton on the Receiver DT10 for 2 seconds within 10 seconds of it having been connected to a hearing instrument or a Programmer DT05.
) Instruction HA scanner in Programmer DT05 The HA scanner is used for detecting how much interference there is from a hearing aid, within the frequency band that the Receiver DT10 is operating in. How to use the scanner: 1. Enter Setting in the menu of the Programmer DT05 to activate the scanner. 2. Make sure that the hearing aid is on and that the Receiver DT10 is NOT attached. 3.
) Battery maintenance Programmer DT05 10) Radio range and channels The rechargeable products in the Digisystem series are equipped with Li-Pol batteries, ie. the same type of batteries used for most mobile phones and laptop computers on the market today. These types of batteries are able to store large amount of energy in relation to their weight and volume. The transmitter and receiver have built-in antennas.
11) Trouble shooting 12) Service and warranty The receiver does not start 1. Check that the correct listening program is selected on the hearing instrument. 2. Make sure the Receiver DT10 is correctly connected to the hearing instrument’s audio shoe. Also check the connection between the audio shoe and the hearing instrument. 3. Make sure all connecting surfaces are clean. 4. Check/replace the hearing instrument’s battery. 5. Remember to press the push-button briefly to switch the DT10 on.
13) Important safety instructions Read these before using your product 1) 2) 3) 4) 5) 6) 7) 8) 9) 10) 11) 12) 13) 14) 15) 16) 17) 18) 19) Read these instructions. Keep these instructions. Heed all warnings. FolIow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not use near any heat sources such as radiators heat registers stoves, or other apparatus (including amplifiers) that produce heat. Do not defeat the safety purpose of the polarized or grounding plug.
Comfort Audio AB Comfort Audio AB, Box154, SE-301 05 Halmstad, Sweden Tel. +46 (0)35 260 16 00 Fax +46 (0)35 260 16 50 Local US office: Comfort Audio Inc, 350 South Northwest Hwy, Ste 300 Park Ridge, IL 60068 USA T (847) 656 5450 usa@comfortaudio.com www.comfortaudio.us MA0397 Ver 1.
