Pump Exploded View – Comet DWD

42

Ref#

P/N

DESCRIPTION

QTY

1

CO32180554

PUMP MANIFOLD

1

2

CO32020018

CAP

3

5

CO36090338

SCREW

4

6

CO36090271

SCREW

4

7

CO32020018

CAP

1

8

CO32020467

CAP

1

9

CO32020018

SCREW

1

10

CO12100815

O-RING

1

11

CO24090308

CHECK VALVE

1

12

CO18020197

SPRING

1

13

CO34100318

EJECTOR

1

14

CO12100040

O-RING

1

15

CO12100049

O-RING

1

17

CO18020180

SPRING

1

18

CO30030024

BALL

1

19

CO28030424

HOSE FITTING

1

20

CO12150667

REGULATING VALVE KIT

1

21

CO18170111

VALVE KNOB

1

22

CO30090246

SUCTION/DISCHARGE VALVE

SEAT

3

23

CO12100465

O-RING

3

24

CO36040063

SUCTION/DISCHARGE VALVE

3

25

CO18020257

SUCTION/DISCHARGE VALVE

SPRING

3

26

CO12050094

SUCTION/DISCHARGE VALVE

CAGE

3

27

CO30090245

SUCTION/DISCHARGE VALVE

SEAT (DISCHARGE SIDE)

3

28

CO12100415

O-RING

3

29

CO36040063

SUCTION/DISCHARGE VALVE

3

30

CO18020257

SUCTION/DISCHARGE VALVE

SPRING

3

31

CO12050092

SUCTION/DISCHARGE VALVE

CAGE (DISCHARGE SIDE)

3

32

CO12100824

O-RING

3

33

CO00090950

RING

3

34

CO12410231

SEALING RING

3

35

CO12410240

SEALING RING

3

36

CO00090944

PACKING RETAINER

3

37

CO12100333

O-RING

3

38

CO00190185

SEALING RING

3

Ref#

P/N

DESCRIPTION

QTY

39

CO04030553

PUMP CRANKCASE

1

40

CO04380149

BEARING

1

41

CO30190012

OUTER SEEGER

1

42

CO00090327

AXIAL RING

1

43

CO12100357

O-RING

1

44

CO04020553

SIDE COVER

1

45

CO30200046

INNER SEEGER

1

46

CO24090314

PISTON

3

47

CO30110044

PIN

3

48

CO02050105

CONNECTION ROD

3

49

CO24040218

COVER PLATE

1

50

CO12100825

O-RING

1

51

CO04020552

CRANKCASE COVER

1

52

CO36250062

SCREW

4

53

CO12100044

O-RING

1

54

CO32000004

CAP

1

55

CO12100056

O-RING

1

56

CO32020434

CAP

1

57

CO04020537

CAP

1

58

CO28000537

SUCTION FITTING KIT

1

59

CO10020158

WATER FILTER

1

64

CO36090032

SCREW

4

65

CO00011014

ECCENTRIC SHAFT

1

66

CO04380015

BEARING

1

67

CO30200012

INNER SEEGER

1

68

CO00190075

SEALING RING

1

69

CO30160012

MOTOR/PUMP SUPPORT

1

REPAIR KIT

100

CO50250098

COMPLETE VALVE KIT

INCLUDES: 22, 23, 24, 25,

26, 27, 28, 29, 30 ,31, 32, 33

1

101

CO50190766

WATER SEAL KIT

INCLUDES: 34, 35, 37

1

102

CO50190768

23, 28, 32, 33, 37, 38, 43, 50,

53, 68

1
