User manual

Introduction
Thank you for selecting an MGE Office Protection Systems product to protect your electrical equipment.
The product you selected is a part of the EX RT series. The EX RT series is a family of Uninterruptible Power Supply
(UPS) designed to provide safe, and reliable AC power back-up for sensitive electrical equipment. To discover the
entire range of MGE Office Protection Systems products, we invite you to visit our website at www
.mgeops.com.
1.0 Scope
Introduction is a general description of system configurations of the EX 5/7/11 RT, and its mechanical electrical
characteristics. Additionally there is an optional accessories section with important information on MGE Office
Protection Systems products that will enhance the performance of the EX 5/7/11 RT. Please contact your MGE
Office Protection Systems representative for detailed information on these options.
Table 1-1: EX RT Model Descriptions and Contents.
Also: All units include rail kits for rack mounting and
stabilizing feet for tower configuration.
NOTE The Power Module is factory configured for single Mains input at 208VAC,
60Hz. Other input-output voltage settings are available. See Section 3.2.1.
Input voltage must be the same as output voltage on HV units!
System Description System Contents Output Voltage
Model # Part #
Power Module Battery Module
Transformer
Module
86215 86216 86217 86207 86209 86211 86311
5 kVA
HV EX 5RT
86050 X X
200/208/220/
230/240/250
5 kVA
LV EX 5RT
86201 X X X 120/208/240
7 kVA
HV EX 7RT
86070 X X
200/208/220/
230/240/250
7 kVA
LV EX 7RT
86203 X X X 120/208/240
11 kVA
HV EX 11RT
86110 X X
200/208/220/
230/240/250
11 kVA
LV EX 11RT
86205 X X X 120/208/240
1 — 186-86000-00 B01 Introduction
