Specifications

IMl66-097
System Operation
Making Calls
Making Outslde Line Calls
To make an outside call, prime line and idle line
preference must be in effect. if so, make the call as
described below:
l lift handset and listen for outside dial tone,
l Dial number.
To end call,
l hang up handset.
Making Intercom Calls
To make an Intercom call wlth prlme Intercom In
effect,
l Iii handset and listen for intercom dial tone,
. dial extension number. (To call system operator,
dial 0.)
l speak to called party.
To make an intercom call wlth prime llne and Idle
line preference In effect,
l lift handset and listen for outside dial tone,
l FLASH for intercom dial tone,
l dial extension number.
Using The Speed Dial
To dlal statlon speed dlal numbers,
lift handset and listen for intercom dial tone (or
FLASH for intercom dial tone if on outside line),
FLASH for feature access - dial tone will stop,
Press keypad digit 0 - 9 for desired personal speed
dial number.
To dlal system speed dlal numbers,
0 Press *.
l Press keypad dig-its 01 - 30 for desired system
speed dial number.
Using The Last Number Redial
To automatlcally redlal the last number previously
dlaled,
l lift handset and listen for intercom dial tone (or
FLASH for intercom dial tone if on outside line),
l FLASH for the feature - dial tone will stop,
l Dial # to redial the last dialed number.
Using Extended DTMF
(Only Available To Single-Line Proprietary Telephones)
When the prime line and idle line preference are In
effect, the length of the DTMF tone can be extended
from the standard length to a pre-programmed longer
length.
To extend tone length,
lift handset,
wait 10 seconds, and dial number (system will then
generate long DTMF tones when dialing),
OR-
immediately press HOLD then press TAP to set the
system to generate long DTMF tones without
waiting for delay conversion.
To alternate between long length and standard
.
length DTMF tqnes during a call,
l Press HOLD then press TAP for line.
Holding Calls
To place call on hold,
Setting A Manual Hold At A Single-Line
l press HOLD,
Proprietary Telephone
q hang up handset (call goes on hold and recalls after
short programmed delay).
To retrieve held call,
l
Setting A Manual Hold At An
.
Industry-Standard Telephone
press FLASH.
leave handset off hook (call goes on hold, intercom
tone times out, and station appears busy to other
system stations, call does not enter hold recall
moW,
-OR*
l lift handset (if call has recalled),
-OR-
hang handset up. (call goes Into hold recall mode,
and telephone immediately sounds hold recall ring)
l lift handset, press TAP (if call has not recalled).
To retrieve held call If off hook,
l press FLASH.
To retrleve held call If on hook,
e Iii handset
5-13
