Specifications

System Description
IMI 66-097
Section 2
System Specifications
SPECIFICATION
SYSTEM CAPACITY
LINES:
STATIONS:
DSS/BLF CONSOLES:
INTERCOM PATHS,
MAXIMUM SIMULTANEOUS
INTERCOM CONVERSATIONS:
POWER REQUIREMENTS
(Fully loaded system)
AC POWER:
DIMENSIONS (approximate)
COMMON EQUIPMENT:
WIDTH (inches): 15.750
HEIGHT(inches): 24.000
DEPTH (inches):
3.0
WEIGHT (pounds):
20.5
PROPRIETARY STATIONS:
FOOTPRINT (inches):
WEIGHT (pounds):
STATION CABLE REQUIREMENTS
6.5 x 8.5
1.9
TYPE:
MAXIMUM LENGTH:
Twisted, non-shielded, #24AWG
1500 feet for proprietary telephones
2000 feet for 1 (or 2 in parallel) model 2500 industry-standard
telephone
SWITCHING PRINCIPLE:
OPERATING ENVIRONMENT
TEMPERATURE:
HUMIDITY:
TERMINATIONS
LINE:
STATION:
IST PORTS:
2 (station ports 26 and 28)
MODEL NUMBER
NO820
N1024
8
10
20
24
10
62
7
8
7
6
117V +/- 10 % Singlephase _ all models
8A
65W
BOVA
Solid-state, space-division analog switching with stored program
control
32-l 22 degrees F (O-50 degrees C)
90 percent relative, non-condensing
Standard, 6-conductor minijack (USOC RJ14C)
Standard SO-pin female connectors for connection to external
distribution field
