For this reason Comdial recommends that the larger
consoles (DB40 and DB70) not be used unless
absolutely necessary since the XE system has a
maximum station capacity of 24 stations thus leaving
these consoles with a large quantity of blanked
buttons.
l The installed distance limit between the common
equipment and a console is the same as that
specified for a multiline telephone. Connect all four
wires (voice pair and data pair) of the console cable
to the station connector block.
. You can use the voice pair connections of the
console simultaneously to enable a PA port function
or to provide off -hook voice announce capability if
you wish. Refer to the information titled External
Paging Interface - Station PA Port for paging
details. If the particular PA system being used
requires an enable signal, the console and PA
equipment connections are limited to station ports
15 and 17.
l The DSS/BLF console port must be programmed as
a DSS/BLF port before console operation can take
place.
l The console port must be also programmed as a PA
port if a PA amplifier has been connected to the
voice pair as part of the system.
Providing Off-Hook Voice Announce With
Handsfree Answerback
You can use the DB32Sxx Adjunct Feature Module to
provide off-hook voice announcing (OHVA) to a station
already busy on a call and allow subsequent
handsfree answerback (HFAB) by that station user.
The DB32S-xx Module also functions as a DSS/BLF
console at the same time. You must program the
station port that is connected to the Adjunct Feature
Module to activate the feature. When a site requires
both DSS/BLF and OHVA operation, program the
station port as an Off-Hook Call Announce port. When
a site requires only DSS/BLF operation, program the
port as a DSS/BLF Console port.
l Two data-paired station ports are required to
provide the OHVA/HFAB feature.
l Connect a telephone to the first data-paired port
Connect the DB32S-xx Adjunct Feature Module to the
voice pair and the data pair of the second data-paired
pod.
Connecting Telephones To the System - continued on next page . . D
