Mounting Procedure
Unpack, and carefully inspect the common
equipment and telephones for shipping damage.
Notify the shipper immediately of any damages
found. Verify that the packages contain all parts
and accessories needed for proper installation and
operation.
If a backboard is required at the mounting location,
attach it securely to provide a stable mounting
surface for the equipment.
Attach the common equipment with three screws
that you thread into three mounting holes located
as shown on Flgure 3-l. While referring to Flgure
3-l ( measure and mark the location of the mounting
holes on the mounting surface.
Drill holes in the mounting surface of a proper size
to accommodate the hardware being used. If
necessary, prepare these holes with inserts,
anchors or other attachment devices as dictated by
the type of mounting surface.
5. Insert the top screws into the mounting surface,
and tighten them to within approximately i/&inch of
the surface.
6. Hang,the cabinet on the top screws using the
mounting holes located on the rear of the cabinet.
Note that these holes are elongated with an
enlargement at one end. This feature allows the
cabinet to slide down on the screws to secure the
mounting when the cabinet is hung on them.
7. insert a third screw through the mounting tab
located on the lower edge of the cabinet and into
the mounting surface, and tighten it into place
