User guide

29
Internet and Voice Connection
Alternate Connection Using a Sp litter
1.Unplugallofyourdevicesfromtheelectricaloutlet.
2.Locatethecoaxcablecomingfromyourcablewalloutletanddisconnectitfromthebackofyourexisting
device.
3.Connectthecoaxcablefromyourcablewalloutlettothesingle-connectorsideofthetwo-waysplitter.
4.Connectoneendofthe3-ft.coaxcabletooneportonthedouble-connectorsideofthesplitterandconnect
theotherendtothe Cable In/RF Inconnectiononthebackofyourexistingdevice.
5.Connectoneendofthe20-ft.coaxcabletotheotherportonthedouble-connectorsideofthesplitterand
connecttheotherendtotheCable In/RF Inconnectiononthebackofyournewdevice.
6.Makesureallconnectionsaresecure.
7. Plugallofyourdevicesintoanelectricaloutlet.
Cable Wall Outlet
Coax Cable
Cable In/RF In
Existing Device
New Device
Splitter
Coax Cable
Coax Cable
Cable In/RF In
3
4
5
