User guide

28
Internet and Voice Connection
Connect & Power Up
1.ConnectthecoaxcablefromyourcablewalloutlettotheCable In/RF Inconnectiononthebackofyour
modem.Youonlyneedonecoaxcableforthissetup,soselecttheonewhichbestsuitsyourneeds.
2.PlugoneendoftheEthernetcableintotheEthernetconnectiononyourcomputerandplugtheotherend
intotheEthernetconnectiononthebackofyourmodem.
Is your connection different?Informationforalternateconnectionsisavailableinthissectionofyour
UserGuide.
3.PlugthetelephonecablefromyourtelephoneintotheTel 1connectiononthebackofyourmodem.
4.Insertthebattery(untilitlocksintoplace)intoyourmodem.
5.Plugthepowercordintothebackofyourmodem,thenintoanelectricaloutlet.IfyourmodemhasaPower
button,turniton.
6.Beforeproceeding,waitfortheonlineconnectionlightonthefrontofyourmodemtostopashingandremain
solid.ThislightmaybelabeledOnline, Sync, Cable or Ready.Thisprocessmaytakeupto10minutes.
7. Do you have other kits to set up?Ifso,dothatnow.Ifnot,gotopage30toactivateyourservice.
Cable Wall Outlet
Coax Cable
Ethernet
Power
Electrical Outlet
Power Cord
Back of Modem
Computer
Ethernet Cable
Telephone
Telephone Cable
(not included)
Tel 1
1
2
3
5
Cable In/RF In
A cordless phone system will be required to use your XFINITY Voice service on more than one phone throughout your home. Connection of
XFINITY Voice service to your home’s existing phone jacks requires the assistance of a Comcast technician.
