User manual

Code Reader™ 3600 (CR3600)
Included with the CR3600 (Palm and Handle Unit)
Quickstart Guide
CR3621 CR3622
Depending on the kit purchased, a combinaon of the following components will be included with
your reader:
Charging Staon with
or without
an Embedded
CodeXML® Modem
USB
Cable
Power
Supply
CodeXML®
M3 Modem
with RS232 or
USB Cable
Baery
Cartridge
C008567_01_CR3600_QuickStart_Guide
Weighted
Base Plate
Screws and
Rubber Feet
Charging Station Assembly Instructions
1. Plug the barrel side of the USB charge cable or power supply (depending on which you
ordered) into the charger. (Figure 1)
2. (Oponal) To aach the weighted base, place the ‘This Side Down’ (Figure 2) side of the
weighted base onto the surface, place the Charging Staon on top of it (Figure 3) and secure
with the screws provided. (Figure 3)
Figure 1
Figure 2
Figure 3
3. Rubber feet can be placed on the corners of the weighted base (Figure 4) or directly onto the
Charging Staon (Figure 5) to prevent slipping from a surface.
Establishing a Bluetooth® Connection
1. If establishing a Bluetooth connecon using the Charging Staon with embedded CodeXML®
Modem, slide the Communicaon Mode Switch (Figure 10) on the Charger/Modem Staon
to Bluetooth mode (the direcon of the arrow). For USB communicaon mode informaon,
please reference the CR3600 User Manual located at www.codecorp.com.
2. Scan the QuickConnect Code located on the front of the Charger/Modem Staon or on the
external CodeXML® M3 Modem. (Figures 14 and 15).
3. The wireless icon located at the top of the reader will ash as it aempts to make connecon.
(Figure 16) The blue LED on the Charging Staon (or CodeXML® M3 Modem) will also ash as
it aempts to connect and will turn solid when the connecon is established. The CR3600 will
beep once and the wireless icon will ash every 10 seconds. (Figures 14, 15 and 16)
For addional CodeXML® M3 Modem informaon, please reference the CodeXML® M3 Modem
QuickStart Guide.
Figure 16
Blue
LED
Blue
LED
Wireless Icon Storage Icon
Good Read
Indicator
QuickConnect
Code
Figure 14
Figure 15
Important Note If Using a non-Code Bluetooth Device:
To connect to a Bluetooth device not manufactured by Code, you will need the Bluetooth address
(oen referred to as the BD_ADDR) of that device. The 12-character Bluetooth address can be
found on the device near the serial number. Then visit Code’s web site at:
hp://www.codecorp.com/bdaddr.php and enter the 12-character address to create the
QuickConnect Code.
You will need to locate the Communicaons (COM) Port assigned to the Bluetooth serial port
protocol before installing the Bluetooth Conguraon Manager soware that is included with your
Bluetooth adapter (e.g., COM 10). This is the COM Port through which the CR3600 will connect.
© 2013 Code Corporaon. All rights reserved.
