1000/1090+/1100/1105 Barcode Scanner User Guide
The example below shows how to set numeric parameters:
Steps
Action User Feedback if Successful
1 Power on the scanner...
T
he scanner will respond with a long beep
(high tone) and its LED indicator will
become solid red and go off quickly.
2 Enter the Configuration Mode…
Enter Setup
T
he scanner will respond with six beeps
(high-low tone repeats three times), and
its LED indicator will become solid green.
Read a Setup barcode...
For example,
Enable Interleaved 25
Select Max./Min. Length
Qualification
T
he scanner will respond with two beeps
(high-low tone) if reading a normal setup
barcode.
3
Max. Length
1
5
Validate
T
he scanner will respond with one short
beep if reading a special setup barcode
such as “Max. Length”, indicating the
setup requires reading more barcodes.
Read the “Decimal Value” barcode(s).
 Refer to Appendix IV “Decimal
System”
T
he scanner will respond with two beeps
(high-low tone) when the input values are
validated.
4 Exit the Configuration Mode…
Update OR Abort
Same as for Enter the Configuration Mode.
5 The scanner will automatically restart itself… Same as for Power on the scanner.
N
ormal setup
barcode
Special setup
barcode
Decimal barcodes
N
ormal setup
barcode
