Troubleshooting guide

1336 PLUS - 6.16 - September, 2001
3-10 Troubleshooting and Error Codes
Table 3.C
Fault Code Cross Reference
Note: Fault Numbers not listed are reserved for future use.
Fault # Display Name Reset/Run
02 Auxiliary Fault Yes
03 Power Loss Fault Yes
04 Undervolt Fault Yes
05 Overvolt Fault Yes
06 Motor Stall Fault Yes
07 Overload Fault Yes
08 Overtemp Fault Yes
09 Open Pot Fault No
10 Serial Fault No
11 Op Error Fault No
12 Overcurrent Flt Yes
13 Ground Fault No
14 Option Error No
15 Motor Thermistor No
16 Bipolar Dir Flt No
17 C167 Watchdog No
18 Hardware Trap No
19 Precharge Fault No
20 Load Loss Flt No
22 DSP Reset Fault Yes
23 Loop Overrn Flt Yes
24 Motor Mode Flt Yes
26 Power Mode Fault Yes
27 DSP Comm Fault No
28 DSP Timeout Fault No
29 Hertz Err Fault No
30 Hertz Sel Fault No
31 DSP Queue Fault No
32 EEprom Fault No
33 Max Retries Fault No
34 Prm Access Flt No
35 Neg Slope Fault No
36 Diag C Lim Flt No
37 DSP Checksum No
38 Phase U Fault No
39 Phase V Fault No
40 Phase W Fault No
41 UV Short Fault No
42 UW Short Fault No
43 VW Short Fault No
46 DSP Protected No
47 Xsistr Desat Flt No
48 Reprogram Fault No
49 Input Phase Flt No
50 Poles Calc Fault No
51 Bgnd 10ms Over Yes
52 Fgnd 10ms Over Yes
53 EE Init Read No
54 EE Init Value No
55 Temp Sense Open No
Fault # Display Name Reset/Run
56 Precharge Open No
57 Ground Warning No
58 Blwn Fuse Flt No
60 Encoder Loss No
61 Mult Prog Input No
62 Ill Prog Input No
63 Shear Pin Fault No
64 Power Overload No
65 Adptr Freq Err No
66 EEprom Checksum No
67 Sync Loss Fault No
68 ROM or RAM Flt No
