User`s manual

Controller Set Up
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
44 Chapter 5 535 User's Manual
13. ALARM SP:2
Specifies the alarm set point for alarm 2 (except HIGH/LOW)
For HIGH or LOW alarms:
If ALM.SRC.:2 = OUTPUT If ALM.SRC.:2 = any other type
R 0.0% to 100.0% R LOW RANGE to HI RANGE
D 0.0% D 0
For BAND alarms:
R 1 to 99999
D 0
For DEVIATION or RATE alarms:
R -9999 to 99999
D 0
14A. HIGH SP:2
Specifies the high alarm set point for alarm 2 of type HIGH/LOW.
If ALM.SRC.:2 = OUTPUT If ALM.SRC.:2 = any other type
R 0.0% to 100.0% R LOW RANGE to HI RANGE
D 0.0% D 0
14B. LOW SP:2
Specifies the low alarm set point for alarm 2 of type HIGH/LOW.
If ALM.SRC.:2 = OUTPUT If ALM.SRC.:2 = any other type
R 0.0% to 100.0% R LOW RANGE to HI RANGE
D 0.0% D 0
15. DEADBAND:2
Defines the deadband for alarm 2.
If ALM.SRC.:2 = OUTPUT If ALM.SRC.:2 = any other type
R 0.1% to 100.0% R 1 to 99999
D 2 D 2
16. ALM.:2 OUT.
Selects the output number for alarm 2.
D NONE
•2
•3
•4
17. LATCHING:2
Defines the latching sequence of alarm 2.
D LATCH
• NO LATCH
ALARM SP:2
(D)
ALM.:2 OUT.
NONE
DEADBAND:2
2
LATCHING:2
LATCH
HIGH SP:2
0.0%
LOW SP:2
0.0%
