Installation
22 NGT ASR Transceiver Getting Started Guide
To connect the tuner to the RF unit:
1 Connect the plug at the end of the coaxial cable from the
tuner to the socket at the end of the cable lead from the
RF unit, then secure the locking ring tightly into position.
1 Connect the plug at the end of the control cable from the
tuner to the socket at the end of the cable lead from the
RF unit, then secure the locking ring tightly into position.
1 Connect the antenna to the antenna connection on the
tuner, then secure it tightly into position.
Connecting the transceiver supply
To connect the transceiver to the transceiver supply:
1 Connect the DC output from the transceiver supply to the
plug at the end of the 12 V cable lead from the RF unit.
1 Connect the transceiver supply to the AC mains supply.
NOTE
If the connectors at the end of the control cables
from the RF unit and tuner are incompatible,
you may require an NGT adaptor cable (Codan
part number 08-05655-001) to connect the tuner
to the RF unit.
