Installation
NGT ASR Transceiver Getting Started Guide 21
Connecting an NGT ASR fixed station
To connect an NGT ASR fixed station:
1 Connect the socket at the end of the cable to the plug
at the end of the cable lead from the RF unit, then
secure the locking ring tightly into position.
1 Connect the socket at the opposite end of the cable to
the plug at the rear of the desk console, then secure
the locking ring tightly into position.
1 Connect the plug at the end of the cable to the socket at
the end of the cable lead from the RF unit, then secure
the locking ring tightly into position.
1 Connect the plug at the opposite end of the cable to the
socket located at the base of the antenna, then secure the
locking ring tightly into position.
Connecting an automatic tuner to the RF unit and
antenna (optional)
NOTE
The handset is supplied connected to the desk
console.
NOTE
If you are installing a VP-116 Voice Privacy
Unit, you will have been supplied with an
Encryptor Interface junction box. The VP-116
connects to the 15-way Encryptor connector
().
NOTE
You may need to install a tuner to improve the
efficiency of the antenna in your fixed station
(see the reference material on the enclosed CD).
NOTE
The tuner used in most applications has
connectors at the end of the cables attached to
the tuner, as described below. However, you
may have a tuner that has sockets on the
connector panel of the tuner.
