Installation
NGT ASR Transceiver Getting Started Guide 19
Cables
Mounting an NGT ASR fixed station
An NGT ASR fixed station is most commonly mounted using a
desk console (Codan part number 15-10471). For general
guidance on suitable locations for equipment and installing the
fixed station see the reference material on the enclosed CD.
Desk console
The pre-assembled desk console combines a handset, a goose
neck microphone, a junction box, an in-built speaker and a
headphone jack (see Figure 2 on page 18).
NOTE
The junction box is fitted inside the desk
console. The connectors on the junction box are
at the rear of the desk console.
Table 3: Cables for a typical NGT ASR fixed station
Cable Symbol Part number
CIB cable between RF unit and console
a
a. The part number for this cable corresponds to a 6 m CIB cable. The cable is also available in a
number of shorter or longer lengths.
08-05610-006
Coaxial cable between RF unit and antenna
b
b. The part number for this cable corresponds to a 30 m coaxial cable. The cable is also available
in a number of shorter lengths.
08-05103-030
