User's Manual
Table Of Contents
- Table of contents
- List of figures
- List of tables
- Introduction
- 1 NGTtransceiver compliance
- 2 Installation
- 3 The handset
- 4 Getting started
- Switching on the transceiver
- Changing the screen contrast
- Changing the screen brightness
- Using the keys on the handset
- Accessing the Main Menu
- Switching scanning on or off
- Switching mute on or off
- Entering your station self address
- Listen Before Transmit Mode
- Replacing LQA information for all channels in an ALE/CALM network
- Making a manual sounding operation in an ALE/CALM network
- Selecting the best channel in an ALE/CALM network
- Making a Selective call from the Address List
- Making a Phone call from the Address List
- Making an emergency call using the emergency key
- Using a special ALE address syntax to make a call
- Appendix A— Standard hot keys
- Appendix B— Entering and editing text
- Appendix C— Finding words and values
- Appendix D— Creating an entry in a list
- Appendix E— HF radio transmission
- Appendix F— Definitions
- Index
Installation
NGT ASR Transceiver Getting Started Guide 17
Connecting the control cable to an automatic tuning
antenna
To connect the control cable:
1 Connect the socket at the end of the cable into the plug
at the base of the antenna, then secure the locking ring
tightly into position.
1 Fit the plug at the opposite end of the cable into the
socket at the end of the lead from the RF unit.
Connecting the power supply
To connect the transceiver to the battery power supply:
1 Connect the power supply cable (Codan part number
08-03255) to the plug at the end of the 12 V cable lead
from the RF unit.
1 Route the power supply cable according to the
instructions supplied with the Vehicle Installation Kit
(Codan part number 15-00112).
1 Insert the 32 A fuse and holder in the power supply cable
at a convenient location, as close as possible to the
battery terminals.
1 Connect the power supply cable to the battery terminals,
black to negative, red to positive.
Connecting ancillary equipment
The NGT ASR mobile transceiver system uses the junction box
for connecting to ancillary equipment.
