User's Manual
Table Of Contents
- Table of contents
- List of figures
- List of tables
- Introduction
- 1 NGTtransceiver compliance
- 2 Installation
- 3 The handset
- 4 Getting started
- Switching on the transceiver
- Changing the screen contrast
- Changing the screen brightness
- Using the keys on the handset
- Accessing the Main Menu
- Switching scanning on or off
- Switching mute on or off
- Entering your station self address
- Listen Before Transmit Mode
- Replacing LQA information for all channels in an ALE/CALM network
- Making a manual sounding operation in an ALE/CALM network
- Selecting the best channel in an ALE/CALM network
- Making a Selective call from the Address List
- Making a Phone call from the Address List
- Making an emergency call using the emergency key
- Using a special ALE address syntax to make a call
- Appendix A— Standard hot keys
- Appendix B— Entering and editing text
- Appendix C— Finding words and values
- Appendix D— Creating an entry in a list
- Appendix E— HF radio transmission
- Appendix F— Definitions
- Index
Installation
14 NGT ASR Transceiver Getting Started Guide
Cables
Mounting an NGT ASR mobile station
Most components of an NGT ASR mobile station are provided
with their own mounting cradles. For general guidance on
suitable locations for equipment and installing these stations
see the reference material on the enclosed CD.
Mounting the handset cradle
To mount the handset cradle:
1 Mount the handset according to the fitting instructions
(Codan part number 15-00129-001) provided with the
handset cradle.
Table 2: Cables for a typical NGT ASR mobile station
Cable Symbol Part number
a
a. The part number corresponds to a standard 6 m cable. The cables are also available in a number
of shorter and longer lengths.
CIB cable between RF unit and junction box 08-05610-006
Coaxial cable between RF unit and antenna 08-05103-006
Control cable between RF unit and antenna 08-05627-006
DC power supply cable 08-03255
