NGT Transceiver ASR H F R A D IO CO M M U N IC A TI O N S GE T T I N G S T A R T E D GU I D E
No part of this guide may be reproduced, transcribed, translated into any language or transmitted in any form whatsoever without the prior written consent of Codan Limited. © Copyright 2004 Codan Limited. Codan part number 15-04137-EN Issue 1, May 2004 NGT® and CALM® are registered trademarks of Codan Limited. Other brand, product, and company names mentioned in this document are trademarks or registered trademarks of their respective holders.
Table of contents CODAN Introduction 1 NGT transceiver compliance Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 European Radio and Telecommunications Terminal Equipment Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Electromagnetic compatibility and safety notices . . . . . . . . . . . . . . . . . . . . 7 FCC compliance . . . . . . . . . . . . . . . . . . . . . . . . .
Table of contents Making a Phone call from the Address List . . . . . . . . . . . . . . . . . . . . . . . . 51 Making an emergency call using the emergency key . . . . . . . . . . . . . . . . . 53 Using a special ALE address syntax to make a call . . . . . . . . . . . . . . . . . . 55 Appendix A—Standard hot keys Appendix B—Entering and editing text Appendix C—Finding words and values Appendix D—Creating an entry in a list Appendix E—HF radio transmission Appendix F—Definitions Standards and icons . . . .
List of figures CODAN Figure 1: Typical NGT ASR mobile station . . . . . . . . . . . . . . . . . . 13 Figure 2: Typical NGT ASR fixed station . . . . . . . . . . . . . . . . . . . 18 Figure 3: The handset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Figure 4: The channel screen in the Channel List . . . . . . . . . . . . . 28 Figure 5: The channel screen during a call . . . . . . . . . . . . . . . . . . 29 Figure 6: The scanning screen . . . . . . . . . . . . . . . .
List of figures This page has been left blank intentionally.
List of tables CODAN Table 1: Earth symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Table 2: Cables for a typical NGT ASR mobile station . . . . . . . . 14 Table 3: Cables for a typical NGT ASR fixed station. . . . . . . . . . 19 Table 4: Features of the handset . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Table 5: Standard hot keys on the handset . . . . . . . . . . . . . . . . . . 59 Table 6: Examples of channels and modes. . . . . . . . . . . . . . . .
List of tables This page has been left blank intentionally.
Introduction CODAN This guide provides instructions on how to connect up your NGT ASR transceiver, and how to perform basic setup and operating tasks. It assumes that you have limited knowledge of HF communication and of using an HF radio.
Introduction Accessing the CD To access the CD: 1 Place the CD in the CD drive of your computer. The CD should automatically launch the NGT ASR Transceiver Reference Manual as a fully text-searchable HTML help file.
1 NGT transceiver compliance CODAN This section contains the following topics: Introduction (4) European Radio and Telecommunications Terminal Equipment Directive (5) Electromagnetic compatibility and safety notices (7) FCC compliance (10) NGT ASR Transceiver Getting Started Guide 3
NGT transceiver compliance Introduction This section describes how to ensure the NGT transceiver complies with the European Electromagnetic Compatibility Directive 89/336/EEC and the European Low Voltage Directive 73/23/EEC as called up in the European Radio and Telecommunications Terminal Equipment Directive 1999/5/EC. This section also contains the requirements for FCC compliance.
NGT transceiver compliance European Radio and Telecommunications Terminal Equipment Directive The NGT transceiver product range has been tested and complies with the following standards and requirements (articles of the R&TTE Directive): • Article 3.1b: ETSI EN 301 489-1 • Article 3.1b: ETSI EN 301 489-15 • Article 3.2: Australian type approval according to AZ/NZS 4770:2000 and ECR 209 • Article 3.1a: Assessed against ICNIRP and FCC requirements • Article 3.
NGT transceiver compliance Protection of the radio spectrum CAUTION 6 Most countries restrict the use of HF radio communications equipment to certain frequency bands and/or require such equipment to be licensed. It is the user’s responsibility to check the specific requirements with the appropriate communications authorities. If necessary, contact Codan for more information.
NGT transceiver compliance Electromagnetic compatibility and safety notices Radiation safety To ensure optimal transceiver performance and to avoid exposure to excessive electromagnetic fields, the antenna system must be installed according to the instructions provided. WARNING Do not touch the antenna while it is transmitting. You should not transmit from your transceiver if people are within: • 1.
NGT transceiver compliance Electrical safety To ensure compliance with the European Low Voltage Directive is maintained, you must install and use the NGT transceiver in accordance with the instructions in the NGT ASR Transceiver Getting Started Guide and the NGT ASR Transceiver Reference Manual. When using equipment that is connected directly to the AC mains these precautions must be followed and checked before apply AC power to the unit: 1 Use the standard AC mains cable supplied.
NGT transceiver compliance Table 1: Earth symbols Symbol Meaning Chassis earth Protective earth NGT ASR Transceiver Getting Started Guide 9
NGT transceiver compliance FCC compliance FCC Part 90 certification The NGT ASR transceiver has been tested and certified to FCC Part 90 (FCC identifier code DYYNGT-2). FCC Part 15 compliance Any modifications made to the NGT transceiver and 3020 Transceiver Supply that are not approved by the party responsible for compliance may void your equipment’s compliance under Part 15 of the FCC rules.
2 Installation CODAN This section contains the following topics: NGT ASR mobile stations (12) NGT ASR fixed stations (18) NGT ASR Transceiver Getting Started Guide 11
Installation NGT ASR mobile stations An NGT ASR mobile station typically consists of: • a handset and cradle • a junction box • a speaker • an RF unit and vehicle mounting cradle (includes DC power cable) • a 12 V DC power supply (battery) • an automatic tuning antenna Figure 1 on page 13 shows a typical NGT ASR mobile station.
Installation Typical NGT ASR mobile station 9350 ANTENNA Figure 1: NGT ASR Transceiver Getting Started Guide 13
Installation Cables Table 2: Cables for a typical NGT ASR mobile station Cable Symbol Part numbera CIB cable between RF unit and junction box 08-05610-006 Coaxial cable between RF unit and antenna 08-05103-006 Control cable between RF unit and antenna 08-05627-006 DC power supply cable 08-03255 a. The part number corresponds to a standard 6 m cable. The cables are also available in a number of shorter and longer lengths.
Installation Mounting the speaker To mount the speaker: 1 Secure the mounting cradle to the surface with at least two screws. Ensure there is sufficient space at the rear for the cable. 1 Attach the speaker to the cradle with the two screws and rubber washers. Mounting the junction box To mount the junction box: 1 Use cable ties or screws to secure the junction box in a suitable location.
Installation 1 Place the RF unit into the cradle and push it under the tabs at the rear of the cradle, then hold the clamp against the front of the RF unit. 1 Rotate the key clockwise, then push the key toward the base of the cradle to lock the RF unit into position. Connecting an NGT ASR mobile station Connecting an NGT ASR mobile station NOTE If you are installing a VP-116 Voice Privacy Unit, you will have been supplied with an Encryptor Interface junction box.
Installation Connecting the control cable to an automatic tuning antenna To connect the control cable: 1 Connect the socket at the end of the cable into the plug at the base of the antenna, then secure the locking ring tightly into position. 1 Fit the plug at the opposite end of the cable into the socket at the end of the lead from the RF unit.
Installation NGT ASR fixed stations An NGT ASR fixed station typically consists of: • a desk console, containing a handset, a goose neck microphone, a junction box, and a speaker • an RF unit • an AC transceiver supply • a suitable fixed antenna (see the reference material on the enclosed CD) Figure 2 shows a typical NGT ASR fixed station.
Installation NOTE The junction box is fitted inside the desk console. The connectors on the junction box are at the rear of the desk console. Cables Table 3: Cables for a typical NGT ASR fixed station Cable Symbol Part number CIB cable between RF unit and consolea 08-05610-006 Coaxial cable between RF unit and antennab 08-05103-030 a. The part number for this cable corresponds to a 6 m CIB cable. The cable is also available in a number of shorter or longer lengths. b.
Installation RF unit and transceiver supply The RF unit and the transceiver supply are self-contained and are usually stacked loosely. If you want to mount the RF unit and/or the transceiver supply, contact your Codan representative to obtain a rack-mounting unit or the appropriate mounting cradles. Rack-mounting unit A rack-mounting unit consists of a 19 inch rack tray. It can be used in conjunction with a desk console to mount your fixed station.
Installation Connecting an NGT ASR fixed station NOTE The handset is supplied connected to the desk console. NOTE If you are installing a VP-116 Voice Privacy Unit, you will have been supplied with an Encryptor Interface junction box. The VP-116 connects to the 15-way Encryptor connector ( ). To connect an NGT ASR fixed station: 1 Connect the socket at the end of the cable to the plug at the end of the cable lead from the RF unit, then secure the locking ring tightly into position.
Installation To connect the tuner to the RF unit: NOTE If the connectors at the end of the control cables from the RF unit and tuner are incompatible, you may require an NGT adaptor cable (Codan part number 08-05655-001) to connect the tuner to the RF unit. 1 Connect the plug at the end of the coaxial cable from the tuner to the socket at the end of the cable lead from the RF unit, then secure the locking ring tightly into position.
3 The handset Figure 3: CODAN The handset 1 2 26 3 25 4 24 23 MUTE CALL SCAN 5 22 6 21 7 1TUNE QZ 2CLAR ABC 8 4 GHI 5 9 7 V S PRS 8 EASI TALK 0 3MODE DEF 20 19 18 HELP JKL 6 MNO 17 16 SEC TUV 9 WXY 15 14 10 * VIEW # CALL LOGS 13 11 12 NGT ASR Transceiver Getting Started Guide 23
The handset Table 4 explains the features of the handset and the tasks they enable you to perform. Table 4: No.
The handset Table 4: No. Feature Features of the handset (cont.) Name Hot key function Normal function Go to Manual Tune enter 1, Q and Z 7 1TUNE QZ 1QZ key 8 4 GHI 4GHI key 9 7VPRSS 7PRS key Toggles between Selcall mute and Voice mute 10 * TALK Asterisk key Toggles Easitalk on enter the upper-case or off text (A) punctuation marks .
The handset Table 4: No. Feature Features of the handset (cont.
The handset Table 4: No. Feature Features of the handset (cont.
The handset The channel screen The channel screen is displayed when you open the Channel List.
The handset If the transmit and receive frequencies are the same, the frequency is only displayed in the receive frequency position on the right side of the screen and the Rx indicator arrow is not used. The signal strength/output power indicator shows whether the transceiver is receiving or transmitting. While a call is being established, the transceiver will show that calling activity is in progress by flashing the icon in place of the scan indicator.
The handset Selecting a channel To select a channel: 1 1 Go to the Channel List. Scroll through the channels in the list. Stop scrolling when the channel you want is displayed. The channel is selected. If you want to change the mode, press the 3MODE DEF key. If the mode does not change there is only one mode for the channel. NOTE You can also use the Find feature to find a channel (see page 67, Finding words and values).
4 Getting started CODAN This section contains the following topics: Switching on the transceiver (32) Changing the screen contrast (33) Changing the screen brightness (34) Using the keys on the handset (35) Accessing the Main Menu (37) Switching scanning on or off (38) Switching mute on or off (39) Entering your station self address (40) Listen Before Transmit Mode (42) Replacing LQA information for all channels in an ALE/CALM network (44) Making a manual sounding operation in an ALE/CALM network (47) Se
Getting started Switching on the transceiver To switch on the transceiver: 1 Press the key. If you are prompted to enter a password, enter your user or administrator password then press the key. If you enter an incorrect password it is automatically erased. If you enter an incorrect password three times the transceiver automatically switches off. Switching off the transceiver To switch off the transceiver: 1 Hold the key down for two seconds then release. The transceiver is switched off.
Getting started Changing the screen contrast To change the contrast of the screen: 1 Press + 9 WXY to access the Screen Contrast entry in the Control List. The Screen Contrast slider screen is displayed. 1 1 1 Use the or key to increase or decrease the contrast. Press the key to save the value. Press the Menu.
Getting started Changing the screen brightness To change the brightness of the screen: 1 Press +0 to access the Screen Brightness entry in the Control List. VIEW The screen brightness setting is displayed. 1 Scroll through the values until the one you want is displayed on the active line. 1 1 Press the key to save the value. Press the Menu.
Getting started Using the keys on the handset Detailed information on the function of the keys on the handset is provided on page 23, The handset and page 59, Standard hot keys. NOTE There are two ways to use the keys on the handset. You can: • press a key • hold a key Pressing a key means to press a key until the handset makes a short beep sound, then release the key.
Getting started Press the key to: • navigate down from the Main Menu to entries and then to settings by selecting the item on the active line in the list • save changes • answer ‘yes’ to prompts Hold the key to edit settings.
Getting started Accessing the Main Menu The Main Menu is easily accessed from the home screen. The home screen may be any screen that you choose however, by default the home screen is the channel screen. For information on setting the home screen see the reference material on the enclosed CD. To access the home screen from any other screen: 1 Hold the key. To access the Main Menu from the home screen: 1 Press the NGT ASR Transceiver Getting Started Guide key.
Getting started Switching scanning on or off To switch scanning on or off: 1 Press the key. If a call is not in progress, scanning is toggled on or off. If a call is in progress, the call is ended. If the transceiver was scanning before the call was sent or received, it resumes scanning. If the transceiver was not scanning before the call, press the key to switch scanning on. NOTE When scanning is switched on mute is also switched on. You cannot use the PTT button while the transceiver is scanning.
Getting started Switching mute on or off To switch mute on or off: 1 Press the key. A message is displayed briefly to inform you that mute has been switched on or off. When the channel screen is displayed the mute status is indicated by a V or S at the top centre of the screen. If the letter is highlighted, mute is on. If the letter is not highlighted, mute is off.
Getting started Entering your station self address To enter your station self address: 1 1 Go to the Address entry in the Control List. Select the entry. If a self address has not yet been entered the screen displays (none). Press the key to open the List Manager. If one or more self addresses have already been entered the screen displays the number of addresses (e.g. 1 items). Press the key to display the self addresses, then hold the key to open the List Manager. 1 Select Add item.
Getting started Enter up to 15 upper-case letters or numbers, or a combination of both. ALE addresses are sent in groups of 3 characters. You should use addresses with a length that is a multiple of 3, but preferably just 3 characters. 1 1 Press the key. Select the network in which you want to use this self address. To use the self address in all networks, select . The self address is created and the List Manager remains open.
Getting started Listen Before Transmit Mode NOTE If you change the setting in the Cfg LBT Mode entry in the Control List you must switch the transceiver off then on again for the change to take effect. The NGT transceiver is capable of listening to a channel before initiating a call on the channel. If the Cfg LBT Mode in the Control List is enabled, the transceiver will detect whether or not there is traffic on the selected channel, i.e. the channel is occupied.
Getting started When the Cfg LBT Mode is set to Override allowed, and the transceiver detects that the channel(s) tried is(are) busy, it will prompt you to try the call again.
Getting started Replacing LQA information for all channels in an ALE/CALM network CAUTION You cannot make a Channel Test call using the ALL, ANY or Wildcard address syntaxes, or to a NET that is set up to link immediately. If your station operates in a rapidly changing environment, e.g. interactions with mobile stations, you may want to replace the LQA information in the relevant part of the database for the channels in an ALE/CALM network just prior to making a call in the network.
Getting started Replacing LQA information as part of a call in an ALE/CALM network To replace LQA information as part of a call: 1 1 Press the key to stop scanning. Start the call using your preferred method. For example, go to the Address List then select the entry for the station you want to call. 1 When the transceiver prompts you to select a channel/mode, select , then hold the key. 1 1 1 View the LQA screen for the best channel/mode to use. Press the key to continue the call.
Getting started Making a Channel Test call in an ALE/CALM network To make a Channel Test call in an ALE/CALM network: 1 1 Press the 1 Select the ALE/CALM network in which you want to make the call. key. Type the ALE address syntax of the stations for which you want to replace the LQA information and select Channel Test as the call type. NOTE You do not have to select a network if you are sending the call to a NET address as the network is already defined by the NET.
Getting started Making a manual sounding operation in an ALE/CALM network If you need to perform a manual sounding operation using the handset, you make a Channel Test call in an ALE/CALM network using the text SOUNDING as the address. You can do this as part of a new call, or if you use this feature often, set up an entry in the Address List, then use this entry to perform a sounding operation in the selected network (see page 204, Creating an entry in the Address List).
Getting started Selecting the best channel in an ALE/CALM network In order to select the best channel based on LQA information stored in the transceiver, you need to provide the context of the best channel, i.e. the address that you want to call and the network in which you want to make the call. To select the best channel: 1 1 1 Press the 1 1 Select any valid call type for the address entered. 1 At the channel/mode prompt, press the Press the key to switch off scanning. key.
Getting started Making a Selective call from the Address List This section shows you how to make a Selective call from the Address List. It assumes that you have created an entry in the list to do this (for help see page 71, Creating an entry in a list and the reference material on the enclosed CD). To make a Selective call from the Address List: 1 Go to the entry you want to call in the Address List.
Getting started NOTE To abort the call before a connection to the other station is made, press the PTT button. 1 Wait until a message informs you that the call has been successful (this means your call has been automatically answered by the other station). 1 Hold down the PTT button then speak. Release the PTT button when you have finished speaking.
Getting started Making a Phone call from the Address List This section shows you how to make a Phone call from the Address List. It assumes that you have created an entry in the list to do this (for help see page 71, Creating an entry in a list and the reference material on the enclosed CD). To make a Phone call from the Address List: 1 Go to the entry you want to call in the Address List. NOTE 1 1 Press the Scroll to the entry or use the Find feature (for help see page 67, Finding words and values).
Getting started If this prompt is displayed... Do this...
Getting started Making an emergency call using the emergency key For information on setting up the key see the reference material on the enclosed CD. NOTE To make a call using the 1 1 Hold the key: key for at least 2 seconds. If you are prompted for details about the call, use the information in the following table to enter them, then press the key. If this prompt is displayed... Do this...
Getting started 1 To complete the call, use the information in the following table. If you are making an... Do this... Emergency call • wait until a message informs you that the call has been successful • hold down the PTT button then speak, releasing the PTT button when you have finished speaking • press the NOTE key to end the call and resume scanning You should test your transceiver’s emergency call facility on a regular basis.
Getting started Using a special ALE address syntax to make a call CAUTION Depending on the configuration of a NET, a NET call may take several minutes to establish a link. NOTE Detailed information on the special ALE address syntaxes is provided in the reference material on the enclosed CD. To make a call using a special ALE address syntax: 1 1 Press the key. If you are prompted for details about the call, use the information in the following table to enter them, then press the key.
Getting started If this prompt is displayed... Do this...
Getting started 1 If required, hold down the PTT button then speak. Release the PTT button when you have finished speaking. NOTE 1 You are able to send data within the established link by pressing the key and following the prompts. To end the call, press the key. The transceiver resumes scanning.
Getting started This page has been left blank intentionally.
Appendix A—Standard hot keys Table 5: CODAN Standard hot keys on the handset Key Hot key task 0 VIEW Channel Screen: toggles between the Channel List and the Address List. 1TUNE QZ Manual Tune: displays the PTT to tune screen so you can manually tune the antenna. 2CLAR ABC Clarifier: displays the Clarifier setting in the Control List so you can change it, if necessary. 3MODE DEF Next Mode: switches to the next possible mode for the currently selected channel.
Standard hot keys This page has been left blank intentionally.
Appendix B—Entering and editing text CODAN Editing a screen To gain access to an editable screen: 1 Hold the key. A question mark is displayed at the end of the heading to show that you can now enter and/or edit text in the setting. NOTE 1 If text has already been entered on the line it is highlighted. Do one of the following: • To use the text displayed, press the key. • To enter new text, start typing. When you have entered the text, press the key. • To edit the text displayed, press the key.
Entering and editing text Entering text To enter text in an editable screen: 1 To enter one of the letters on a key, press the key repeatedly until the letter is displayed. NOTE 1 You can also hold the key until the letter you want is displayed, then release the key. To enter another letter on the same key, wait until the cursor moves to the next space... ...then press the key repeatedly until the letter you want is displayed. 1 To enter a letter on another key, press the key for the letter.
Entering and editing text Changing between alpha and numerical characters To change between upper-case and lower-case letters and numbers in an editable screen: 1 CALL Press the # LOGS key to change the character/case indicator at the bottom right of the screen from ‘A’ to ‘a’ to ‘#’. When you are prompted to enter a call address, the characters that you can enter are determined by the call systems installed in the transceiver.
Entering and editing text Entering special characters in messages and names To enter special characters: NOTE 1 The special characters that are available are: . , ’ ? ! & # $ * ( ) - + / Use the and keys to move the cursor to the point where you want to insert a special character, then press EASI the * TALK key repeatedly until the symbol you want is displayed.
Entering and editing text 1 When you have selected the character that you want to MODE use, use the 1TUNE QZ or 3 DEF keys to scroll left or right respectively. 1 When you have made the changes, press the exit the special character mode. key to Entering text in an ALE call address NOTE EASI The * TALK key may be used to enter the special ALE addressing characters easily. NOTE You can use any of the characters in the basic 38 ASCII subset (A–Z, 0–9, @ and ?) for the address.
Entering and editing text Saving text changes To save the changes you have made: 1 Press the key. The question mark is removed from the heading. If you do not want to save the text, hold the discard the changes.
Appendix C—Finding words and values CODAN Finding a word To find any word in the Main Menu or in the name of an entry: 1 From the Main Menu select the list in which you want to search. 1 Press the key once. The Find prompt is displayed on the top line. 1 Enter the first character of the word you want to find. The first item that contains a word beginning with this character is displayed. If there aren’t any words that begin with this character the character is deleted and an error beep is made.
Finding words and values Finding a value To find a value that begins with a specific character: 1 From the Main Menu select the list in which the value is stored. NOTE 1 Press the You cannot use this type of search in the Main Menu or in the Control List. key twice. The Find prompt is displayed on the top line with the name of the first setting in the entry. For example: NOTE 1 The search for a value will be conducted in the setting displayed.
Finding words and values 1 Scroll through the entries until the one you want is displayed. 1 Press the NGT ASR Transceiver Getting Started Guide key to exit Find at the entry.
Finding words and values This page has been left blank intentionally.
Appendix D—Creating an entry in a list NOTE CODAN This process does not apply to entries in the Control List. To create an entry in a list: 1 1 1 Select the list in which you want to create an entry. Hold the key to open the List Manager. Select Create entry. The transceiver suggests a name for the new entry based on the name of the entry you were on. 1 Enter the name that you want to use for the new entry. The name must be unique to the list that you are in.
Creating an entry in a list 72 1 If you want to view the entry you have created, close the List Manager by pressing the key. 1 Press the Menu.
Appendix E—HF radio transmission CODAN The HF band is the range of frequencies between 3 and 30 MHz. HF transceivers usually cover a frequency range of 1.6 to 30 MHz. Codan HF transceivers transmit on single sidebands. This reduces the power required to send HF signals and increases the number of channels available within the HF spectrum. HF transceivers are primarily used for long-range communication where distances of 3000 km and more are possible.
HF radio transmission Sky wave The sky wave is the most important form of HF propagation. The radio wave is transmitted toward the sky and is reflected by the ionosphere to a distant receiver on earth. The reflective properties of the ionosphere change throughout the day, from season to season, and yearly.
HF radio transmission Solar activity varies over an 11 year cycle. Higher frequencies need to be used during periods of peak activity. It is important to remember that you may need to change the frequency you are using to achieve the best communication. The general rules of thumb for HF communication are: • the higher the sun, the higher the frequency • the further the distance, the higher the frequency Channels and modes A channel is a name that is given to a frequency or a pair of frequencies, e.g.
HF radio transmission Networks and scanning A network is two or more stations that use the same frequencies and call system to communicate. The frequencies are allocated by a government authority and enable the network to maintain HF communication throughout the day and night. The call system is the method the network uses to make and receive calls. For example, in networks that use the ALE/CALM call system, the transceiver selects the best channel/mode for the call.
HF radio transmission The Advanced ALE options The Advanced ALE options are installed in addition to the CALM option, and are standard for the NGT ASR transceiver. They provide the capability to make ALE calls using ALL, ANY, Group Selective, NET and Wildcard address syntaxes. These calls are from one station to many stations at the same time. The Advanced ALE options also provide advanced link quality analysis and advanced messaging.
HF radio transmission The word ‘over’ is used to signify the end of your transmission. The transceiver may be set up to transmit a short beep when you release the PTT button on the handset. When your conversation with the other party is finished, the party that speaks last should say ‘out’. Swearing or foul language should not be used—heavy penalties can apply. Keep communication as short as possible.
Appendix F—Definitions CODAN Standards and icons The following standards and icons are used in this guide: This typeface Means... Italic a cross-reference or text requiring emphasis This icon Means...
Definitions Acronyms and abbreviations 80 This term Means...
Definitions Glossary This term Means... active line The line below the title of a list on the handset screen. Items in the active line are selected by pressing the key. address The HF transceiver equivalent of a telephone number. Your station self address is used by other stations to call you, and it is sent when you make calls to identify you as the caller. It is sometimes referred to as an ID, a station ID, or a self ID.
Definitions This term Means... ANY call An ALE address syntax used to broadcast to any station that is tuned to the same frequency in an ALE/CALM network or scanning the network. The ANY call uses a special address syntax @@? that ALE stations recognise. The ANY call requests an automatic response from stations detecting the call. These responses are returned in any slot position (collisions may occur).
Definitions This term Means... Channel Test call A call that enables you to test the quality of a channel. It is sometimes referred to as a Beacon call. Channel Test calls may be made in an ALE/CALM network to replace information in the LQA database, and to perform a manual sounding operation. control cable A cable connecting two items of equipment that allows control information to be passed between the equipment.
Definitions This term Means... Group Selective An ALE call that is sent to stations call specifically addressed in the call that are tuned to the same frequency in an ALE/CALM network or scanning the network. The Group Selective call requests an automatic response from stations that detect the call. These responses are returned in reverse order from that provided in the call.
Definitions This term Means... link A link is established following a 3-way handshake process. Scanning is off and a timeout, set using the Cfg In Call Timeout entry in the Control List, will be active. With ALL calls and NET calls that are set to link immediately, the linking establishment process is 1-way.
Definitions 86 This term Means... mobile station A station that is usually mounted in a vehicle or is portable and easily transportable. It consists of a transceiver, a power supply, an antenna, control and accessory devices, ancillary equipment, and appropriate connecting cables. mode A type of reception or transmission you can use with a channel e.g. USB. NET call An ALE address syntax that is used to send a call from one station to other stations that have the NET programmed in the NET List.
Definitions This term Means... revertive A signal sent by a station in response to a call. RF unit The unit in a transceiver that modulates audio signals onto radio frequencies that can be transmitted on air, and that demodulates the radio frequencies it receives into audio signals. Selective call A call that enables you to contact a specific station then speak to an operator. Send Position call A call that sends your GPS position to a specific station.
Definitions Units Measurement Unit Abbreviation Distance metre m Frequency hertz Hz Time second s Voltage volt V Unit multipliers NOTE 88 Units are expressed in accordance with ISO 1000:1992 ‘SI units and recommendations for the use of their multiples and of certain other units’. Unit Name Multiplier M mega 1000000 k kilo 1000 m milli 0.
Definitions About this issue This is the first issue of the NGT ASR Transceiver Getting Started Guide. Associated documents This guide is one of a series of documents associated with the NGT transceiver.
Definitions This page has been left blank intentionally.
Index A Address List calling from 49, 51 Advanced ALE options 77 B best channel selecting 48 brightness screen 34 C cables fixed station 19 mobile station 14 call sign 77 call systems ALE/CALM 76 call types Emergency 43, 53 calls from Address List 49, 51 using emergency key 43, 53 using special ALE address syntaxes 55 CALM option 76 channel screen 28 channels automatic selection 76 definition 75 manual selection 30 compliance electromagnetic compatibility and safety notices 7 earth symbols 8 electrical sa
Index 19 inch rack-mounting unit 20 desk console 19 mounting cradles 20 frequency selection depending on distance and time of day 74 N G O ground wave 73 Option Advanced ALE 77 H handset keys 23, 35 HF radio transmission 73 hot keys standard 59 I installation 11 fixed 18 mobile 12 L LBT Mode 42 list creating an entry 71 LQA information replacing using Channel Test call 44 M Main Menu accessing 37 manual sounding 47 MIL-STD-188-141B 77 mobile station 12 cables 14 installing 16 mounting 14 handset c
Index W wave direct 73 ground 73 sky 74 NGT ASR Transceiver Getting Started Guide Index-3
