Installation
26 NGT Transceiver Getting Started Guide
Cables
NOTE
The Code 766 Desk Console comes with a 2 m
cable that connects directly to the 10-way
connector from the RF unit. The console
replaces the 6 m handset and speaker connector
cable, and external speaker. The handset
connects directly to the back of the console.
Table 3: Cables for a typical fixed NGT station
Cable Symbol Part number
CIB cable between RF unit and console
a
(NGT
AR and SR Transceivers only)
a. The part number for this cable corresponds to a 6 m CIB cable. The cable is also available in a
number of shorter or longer lengths.
08-05610-006
Handset and speaker connector cable (NGT AR Voice
and VR Transceivers only)
08-06022-001
Coaxial cable between RF unit and antenna
b
b. The part number for this cable corresponds to a 30 m coaxial cable. The cable is also available
in a number of shorter lengths.
08-01503-030
