The front panel
2110 SSB Transceiver Getting Started Guide 25
Hold to go from any location to the home screen. If you
have entered text into a setting and want to discard the
changes you made, hold .
The scroll keys
The and keys are the scroll keys. Use these keys to scroll
up or down through any list, to scroll left or right over text,
and to increase or decrease a value.
Interface connectors
The interface connector area comprises:
• the 6-way handset connector ( )
• the 19-way GPIO connector ( )
Antennas
The antenna area comprises:
• the antenna stud ( ) for whip antennas and the long wire
antenna adaptor
•the 50Ω connector ( ) for broadband and dipole
antennas
