The front panel
24 2110 SSB Transceiver Getting Started Guide
User controls
The user control area comprises:
•an LCD
• navigation keys (
, , , , )
• volume controls (
, )
• soft function keys (F1, F2, F3) corresponding to the
function displayed above the key on the front panel
screen
• alphanumeric keys (0–9,
*
, #)
• emergency key ( )
• power key ( )
There are two ways to use the keys on the front panel. You
can:
•press a key, briefly
• hold a key for 2 seconds
The and keys
Press to:
• select the item on the active line in the list
• save changes
• answer ‘yes’ to prompts
Hold to edit settings.
Press to:
• navigate up from settings to entries
• backspace over text
• remove messages on the screen
• cancel changes
• answer ‘no’ to prompts
