SSB Transceiver 2110 H F R A D IO CO M M U N IC A TI O N S GE T T I N G S T A R T E D GU I D E
No part of this guide may be reproduced, transcribed, translated into any language or transmitted in any form whatsoever without the prior written consent of Codan Limited. © Copyright 2004 Codan Limited. Codan part number 15-04136-EN Issue 1, November 2004 CALM® is a registered trademark of Codan Limited. Other brand, product, and company names mentioned in this document are trademarks or registered trademarks of their respective holders. The English version takes precedence over any translated versions.
Table of contents CODAN Introduction Overview of this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Accessing the CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1 2110 SSB Transceiver compliance Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 European Radio and Telecommunications Terminal Equipment Directive . . . . . . . . . . . . . . . . . . . . . . . . . .
Table of contents 5 Getting started Switching on the transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Switching off the transceiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Setting up basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Making a basic voice call . . . . . . . . . . . . .
Table of contents Appendix F—Definitions Standards and icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Acronyms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Unit multipliers . . . . . . . .
Table of contents This page has been left blank intentionally.
List of figures CODAN Figure 1: Typical front panel of a battery charger . . . . . . . . . . . . . 16 Figure 2: Transceiver with battery pack connected . . . . . . . . . . . . 19 Figure 3: The front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Figure 4: The channel screen in the Channel List . . . . . . . . . . . . . 28 Figure 5: Battery status indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Figure 6: The handset. . . . . . . . . . . . . . . . . . .
List of figures This page has been left blank intentionally.
List of tables CODAN Table 1: Earth symbol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Table 2: Battery storage times . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Table 3: Selection guide for antennas. . . . . . . . . . . . . . . . . . . . . . 21 Table 4: Standard hot keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Table 5: General troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . 44 Table 6: Specifications . . . . . . .
List of tables This page has been left blank intentionally.
Introduction CODAN Thank you for purchasing a Codan 2110 SSB Transceiver. With this great product and Codan’s supreme after-sales support, you can look forward to many years of clear and reliable HF communication. Please read this guide thoroughly and retain it for future reference. The 2110 SSB Transceiver is a self-contained, lightweight, waterproof and rugged communication system. Overview of this guide This guide provides instructions on how to get started with your 2110 SSB Transceiver.
Introduction Appendix B Using Quick Start—explains how to use the Quick Start feature, if enabled Appendix C Using the GPS receiver—explains the information provided by the GPS receiver, if fitted Appendix D Transceiver specifications—provides the common operational specifications of the transceiver Appendix E HF radio transmission—describes the medium of HF communication and how to use it effectively Appendix F Definitions—explains the terms and abbreviations used in this guide Appendix G Warranties—expla
1 2110 SSB Transceiver compliance CODAN This section contains the following topics: Introduction (4) European Radio and Telecommunications Terminal Equipment Directive (5) Electromagnetic compatibility and safety notices (7) C-tick approval (9) Care and safety information (10) 2110 SSB Transceiver Getting Started Guide 3
2110 SSB Transceiver compliance Introduction This section describes how to ensure the 2110 SSB Transceiver complies with the European Electromagnetic Compatibility Directive 89/336/EEC and the European Low Voltage Directive 73/23/EEC as called up in the European Radio and Telecommunications Terminal Equipment Directive 1999/5/EC. The CE Declaration of Conformity and Expert Letter of Opinion for the product is listed on page 73, Associated documents.
2110 SSB Transceiver compliance European Radio and Telecommunications Terminal Equipment Directive The 2110 SSB Transceiver has been tested and complies with the following standards and requirements (articles of the R&TTE Directive): • Article 3.1b: ETSI EN 301 489-1 • Article 3.1b: ETSI EN 301 489-15 • Article 3.2: Australian type approval according to AZ/NZS 4770:2003 • Article 3.1a: assessed against ICNIRP requirements • Article 3.
2110 SSB Transceiver compliance Protection of the radio spectrum CAUTION 6 Most countries restrict the use of HF radio communications equipment to certain frequency bands and/or require such equipment to be licensed. It is the user’s responsibility to check the specific requirements with the appropriate communications authorities. If necessary, contact Codan for more information.
2110 SSB Transceiver compliance Electromagnetic compatibility and safety notices Radiation safety To ensure optimal transceiver performance and to avoid exposure to excessive electromagnetic fields, the antenna system must be installed according to the instructions provided. High voltages exist on the antenna during transmission and tuning. Do not touch the WARNING antenna during these activities. RF burns may result.
2110 SSB Transceiver compliance Electrical safety To ensure compliance with the European Low Voltage Directive is maintained, you must deploy and use the 2110 SSB Transceiver and antennas in accordance with the instructions in the 2110 SSB Transceiver Getting Started Guide, the Quick Reference Cards supplied with each antenna, and the 2110 SSB Transceiver Reference Manual.
2110 SSB Transceiver compliance Earth symbol An antenna earth connection point is provided on the 2110 SSB Transceiver. The symbol shown in Table 1 is used to identify the earth on the equipment. Table 1: Earth symbol Symbol Meaning Antenna earth C-tick approval The 2110 SSB Transceiver meets the requirements of the Australian Communications Authority Radiocommunications (MF and HF Radiotelephone equipment—Land Mobile Services) Standard 2003 (AS/NZS 4770).
2110 SSB Transceiver compliance Care and safety information Storage of batteries Codan recommends that batteries are fully charged prior to storage. The length of time that they can be stored before recharging is necessary is dependent on the type of battery and the average storage temperature. Table 2: Battery storage times Type Storage time @ 20°C (70°F) Storage time @ 30°C (85°F) NiMh 12 months 6 months SLA 15 months 10 months Disposal of batteries Batteries must be recycled.
10 SSB Transceiver compliance Deploying antennas WARNING Do not deploy the antenna at sites with overhead power cables. WARNING Do not deploy or use any antenna if there is lightning in the area.
2110 SSB Transceiver compliance This page has been left blank intentionally.
2 Your 2110 SSB Transceiver CODAN The 2110 SSB Transceiver system has a range of accessories that are used in different situations. The following photographs may help you to identify the transceiver and its typical accessories.
Your 2110 SSB Transceiver This page has been left blank intentionally.
3 Preparing the 2110 SSB Transceiver for use CODAN This section contains the following topics: Charging a battery (16) Connecting a battery to the transceiver (19) Inserting the transceiver into a backpack (20) Selecting an appropriate antenna (21) 2110 SSB Transceiver Getting Started Guide 15
Preparing the 2110 SSB Transceiver for use Charging a battery Before using your transceiver, you must ensure that the supplied battery is fully charged. You may use an AC–DC or DC–DC charger with the battery. The AC–DC charger (Type 3121) uses a universal AC mains input of 90–264 V AC. The DC–DC battery charger (Type 3122) may be powered from any 12–60 V DC source, for example, from a vehicle 12 V DC outlet, or from a 24 V vehicle battery.
Preparing the 2110 SSB Transceiver for use CAUTION Provide clear notification that charging is underway. Ensure there is adequate ventilation around the battery during charging. To charge a battery: 1 Do one of the following: • If the battery is attached to the transceiver, use cable 08-06215-001 to connect the output of the charger to the 19-way connector on the front panel of the transceiver.
Preparing the 2110 SSB Transceiver for use Notes on charging batteries A battery will require 3–5 discharge/recharge cycles when new before it reaches its full capacity. In order to increase the battery service life, it is recommended that the battery is not fully discharged during each cycle.
Preparing the 2110 SSB Transceiver for use Connecting a battery to the transceiver The battery is connected to the bottom of the transceiver. It is held in place by clips with locking key latches (see Figure 2). The battery connector on the base of the transceiver is on the same side of the transceiver as the antenna connectors on the front panel.
Preparing the 2110 SSB Transceiver for use Inserting the transceiver into a backpack All backpacks come with adjustable straps that hold the transceiver firmly in position. Some backpacks have an internal mounting frame. To insert the transceiver into a backpack with an internal mounting frame: 1 Open the rear of the backpack to expose the mounting frame. 1 Push the transceiver between the foam mounts on the frame. 1 1 Secure the transceiver with the two adjustable straps.
Preparing the 2110 SSB Transceiver for use Selecting an appropriate antenna Use the following table as a guide to selecting an antenna that is appropriate for your communication requirements.
Preparing the 2110 SSB Transceiver for use This page has been left blank intentionally.
4 The front panel CODAN Overview The front panel has three main areas: user controls, connectors and antennas, as shown in Figure 3.
The front panel User controls The user control area comprises: • an LCD • , , , volume controls ( , ) • navigation keys ( , ) • soft function keys (F1, F2, F3) corresponding to the function displayed above the key on the front panel screen • alphanumeric keys (0–9, • emergency key ( • power key ( ) *, #) ) There are two ways to use the keys on the front panel.
The front panel Hold to go from any location to the home screen. If you have entered text into a setting and want to discard the changes you made, hold . The scroll keys The and keys are the scroll keys. Use these keys to scroll up or down through any list, to scroll left or right over text, and to increase or decrease a value.
The front panel Hot keys Hot keys enable you to perform a task quickly. The transceiver comes with some standard hot keys programmed; the keys are labelled with the corresponding task performed. You can also create your own hot keys (see the reference material on the enclosed CD). Table 4: Standard hot keys Hot key Function F1 Pressing F1 performs the macro assigned to this soft function key. By default, MUTE is assigned to this key, so pressing F1 toggles mute on or off.
The front panel Table 4: Standard hot keys (cont.) Hot key Function V/S Pressing V/S toggles the mute type between Voice mute and Selcall mute. SEC Pressing or holding SEC enters Secure mode, if the hardware option is fitted, and special firmware is programmed into the transceiver and enabled. GPS Pressing GPS displays your current GPS position, if the hardware option is fitted and enabled. EASITALK Pressing EASITALK toggles the DSP noise reduction algorithm on or off.
The front panel The channel screen The channel screen is displayed when you press Figure 4: or VIEW.
The front panel Battery status indicator The channel screen displays a battery status indicator. The indicator graphically shows the: • state of charge • state of health Figure 5: Battery status indicator State of charge State of health 32h 100% 100% 16h 50% 100% 16h 100% 50% 8h 50% 50% State of charge The state of charge indicates graphically how much charge is remaining in the battery.
The front panel NOTE 30 When charging a new battery it may show a low state of health until it has been fully charged and discharged several times.
The front panel The handset The 2110 SSB Transceiver supports standard audio accessories using H-229 type connectors. The handset is a standard issue, lightweight, tactical H-250/U type, with builtin earphone, noise-cancelling microphone, and PTT button. It is connected to the 6-way connector on the front panel of the transceiver.
The front panel This page has been left blank intentionally.
5 Getting started CODAN This section contains the following topics: Switching on the transceiver (34) Setting up basics (35) Selecting a channel (36) Making a basic voice call (37) Making a Selective call (38) Scanning channels (41) You should not transmit from your transceiver or tune the antenna unless people are beyond the safe working distance of: WARNING • 0.2 m (8 in) from a long wire, end-fed broadband, broadband dipole, or wire dipole antenna • 0.
Getting started Switching on the transceiver Prior to operational use, you should connect an antenna to the transceiver (see page 21, Selecting an appropriate antenna, and the Quick Reference Card supplied with the antenna). NOTE To switch on the transceiver: 1 Press . If you are prompted to enter a password, enter your user or administrator password, then press . If you enter an incorrect password it is automatically erased.
Getting started Setting up basics NOTE Basic information for the transceiver, such as channels, self addresses, time and date, and enabling channels for scanning, should be set up by your system administrator using the NGT System Programmer. If Quick Start is enabled you can enter some of this information (see page 49, Using Quick Start).
Getting started Selecting a channel To select a channel: 1 Press VIEW until the channel screen is displayed. If scanning is on, press SCAN to switch it off. 1 Scroll through the channels in the list. Stop scrolling when the channel you want is displayed. The channel is selected. 1 If you want to change the sideband or IF filter settings, press MODE. If the mode does not change there is only one mode for the channel.
Getting started Making a basic voice call To make a basic voice call: 1 Select the channel that you want to use (see page 36, Selecting a channel). 1 Hold down PTT then speak, releasing PTT when you have finished speaking. Muting the transceiver If you do not want to listen to on-air noise, you can mute the transceiver so that you will only hear voice traffic on the channel. To switch mute on or off: 1 Press MUTE.
Getting started Making a Selective call NOTE The call types available will depend on the options installed in your transceiver. To make a Selective call: 1 1 Call type Channel Test Press CALL. Enter the address of the station you want to call, scroll to the type of call you want to make, then press CALL. Icon Used for... Testing the audible quality of a channel in a Codan Selcall network. Replacing LQA information for an ALE/CALM network (if you have the MILSTD-188-141B ALE option installed).
Getting started Call type Icon Used for... Selective Sending a selective call to a remote transceiver. Send Position Sending your GPS position to a remote transceiver. A GPS receiver must be fitted and enabled in your transceiver. 1 If you are prompted for details about the call, use the information in the following table to enter them, then press CALL. If this prompt is displayed... Do this...
Getting started 1 If you made the call in: • an ALE/CALM network, wait until a message informs you that the call has been successful (this means your call has been automatically answered by the other station) • a Codan Selcall network, wait until a message informs you that the call has been sent and listen for audible beeps transmitted from the other station 1 Hold down PTT then speak. Release PTT when you have finished speaking.
Getting started Scanning channels Before you can switch scanning on, you need to allocate some channels to be scanned. If you have Quick Start enabled you can create a scan list from channels programmed into the transceiver (see page 49, Using Quick Start). If this feature is disabled, your system administrator will allocate some channels to a network, then enable scanning of this network. Switching scanning on or off To switch scanning on or off: 1 Press SCAN. Scanning is toggled on or off.
Getting started The channel/modes through which you can scroll are those in the networks that were being scanned. They are not listed alphabetically but in the order in which they were being scanned. If you do not press a key within 30 seconds the transceiver automatically resumes scanning.
6 Troubleshooting CODAN Below is a checklist for basic troubleshooting.
Troubleshooting Table 5: Problem General troubleshooting Solution The sound from Drain any moisture from the front panel of the transceiver by the front panel turning it upside down. speaker is muffled Communications Try another channel. are not clear Press PTT. If you are using a whip or long wire antenna, check that the antenna selection icon is ATU or ATU/50 (see Figure 4 on page 28).
Appendix A—Entering and editing text CODAN Editing a screen To gain access to an editable screen: 1 Hold . A question mark is displayed at the end of the heading to show that you can now enter and/or edit text in the setting. NOTE 1 If text has already been entered on the line it is highlighted. Do one of the following: • To use the text displayed, press . • To enter new text, start typing. When you have entered the text, press . • To edit the text displayed, press .
Entering and editing text Entering text To enter text in an editable screen: 1 To enter one of the letters on a key, press the key repeatedly until the letter is displayed. NOTE 1 You can also hold the key until the letter you want is displayed, then release the key. To enter another letter on the same key, wait until the cursor moves to the next space... ...then press the key repeatedly until the letter you want is displayed. 1 To enter a letter on another key, press the key for the letter.
Entering and editing text Changing between alpha and numerical characters To change between upper-case and lower-case letters and numbers in an editable screen: 1 Press # to change the character/case indicator at the bottom right of the screen from A to a to #. NOTE When you are prompted to enter a call address, the characters that you can enter are determined by the call systems installed in the transceiver.
Entering and editing text NOTE If you want to insert a space, make sure that A or a is displayed at the bottom right of the screen before you press 0 otherwise you will enter a zero. NOTE You can enter a special character using , or with and . * Deleting text To delete text: 1 Use and to move the cursor one position to the right of the character that you want to delete, then press . Saving text changes To save the changes you have made: 1 Press . The question mark is removed from the heading.
Appendix B—Using Quick Start CODAN Quick Start provides simple methods to configure your transceiver to a basic operating state. Quick Start will be available if your transceiver contains only one station self address and network names from this default list: • *Voice • *Selcall • *CALM • !Default When you hold , you should see the Quick Start entries, for example, Add/Edit channel, Set scan list etc. If these entries are not displayed, then Quick Start is not available to you.
Using Quick Start Adding/Editing a channel To add or edit a channel: 1 1 1 Open Quick Start. Scroll to Add/Edit channel, then press . Enter the name of the channel that you want to use, then press . NOTE For help with entering text see page 45, Entering and editing text. If you want to use an existing channel, scroll to the channel, then press . 1 Enter the receive frequency in kilohertz, then press NOTE 1 1 . You can enter the frequency to three decimal places.
Using Quick Start Setting up a scan list To set up a scan list: 1 1 Open Quick Start. Scroll to Set scan list, then press . The first channel in the transceiver is displayed. 1 If you want to add this channel to the scan list, press . If you do not want to add this channel to the scan list, press . When all the channels have been viewed or you have added 20 channels to your scan list, the transceiver will return to Quick Start.
Using Quick Start When all the changes have been made, the transceiver will return to Quick Start. 1 Close Quick Start, if required. Setting your station self address NOTE When Quick Start is available, any self address that you enter using this method will replace the previous self address. If you want to enter more than one self address, and hence disable the Quick Start features, see the reference material on the enclosed CD. To set your station self address: 1 1 1 Open Quick Start.
Using Quick Start Adding/Editing an entry in the Address List or Call Book To add or edit an address that you call frequently: 1 1 1 Open Quick Start. Scroll to Address/CallBk, then press . Enter the name of the station or person that you want to add to the list, or use and to select an existing entry, then press . NOTE For help with entering text see page 45, Entering and editing text. 1 Scroll to the type of call that you want to make, enter the station address that you want to call, then press .
Using Quick Start Deleting an entry To delete addresses, channels or phone links: 1 1 1 Open Quick Start. 1 Scroll to the item you want to delete, then press Scroll to Delete..., then press Scroll to the list from which you want to delete an item, then press . NOTE 1 54 . . If you delete a channel from the Channel List, it is deleted automatically from the scan list. Close Quick Start, if required.
Appendix C—Using the GPS receiver CODAN The GPS antenna is located behind the front panel of the transceiver (see Figure 3 on page 23). In order to obtain reliable and accurate GPS information, you should ensure that the front panel of the transceiver is pointed toward the sky and is not shadowed by overhead obstructions. To access GPS information: 1 Press GPS to see the GPS screen.
Using the GPS receiver This page has been left blank intentionally.
Appendix D—Transceiver specifications Table 6: CODAN Specifications Item Specification Frequency range Transmit: 1.6 to 30 MHz Receive: 250 kHz to 30 MHz Channel capacity 400 channels Operating modes Single sideband (J3E) USB and LSB or switched USB/LSB, AM H3E (optional) Sensitivity Frequency: 0.25 to 30 MHz RF amp off: 0.28 µV PD, –118 dBm Frequency: 1.6 to 30 MHz RF amp on: 0.14 µV PD, –124 dBm For 10 dB SINAD with greater than 50 mW audio output Power output 25 W PEP ±0.
Transceiver specifications Table 6: Specifications Item Specification Size 2110 including battery: 245 mm W × 350 mm D × 92 mm H (9.8 in W × 14.0 in D × 3.7 in H) Weight Sealing 58 2110 only: 245 mm W × 250 mm D × 92 mm H (9.8 in W × 10.0 in D × 3.7 in H) 2110 only: 2.5 kg (5.5 lb) 13 Ah NiMh battery 2.9 kg (6.4 lb) 8 Ah NiMh battery 2.1 kg (4.6 lb) 7 Ah SLA battery 3.2 kg (7.
Appendix E—HF radio transmission CODAN The HF band is the range of frequencies between 3 and 30 MHz. HF transceivers usually cover a frequency range of 1.6 to 30 MHz. Codan HF transceivers transmit on single sidebands. This reduces the power required to send HF signals and increases the number of channels available within the HF spectrum. HF transceivers are primarily used for long-range communication where distances of 3000 km (1800 mi) and more are possible.
HF radio transmission Sky wave The sky wave is the most important form of HF propagation. The radio wave is transmitted toward the sky and is reflected by the ionosphere to a distant receiver on earth. The reflective properties of the ionosphere change throughout the day, from season to season, and yearly.
HF radio transmission Solar activity varies over an 11 year cycle. Higher frequencies need to be used during periods of peak activity. It is important to remember that you may need to change the frequency you are using to achieve the best communication.
HF radio transmission Networks and scanning A network is two or more stations that use the same frequencies and call system to communicate. The frequencies are allocated by a government authority and enable the network to maintain HF communication throughout the day and night. The call system is the method the network uses to make and receive calls.
HF radio transmission In this example your call sign is AB2 and you are calling a station with the call sign AB1. A call sign is a group of letters and numbers issued by a government authority to identify a station. The phonetic alphabet is used to ensure that your call sign is understood. The word ‘over’ is used to signify the end of your transmission. The transceiver may be set up to transmit a short beep when you release the PTT button on the handset.
HF radio transmission This page has been left blank intentionally.
Appendix F—Definitions CODAN Standards and icons The following standards and icons are used in this guide: This typeface Means... Italic a cross-reference or text requiring emphasis This icon Means...
Definitions Acronyms and abbreviations 66 This term Means...
Definitions This term Means...
Definitions Glossary This term Means... active line The line below the title of a list on the front panel screen. Items in the active line are selected by pressing . address The HF transceiver equivalent of a telephone number. Your station self address is used by other stations to call you, and it is sent when you make calls to identify you as the caller. It is sometimes referred to as an ID, a station ID, or a self ID.
Definitions This term Means... Get Position call A call that gets the GPS position of a specific station. Get Status call A call that gets diagnostic or configuration information about the transceiver at a specific station. front panel The interface that is used to control the functions of the 2110 SSB Transceiver. It consists of a display, keypad and connectors for the handset, antenna, ancillary equipment, and earthing.
Definitions This term Means... macro A short set of instructions to automate a task you perform with the transceiver. When a macro is assigned to a key, the key becomes a hot key. manual sounding A Channel Test call made in an ALE/CALM network using the text SOUNDING as the call address. The station performs a sounding operation, which other stations use to update the information in their LQA database. Manual sounding is available if the MILSTD-188-141B ALE option is installed.
Definitions This term Means... transceiver unit The device that modulates audio signals onto radio frequencies that can be transmitted on air, and that demodulates the radio frequencies it receives into audio signals. Selective call A call that enables you to contact a specific station then speak to an operator. Send Position call A call that sends your GPS position to a specific station. sideband A band of frequencies that is above or below a modulated carrier frequency.
Definitions Units NOTE Imperial dimensions are in United States Customary Units. Measurement Unit Abbreviation Length metre (inch/feet/yard/ mile) m (in/ft/yd/mi) Frequency hertz Hz Time second s hour h Voltage volt V Weight gram (pound) g (lb) Unit multipliers NOTE 72 Units are expressed in accordance with ISO 1000:1992 ‘SI units and recommendations for the use of their multiples and of certain other units’. Unit Name Multiplier M mega 1000000 k kilo 1000 m milli 0.
Definitions About this issue This is the first issue of the 2110 SSB Transceiver Getting Started Guide. Associated documents This guide is one of a series of documents associated with the 2110 SSB Transceiver.
Definitions This page has been left blank intentionally.
Appendix G—Warranties CODAN Codan’s warranty statement is provided on the International Product Warranty Card (Codan part number 12-50144). This statement sets out standard use and misuse under the terms of the warranty.
Warranties This page has been left blank intentionally.
Index CODAN A E Address List adding/editing entries 53 calling from 38 alternative charger requirements 17 electromagnetic compatibility and safety notices compliance earth symbol 9 electrical safety 8 electromagnetic compatibility 7 protection of the radio spectrum 6 entering and editing text changing between alpha and numerical characters 47 deleting text 48 editing a screen 45 entering special characters 48 entering text 46 inserting text 47 moving the cursor 47 saving text changes 48 European Radio
Index P password entering 34 phonetic alphabet 63 power on/off 34 Q Quick Start 49 adding/editing a channel 50 adding/editing an entry in the Address List or Call Book 53 deleting an entry 54 opening and closing 49 setting the time and date 51 setting up a scan list 51 setting your station self address 52 S safety radiation 7 scan rate, see call detect time 68 scanning channels 41, 62 pausing channel scanning 41 selecting an item in a list 24 channel 36 sky wave 60 storage battery 10 W wave direct 59 gr
