UHF Amplifier Instruction Manual UT-3 406 - 512 MHz 5-3
R30 R ES., SM, 49k9 1206, 1%, 100ppm 1150-4B4992FP
R31 RES., SM, 10k0 1206, 1%, 100ppm 1150-4B1002FP
Ref
Desig Description Part No.
R32 RES., SM, 49R9 1206, 1%, 100ppm 1150-1B49R9FP
R33 RES., SM, 4k53 1206, 1%, 100ppm 1150-3B4531FP (0.5 - 2.0 Watts)
R33 RES., SM, 49k9 1206, 1%, 100ppm 1150-4B4992FP (2.0 - 8.0 Watts)
R34 RES., SM, 49k9 1206, 1%, 100ppm 1150-4B4992FP (0.5 - 2.0 Watts)
R34 RES., SM, 39k2 1206, 1%, 100ppm 1150-4B3922FP (2.0 - 8.0 Watts)
R35 RES., SM, 10k0 1206, 1%, 100ppm 1150-4B1002FP
R36 POT., SM, 50k 12 TURN, SIDE ADJUST 1172-M30503X5
R37 RES., SM, 1k00 1206, 1%, 100ppm 1150-3B1001FP
R38 POT., SM, 50k 12 TURN, SIDE ADJUST 1172-M30503X5
R39 RES., SM, 1k00 1206, 1%, 100ppm 1150-3B1001FP
R40 RES., SM, NOT INSTALLED NOT INSTALLED
R41 RES., SM, 10k0 1206, 1%, 100ppm 1150-4B1002FP
R42 RES., SM, 1k00 1206, 1%, 100ppm 1150-3B1001FP
R43 RES., SM, 27k4 1206, 1%, 100ppm 1150-4B2742FP
R44 RES., SM, 10k0 1206, 1%, 100ppm 1150-4B1002FP
TL1* COAX, DIRECTIONAL COUPLER 0.5" 7496-30CR005T
TL2 COAX, CONFORMABLE 50 OHM, 0.083", 60 mm 7482-5024T083
TL3, TL4 COAX, DIRECTIONAL COUPLER 0.5" 7496-30CR005T
TL5 COAX, CONFORMABLE 50 OHM, 0.083", 29 mm 7482-5024T083
U1-U3 I.C., MC33172 DUAL OP AMP, S0-8 2302-33172N08
U4 AMP, RF, MHW707-1 7W, 403-440 MHz 2257-MHW70701 (406-430 MHz)
U4 AMP, RF, MHW707-2 7W, 440-470 MHz 2257-MHW70702 (450-470 MHz)
U4 AMP, RF, MHW707-3 7W, 470-500 MHz 2257-MHW70703 (470-490 MHz)
U4 AMP, RF, MHW707-4 7W, 490-512 MHz 2257-MHW70704 (490-512 MHz)
PCB UT-3/400 AMPLIFIER 4323-15931613
LPF UT-3/400 LOWPASS FILTER ASSEMBLY A23-LPF-3
