UHF Amplifier Instruction Manual UT-3 406 - 512 MHz
5-1
5 PARTS LISTS
5.1
UT-3 / UT4
UHF Amplifier Electrical Parts List
NOTE:
Reference
Designators
labeled
with an asterisk (*) are used only in 2.0 - 8.0 Watts amplifiers.
Ref
Desig Description Part No.
C1-C6
CAP.,
SM,
18nF
CER,
1206, X7R 1008-4B183K5R
C7,
C8
CAP.,
SM,
4.7µF
TANT., 10%, 16V
1055-5B475K16
C9
CAP.,
SM,
1nF
CER,
1206, C0G
1008-3B102K1G
C10
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C11,
C12
CAP.,
SM,
100nF
CER,
1206, X7R 1008-5B104K5R
C13
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C14*
CAP.,
SM,
150pF
CER,
1206, C0G
1008-2B151J1G
C15*
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C16*
CAP.,
SM,
15pF
PORCEL.,
±5%,
500V 1036-1B2150J5
C17*
CAP.
TRIM,
0.6-3.5pF
VERT.,
>9T 1082-C0R6003G
C18*
CAP.,
SM,
NOT INSTALLED NOT INSTALLED
C19*
CAP.,
SM,
47pF
PORCEL.,
±5%,
500V 1036-1B2470J5 (406-430 MHz)
C19*
CAP.,
SM,
39pF
PORCEL.,
±5%,
500V 1036-1B2390J5 (450-470 MHz)
C19*
CAP.,
SM,
30pF
PORCEL.,
±5%,
500V 1036-1B2300J5 (470-490 MHz)
C19*
CAP.,
SM,
30pF
PORCEL.,
±5%,
500V 1036-1B2300J5 (490-512 MHz)
C20*
CAP.,
4.7µF
DIP. TANT., 10%, 35V 1054-5E475K35
C21*
CAP.,
SM,
100nF
CER,
1206, X7R 1008-5B104K5R
C22*
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C23*
CAP.,
SM,
1nF
CER,
1206, C0G
1008-3B102K1G
C24*
CAP.
TRIM,
0.6-3.5pF
VERT.,
>9T 1082-C0R6003G
C25*
CAP.,
SM,
7.5pF
PORCEL.,
±0.25pF
1036-0B2759C5 (406-430 MHz)
C25*
CAP.,
SM,
4.7pF
PORCEL.,
±0.25pF
1036-0B2479C5 (450-470 MHz)
C25*
CAP.,
SM,
3.0pF
PORCEL.,
±0.25pF
1036-0B2309C5 (470-490 MHz)
C25*
CAP.,
SM,
NOT INSTALLED NOT INSTALLED (490-512 MHz)
C26*
CAP.,
SM,
4.7pF
PORCEL.,
±0.25pF
1036-0B2479C5 (406-430 MHz)
C26*
CAP.,
SM,
3.0pF
PORCEL.,
±0.25pF
1036-0B2309C5 (450-470 MHz)
C26*
CAP.,
SM,
3.0pF
PORCEL.,
±0.25pF
1036-0B2309C5 (470-490 MHz)
C26*
CAP.,
SM,
3.0pF
PORCEL.,
±0.25pF
1036-0B2309C5 (490-512 MHz)
C27
CAP.,
SM,
150pF
CER,
1206, C0G
1008-2B151J1G
C28
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C29
CAP.,
SM,
100nF
CER,
1206, X7R 1008-5B104K5R
C30-C32
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C33
CAP.,
SM,
150pF
CER,
1206, C0G
1008-2B151J1G
C34
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C35
CAP.,
SM,
100nF
CER,
1206, X7R 1008-5B104K5R
C36
CAP.,
SM,
10nF
CER,
1206, X7R 1008-4B103K5R
C37
CAP.,
10nF
FILM,
MMK5, 10%,63V 1016-4A103K63
C38
CAP.,
10µF
DIP. TANT., 20%, 25V 1054-6E106M25
D1 DIODE, MBZ5233B 6.0V ZENER, SOT-23
2102-MBZ5233B
D2 DIODE, IN5402 3A
RECT,
DO-201AD 2001-1N540200
D3, D4 DIODE, BYD17J R
ECTIFIER,
SOD-87
2101-BYD17J00
D5* DIODE, MMBD701 HOT
CARRIER,
SOT-23 2105-MMBD7010
D6, D7 DIODE, MMBD701 HOT
CARRIER,
SOT-23 2105-MMBD7010
