UHF Amplifier Instruction Manual UT-3 406 - 512 MHz
3 Turn on the power to the transmitter.
4 For high power
amplifier
units, follow steps 5 to 7 below. For low power amplifiers,
skip to the
Output
Power
Alarm
procedure.
5 Tune the output
matching
capacitor
for
maximum
output
power.
This should be
approximately
8 Watts.
6 For single frequency applications, tune the input
matching
capacitor
so that
+9.5
Vdc
current is
minimized
without
sacrificing
output
power.
For wideband
applications
it
is best to tune the
amplifier
at the highest frequency in the band of
interest
and then
tune the input
matching
capacitor
so that the
+9.5
Vdc current never exceeds 1.2
amps over the desired frequency band.
7 For single frequency applications, re-peak the output
matching
capacitor. For
wideband
applications
it is best to tune the
amplifier
at the highest frequency in the
band of
interest
and then re-peak the output
matching
capacitor
so that the
+13.8
Vdc
current never exceeds 1.5 amps over the desired frequency band.
3.6.2.2
Output Power Alarm (Forward Power)
Open
Collector
Output
*
note:
the output power
alarm
output is factory configured as an open
collector
output
so a pull-up resistor may be required on
transmitter
pin B26 if one is not
already
present.
1
Adjust
R7, the output power adjustment, to the output power at which the
Output
Power
Alarm
is to be
activated.
2
Monitor
transmitter
pin B26, the
Output
Power
Alarm
line, and slowly turn R21, the
output power
alarm
adjustment, clockwise
until
pin B26 goes low. The
alarm
is now
set for the current output power of the transmitter.
Linear
Output
1 Open the
amplifier
case to disable (open c
ircuit)
jumper JU2 and
enable
(short)
jumper
JU1.
2
Monitor
transmitter
pin B26 with a voltmeter.
3
Adjust
R7, the output power adjustment, for full
transmitter
output
power.
