IR850 | Wireless Internet Radio

Quick Start Guide

Requirements

To connect and use your Internet Radio, you will need the following:

Broadband Internet connection •

A connection speed of 64 Kbps or greater is recommended.

Wireless Router or Access Point•

Your wireless router should support Wi-Fi 802.11b/g connections.

If you have a router that supports 802.11n, make sure that it has

been congured to accept 802.11b/g connections as well.

Wireless Router Network Settings•

You will need to know the name of your network (SSID) as well as

the WEP or WPA password if your network is secured. These set-

ings can usually be found on the administration webpage of your

wireless router. Please refer to your wireless router’s documenta-

tion for help.

Basic Controls

Remote Key Function

Navigate through menus (Left,

Right, Up, Down)

Enter a menu selection.

Access the Main menu

Change the station information

displayed on screen.

Change the function mode

(Internet Radio, Music Player,

FM radio)

Turn the unit on or off

Turn the volume level up.

Remote Key Function

Turn the volume level down.

For a full description of all available controls,

please refer to the instruction manual.

Before using the remote control, pull out

the protective strip of plastic from the bat-

tery compartment to remove it.

Summary of content (4 pages)

PAGE 1
Quick Start Guide IR850 | Wireless Internet Radio Requirements To connect and use your Internet Radio, you will need the following: • Broadband Internet connection A connection speed of 64 Kbps or greater is recommended. • Wireless Router or Access Point Your wireless router should support Wi-Fi 802.11b/g connections. If you have a router that supports 802.11n, make sure that it has been configured to accept 802.11b/g connections as well.
PAGE 2
Connect to Your Wireless Network You will need to configure the IR850 to connect to the internet through your wireless network the first time you use it. After that, the IR850 will automatically connect to the internet using these saved settings unless you reset the unit to its factory-default settings. 1) Connect the Power. Plug one end of the power adapter into the Power jack located on the bottom of the unit, then plug the other end into an AC 100240V wall outlet. Press to turn the radio on.
PAGE 3
Connect to Your Wireless Network (cont) Troubleshooting your network connection • If after trying to connect to your wireless network, the display reads “Failed to connect,” please try the following: Move the radio to a location where the wireless signal is stronger (e.g., closer to your wireless access point). • Make sure that your password has been entered correctly. • Ensure that your wireless router and internet modem are connected and working normally.
PAGE 4
Frontier Silicon Internet Radio Portal For More Help Visit the Frontier Silicon web portal at www.wifiradio-frontier.com to browse global stations and personalize your favorites. You can also add additional stations to your radio through the website. Please refer to the accompanying Instruction Manual for further help with your Coby Internet Radio. You may also visit our website at: You will need to create an account and register your device to use the web portal. 1) Get the unique access code.
