MODELS: MX46SPH COBRA LAWN MOWER OWNER’S MANUAL Cobra Garden Machinery Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK www.cobragarden.co.
CONTENTS SECTION 1 SYMBOLS MARKED ON THE PRODUCT……………………………3 SECTION 2 GENERAL SAFETY RULES…………………………………………….3 SECTION 3 PARTS DESCRIPTION………………………………..…………….…..6 SECTION 4 TECHNICAL DATA…………………………………………………...…..6 SECTION 5 ASSEMBLY…………………………………………………………….….7 SECTION 6 “3 IN 1”……………………………………………………………….…....9 SECTION 7 OPERATION INSTRUCTIONS……………………………………..…..11 SECTION 8 MAINTENANCE INSTRUCTIONS ……………………………..……...14 SECTION 9 LUBRICATION INSTRUCTIONS …………………………………..….
WARNING： For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarise yourself with your mower before each use. 1. SYMBOLS MARKED ON THE PRODUCT Fig. A B.1 Read Operator's Manual. B.2 Keep bystanders away. B.3 Pay attention to the operator's hands and feet to avoid injury. B.4 Fuel is flammable. Do not add fuel with running machine. B.
Training 1. Before using the lawnmower read the instructions carefully. Familiarise yourself with the controls and pay particular attention in learning how to stop the machine in an emergency. 2. Never allow children or people unfamiliar with these instructions to use the lawn mower. Local regulations can restrict the age of the operator. 3. Never mow while people, especially children or pets are nearby. 4.
19. Stop the engine and disconnect the spark plug wire, make sure that all moving parts have come to a complete stop and, where a key is fitted remove the key, make sure engine has had time to cool: - Before unclogging the chute and clearing blockages. - Before checking, cleaning or working on the lawn mower. - After striking a foreign object. Inspect the lawnmower for damage and make repairs before restarting. - If the lawn mower starts to vibrate abnormally (check immediately). 20.
3. PARTS DESCRIPTION Fig.C MX46SPH 1. Upper handle 2. Starter handle 3. Rope Guide 4. Locking Lever 5. Grass catcher 6. Height adjusting lever 7. Deck 8. Sideward flap 9. Spark Plug 10. Oil Cap 11. Fuel cap 12. Cable-clamp 13. Choke Lever 14. Brake control handle 15. Self-drive control handle 16. Mulching wedge 17. Discharge channel Including a spark plug wrench 4.
(According to 2000/14/EC) Vibration 2.168m/s² (According to EN 836 Annex G) k=1.5m/s² 5. ASSEMBLY 5.1 FOLDING HANDLE For the MX46SPH 1. Fix the lower handlebars into the mower body with the locking knobs, bolts and washers as Fig. 1A,/Fig.1B/Fig.1C shown. 2. Lift the two locking levers to release the upper handlebars for folding. (Fig.1D) 3. Push the locking lever closed to lock the handlebars in the operating position. (Fig. 1E) 4. Adjust the tension by turning the lock nut with a suitable spanner.
Fig.2 5.3 MOUNTING AND DISMOUNTING THE GRASS CATCHER 1. To fit: Raise the rear cover and hitch the grass catcher on rear of the mower. 2. To remove: grasp and lift the rear cover, remove grass catcher. Fig.3A Fig.3B Fig.3C 5.4 STARTER HANDLE Move the starter handle from the engine to the rope guide. (Fig.4A, 4B) Fig. 4A MX46SPH 5.5 HEIGHT OF CUT Apply outward pressure to disengage the lever from the rack. Move lever forward or back to adjust the height. (Fig.5A see clause 7.9) Fig.
5.6 Tool Box For the MX46SPH This MX46SPH lawn mower has a tool box. Push the button to open it, and then press the cover to lock it. You can put tools such as spanners and screwdrivers in this box. Fig.6 Starting Operation 6. “3 IN 1” The lawn mower has 3 in 1 features: 1. Rear grass collection. 2. Grass mulching. 3. Side-discharge.
TWO: Resetting for side-discharge mowing 1. Lift the rear cover and remove the grass catcher. 2. Mount the discharge channel. 3. Lift the sideward flap for side discharge (Fig.7D) 4. Mount the discharge guide for side discharge on the support pin of the sideward flap. (Fig.7E/Fig.7F) 5. Lower the sideward flap- the flap lies on the discharge channel. (Fig.7G) WARNING: Only when the engine and the blade are at standstill! Fig. 7D Fig. 7F Fig. 7E Fig.
7. OPERATING INSTRUCTIONS 7.1 BEFORE STARTING Service the engine with petrol and oil as instructed in the separate engine manual packed with your mower. Read all instructions carefully. WARNING! Petrol is highly flammable. Store fuel in containers specifically designed for this purpose. Refuel outdoors only, before starting the engine and do not smoke while refueling or handling fuel. Never remove the cap of the fuel tank or add petrol while the engine is running or when the engine is hot.
Start the engine carefully according to the instructions and with feet well away from the blade. Do not tilt the lawn mower when starting the engine. Start the mower on a level surface, free of high grass or obstacles. Keep hands and feet away from the rotating parts. Do not start the engine when standing in front of the discharge opening. 7.3 OPERATION PROCEDURES During operation, tightly hold the brake handle with both hands.
will also help to clean up any stray clippings left on the lawn. The mower should always be operated at full throttle to get the best cut and allow it to do the most effective job of mowing. Clean underside of deck: Be certain to clean the underside of the cutting deck after each use to avoid a build-up of grass, which could prevent proper mulching. WARNING: If the mower blade strikes a foreign object, stop the engine immediately.
8. MAINTENANCE INSTRUCTIONS SPARK PLUG Use only the original replacement spark plug. For best results, replace the spark plug every 100 hours of use. 9. LUBRICATION INSTRUCTIONS CAUTION: DISCONNECT THE SPARK PLUG BEFORE SERVICING. . 1. WHEELS-Lubricate the ball bearings in each wheel at least once a season with a light oil. 2. ENGINE-Follow engine manual for lubrication instructions 10. CLEANING CAUTION: Do not hose the engine. Water can damage the engine or contaminate the fuel system. 1.
Cobra Part Number 263002488 for the MX46SPH – Available to order from your local dealer. WARNING: Periodically inspect the blade adapter for cracks, especially if you strike a foreign object. Replace when necessary. For best results your blade should be sharp. Slightly worn blades may be re-sharpened with care. After removing the blade, it may be ground or filed, so that the cutting edge is as close to the original bevel as possible.
The following steps should be taken to prepare the lawn mower for storage at the end of the mowing season. 1. Drain the fuel from the engine by running the engine until it stops. a) Start the engine and let it run until it has used up all remaining petrol and stalls. b) Remove the spark plug. Use an oilcan to fill approx. 20 ml oil into the combustion chamber. Operate the starter to evenly distribute the oil in the combustion chamber. Replace the spark plug. 2.
12 TROUBLES SHOOTING PROBLEM Engine does not start. PROBABLE CAUSE Throttle chock not in the correct position for the prevailing conditions. Fuel tank is empty. Air cleaner element is dirty. Spark plug loose. Spark plug wire loose or disconnected from plug. Spark plug gap is incorrect. Spark plug is defective Carburetor is flooded with fuel Engine difficult to start or loses power. Engine operates erratically. Faulty ignition module Dirt, water, or stale fuel tank. Vent hole in fuel tank cap is plugged.
13. WARRANTY This product is warranted in accordance with legal regulations for a 24 month period effective from the date of purchase by the first user. This product will not be covered if used in a commercial application.
15. EC-DECLARATION OF CONFORMITY EC Declaration of Conformity We herewith declare, Cobra Garden Machinery Henton & Chattell Ltd, London Road, Nottingham NG2 3HW UK That the following machine complies with the appropriate basic safety and health requirements of the EC Directive based on its design and type, as brought into circulation by us.
