SAILOR 6390 Navtex Receiver User manual
98-137261.
98-137261.book Page ii Wednesday, October 16, 2013 12:20 PM Disclaimer Any responsibility or liability for loss or damage in connection with the use of this product and the accompanying documentation is disclaimed by Thrane & Thrane A/S. The information in this manual is provided for information purposes only, is subject to change without notice and may contain errors or inaccuracies. Manuals issued by Thrane & Thrane A/S are periodically revised and updated.
98-137261.book Page iii Wednesday, October 16, 2013 12:20 PM Safety summary Observe the following general safety precautions during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of the equipment. Thrane & Thrane A/S assumes no liability for the customer's failure to comply with these requirements.
98-137261.book Page iv Wednesday, October 16, 2013 12:20 PM Preface Approvals and standard compliance SAILOR 6390 Navtex Receiver is approved to MED 2012/32/EU and fulfills the requirements in the following standards: IEC-60945 (2002), IEC-60945 Corrigendum 1 (2008), IEC61097-6 (2005-12), IEC-61162-1 (2010-11) (aligned with NMEA 0183 version 4.00), ITU-T X.27/V.11 (1996) The SAILOR 6390 Navtex Receiver is approved to SOLAS Regulations IV/7, IV/14: ITU-R M.540-2 (06/90) and ITU-R M.625-3 (10/95).
98-137261.book Page v Wednesday, October 16, 2013 12:20 PM Related documents The following table shows the documents related to this manual and to the SAILOR 6390 Navtex Receiver.
98-137261.
8-137261.book Page vii Wednesday, October 16, 2013 12:20 PM Table of contents Chapter 1 Introduction SAILOR 6390 Navtex Receiver .......................................................1 Navtex message (example) ..............................................................3 Use scenarios ..........................................................................................4 Chapter 2 Operation Operation – SAILOR 6004 Control Panel ..................................5 Operation with INS equipment ...
98-137261.
98-137261.book Page 1 Wednesday, October 16, 2013 12:20 PM 11111 Chapter 1 Introduction Introduction 1 SAILOR 6390 Navtex Receiver The SAILOR 6390 Navtex Receiver receives Navtex messages on the international Navtex frequencies 490 kHz, 518 kHz and 4,209.5 kHz. It can hold 2000 messages per frequency. Messages are not affected by a power cycle. If not tagged to avoid deletion, messages are cleared from the message log after 661 hours.
98-137261.
98-137261.book Page 3 Wednesday, October 16, 2013 12:20 PM 11111 Chapter 1: Introduction Introduction Navtex message (example) The following message shows an example of a Navtex message. ZCZC XZ28 REYKJAVIK VIA GRINDAVIK 120350 UTC SEPT 2013 NO MESSAGE ON HAND NNNN Message item Explanation ZCZC Start of message (not displayed) X Coast Station ID in the Navigational Area Z Message type (See The following list shows the Navtex message types available. on page 10 for a list of all message types.
98-137261.book Page 4 Wednesday, October 16, 2013 12:20 PM Chapter 1: Introduction Use scenarios The SAILOR 6390 Navtex Receiver can be used in the following contexts: • Use with the SAILOR 6004 Control panel • Use as a stand-alone unit with an INS An optional printer can be connected in both use scenarios. Use with the SAILOR 6004 Control panel The SAILOR 6004 Control panel is the user interface for the SAILOR 6390 Navtex Receiver. The user interface is in English.
98-137261.book Page 5 Wednesday, October 16, 2013 12:20 PM 22222 Chapter 2 This chapter has the following sections: • Operation – SAILOR 6004 Control Panel • Operation with INS equipment 2 Operation Operation Operation – SAILOR 6004 Control Panel As soon as DC power is provided the SAILOR 6390 Navtex Receiver is on. To switch on the SAILOR 6004 Control Panel push the power button. Operate the SAILOR 6004 Control Panel by tapping the touch screen.
98-137261.book Page 6 Wednesday, October 16, 2013 12:20 PM Chapter 2: Operation Dim and night mode Turn the dim knob of the SAILOR 6004 Control Panel to increase or decrease the display brightness. The display goes into night mode either when turning the dim knob counterclockwise or when the internal light sensor detects the light level for changing to night mode1. To dim to level zero push the power button once.
98-137261.book Page 7 Wednesday, October 16, 2013 12:20 PM 22222 2. Navtex app-specific area Short message listing, each row represents a Navtex message. Tap a message to display the full message. • Open envelope: The message has been read or is older than 24 hours. • Closed envelope: The message has not been read and is newer than 24 hours. Only messages filtered for Display are shown in this list.
98-137261.book Page 8 Wednesday, October 16, 2013 12:20 PM Chapter 2: Operation Sorting the list of Navtex messages To sort the list of Navtex messages tap the heading of the column. Tap it again to toggle the sorting order, ascending or descending. The default sorting is for Time, newest on top. Navtex message in detail To view details of a navtex message tap the message.
98-137261.book Page 9 Wednesday, October 16, 2013 12:20 PM 22222 Chapter 2: Operation SAR messages When a SAR message (message type D, see page 9) is received, the SAILOR 6390 Navtex Receiver emits an audible signal and the message is displayed in the SAILOR 6004 Control Panel’s display. Filtering message types and stations You can customise the SAILOR 6390 Navtex Receiver to receive Navtex messages of certain types and from selected coast stations.
98-137261.book Page 10 Wednesday, October 16, 2013 12:20 PM Chapter 2: Operation 4. Swipe the field Select message types and select the message types you want to receive on this frequency. A, B, D and L are mandatory. 5. Tap Apply. The selected message types are displayed directly below the frequency. The following list shows the Navtex message types available. Note Message types A, B, D and L cannot be filtered out.
98-137261.book Page 11 Wednesday, October 16, 2013 12:20 PM 22222 Chapter 2: Operation Filtering stations The SAILOR 6390 Navtex Receiver can automatically filter messages from coast stations within a certain range of NM of own position (default). You can also filter coast stations manually. To set up filters for stations do as follows: 1. Tap the menu icon and then Filters. 2. Tap Printer, Display or INS to select for which output you want to set up a filter. 3.
98-137261.book Page 12 Wednesday, October 16, 2013 12:20 PM Chapter 2: Operation Printer attached to the SAILOR 6004 Control Panel A printer can be connected to one of the USB connectors of the SAILOR 6004 Control Panel. Every time a Navtex message is received and applies to the filtering set up for Printer, the message is output on the printer.
98-137261.book Page 13 Wednesday, October 16, 2013 12:20 PM 33333 Chapter 3 This chapter has the following sections: • Maintenance • Alarms and notifications • Reinstalling or updating the Navtex app • Troubleshooting guide • Service and repair 3 Maintenance Maintenance of the SAILOR 6390 Navtex Receiver can be reduced to a maintenance check at each visit of the service staff. Inspect the unit for mechanical damages, salt deposits, corrosion and any foreign material.
98-137261.book Page 14 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance System LEDs LED Colour Description Power Green Lit when the device is on. Rx Green Flashing when receiving Navtex data on any active frequency. Test Green Lit when the power-on-self-test is passed. Flashes if a fault is detected.
98-137261.book Page 15 Wednesday, October 16, 2013 12:20 PM 33333 Alarms and notifications Overview If an alarm is reported from the SAILOR 6390 Navtex Receiver a flashing red triangle appears in the bottom bar of the SAILOR 6004 Control Panel display: • Flashing, bright red triangle: Unacknowledged alarm(s). • Faded red triangle: Acknowledged alarm(s). Flashing, bright red Faded red To acknowledge an alarm do as follows: 1.
98-137261.book Page 16 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance Installation with SAILOR 6004 Control Panel Alarm Description Remedy 001 Navigational Warning Read associated message. 002 Meteorological Warning Read associated message. 003 Search and Rescue Information Read associated message. 004 Receiver Malfunction Contact your supplier. 005 Built-in Self Test Failure Check antenna installation. 006 General Failure Power cycle the unit.
98-137261.book Page 17 Wednesday, October 16, 2013 12:20 PM 33333 Installation with an INS Alarms and notifications are signalled via the NMEA sentence ALR. See the user documentation of the equipment connected to the SAILOR 6390 Navtex Receiver for further information on how alarms and notifications are displayed.
98-137261.book Page 18 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance Tap the icon System and the following topics are available: • Settings for Network settings, Date/Time and Debugging. • Applications to install and manage applications. • Self Test for testing Touch, Controls, Display, Audio, USB, Light Sensor, Alarm Output, NMEA and LAN. • About with Legal information, software versions and network information.
98-137261.book Page 19 Wednesday, October 16, 2013 12:20 PM 33333 Chapter 3: Service & maintenance Applications Service & maintenance Tap Applications to install, uninstall or update applications. This section has two tabs: Available, showing the apps that are available to the SAILOR 6004 Control Panel on the current network, and Installed, showing the apps already installed. To install an app, do as follows: 1. Tap Available to display the apps that are available to this SAILOR 6004 Control Panel. 2.
98-137261.book Page 20 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance • Uninstall – tap here to uninstall this app from the SAILOR 6004 Control Panel. 3. Enter the password for user level (user) and tap OK. Self Test Tap Self Test to start the self test of the SAILOR 6004 Control Panel. For further details on the self test see the installation manual of the SAILOR 6004 Control Panel.
98-137261.book Page 21 Wednesday, October 16, 2013 12:20 PM 33333 To access this screen tap the menu icon and then Settings. • Own Device Name: Identification of the SAILOR 6004 Control Panel in the network. It must consist of the letters II followed directly by 4 digits. • Remote Device Name: Identification of the SAILOR 6390 Navtex Receiver in the network. It must consist of the letters CR followed directly by 4 digits.
98-137261.book Page 22 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance Troubleshooting guide Problem Symptom Remedy The SAILOR 6390 Navtex Receiver will not turn on. Green power LED on SAILOR 6390 Navtex Receiver is off. If the power cable is connected directly to the SAILOR 6390 Navtex Receiver then check that ON IN is wired to VBAT-. No message can be received. Test LED flashes. Check the antenna installation. The Time No valid column shows message time.
98-137261.book Page 23 Wednesday, October 16, 2013 12:20 PM 33333 Chapter 3: Service & maintenance Symptom Remedy SAILOR 6004 Control Panel cannot be switched off. Password entered in the SAILOR 6004 Control Panel, but padlock does not open If the SAILOR 6004 Control Panel cannot be switched off normally (e.g. due to a fault): Push and hold for 12 seconds. If a remote switch is installed, see the note on page 5. Authorization failed.
98-137261.book Page 24 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance Service and repair Should your Cobham SATCOM product fail, please contact your dealer or installer, or the nearest Cobham SATCOM partner. You will find the partner details on www.cobham.com/satcom where you also find the Cobham SATCOM Self Service Center web-portal, which may help you solve the problem.
98-137261.book Page 25 Wednesday, October 16, 2013 12:20 PM 33333 Chapter 3: Service & maintenance 2. Remove the cables from the spring-loaded terminals and the connectors. 3. Remove the SAILOR 6390 Navtex Receiver by moving it upwards, away from the mounting surface. Replacing the fuse Service & maintenance One fuse is installed in the SAILOR 6390 Navtex Receiver. If this fuse is blown, do as follows: 1. Track down why the fuse was blown and solve the problem, e.g.
98-137261.book Page 26 Wednesday, October 16, 2013 12:20 PM Chapter 3: Service & maintenance address, part number and full serial number. Mark the carton FRAGILE to ensure careful handling. Note Correct shipment is the customer’s own responsibility. If the original shipping carton is not available, the following general instructions should be used for repacking with commercially available material. 1. Wrap the defective unit in heavy paper or plastic.
98-137261.book Page 27 Wednesday, October 16, 2013 12:20 PM AAAAA Specifications A SAILOR 6390 Navtex Receiver Item Specification Weight 1.3 kg Dimensions L x W x H: 190 x 270 x 42.5 mm Input voltage 12-24 VDC (10.8 VDC to 31.2 VDC) Power consumption Typical 6.
98-137261.book Page 28 Wednesday, October 16, 2013 12:20 PM Appendix A: Specifications Item Specification Interfaces TNC antenna connector Alarm relay output (normally closed) 2 LAN connectors Remote on NMEA0183 in and out for INS support NMEA0183 in for e.g.
98-137261.book Page 29 Wednesday, October 16, 2013 12:20 PM BBBBB Glossary Glossary A AIS Automatic Identification System. Automatic tracking system used on ships and by vessel traffic services (VTS) for identifying and locating vessels by electronically exchanging data with other nearby ships and AIS Base stations. G GMDSS Global Maritime Distress and Safety System.
98-137261.book Page 30 Wednesday, October 16, 2013 12:20 PM Glossary LORAN LOng RAnge Navigation, a terrestrial radio navigation system which enables ships and aircraft to determine their position and speed from low frequency radio signals transmitted by fixed land based radio beacons. N NAVDAT High Speed NAVtex DATa sent out on 500 kHz. Not yet part of mandatory Navtex reception, but mentioned in ITU-R M.2010 and ITU-R M.2201. NMEA National Marine Electronics Association (standard).
