User Instructions

Physical Mass
Dimensions
82g
90mm x 85mm
Power DC Input
Power Consumption
8-16V
Typically 4W when meshed to a sin-
gle node at 100mW Tx power.
[Power consumption is dependent
on data rate, channel BW and num-
ber of nodes]
A/V input
(Separate Card
Option)
Video Input
Video Format
Video Encoding
Quality
Video bit-rate
Resolution
Frame Rate
Audio Input
Audio Sampling Freq.
Audio encoding
Audio bit-rate
Composite or SDI (selectable)
525 or 625 (PAL or NTSC)
MPEG4
Low/Medium/High (selectable)
2.4Mbit/s to 50kb/s (variable)
704, 576, 480 or 352
Self-selecting 30 to 2F/s
Line level or Microphone level
48kHz
MPEG audio layer 1
384 to 64kb/s
Store and For-
ward options
Storage Format
Record Options
Files Download
AV Clip Size
Secure Digital (SD) Card interface—
optional
Continuous or Triggered
From web browser interface
(Milestone)
30 seconds
Environment Temperature Range -10 to +50 °C
January 2016 Data Sheet
www.cobham.com/tcs
