User Instructions

January 2016 Data Sheet
RF Tuning Step Size
Output Power
Bandwidth
Mesh Capacity
Modulation
Carrier Modulation
FEC Rate
Receive Diversity
Receive Sensitivity
125kHz step
+20 to -10dBm, 0.25dB steps (100mW)
2.5, 3.0, 3.5, 5.0, 6.0 MHz
Up to 8.8Mb/s
COFDM 360 carrier modulation
BPSK, QPSK or 16QAM (adaptive)
FEC1/2, FEC2/3 (adaptive)
Maximum Ratio Combining
-98dBm (BW 2.5MHz / BPSK 1/2)
IP Interface Ethernet electrical
IP Address Alloc.
Video & Audio stream-
ing format
100BaseT Ethernet
DHCP dynamic IP Addressing
Multicast VLC compatible UDP & RTSP
Support
Open Audio
comms
channel
Audio Comms channel
Compression
Interface Microphone level/headphone
G726 32kbit audio
Encryption Type AES128 or AES256 (both optional)
GPS Dedicated GPS I/F RS232/RS485
Data
Interface
RS232/RS485 data 1K2 to 115K2 baud switchable, UDP &
TCP routing protocol
Control Local Control
Remote control
Bicolour LED indicates power and mesh
status. Mission Commander PC App.
Web browser control
Specification
www.cobham.com/tcs
Frequency
Selection
D1700
D1702
D1703
D1705
D1707
D1710
D1713
D1715
200 – 300 MHz
300 – 470 MHz
450 – 600 MHz
1140 – 1500 MHz
1980 – 2550 MHz
3000 – 3700 MHz
4400 – 5000 MHz
5500 – 6000 MHz
Interfaces Antenna 1 [Rx]
Antenna 2 [Tx/Rx]
Transmitter Port
External PA input
Power
Ethernet 1
Ethernet 2
Control and Misc
Camera (A/V)
SMP J19
SMP J22
SMP J24
SMP J6
JST J2
JST J14
JST J15
JST J3 (RS485) JST J12 (RS232)
Optional Card—D550
