User's Manual

11 LEDs
This chapter summarize all LEDs notification descript in previous chapters.
11.1 Trigger Status LEDs
11.1.1 AUX LED
Notification event
Event description
Action of notification
Power on notification
Section 4.2
Continuously turned on for 1 sec
Spare on
Section 6.1
Turned on
Spare off
Section 6.1
Turned off
11.1.2 Light Bar LED
Notification event
Event description
Action of notification
Power on notification
Section 4.2
Continuously turned on for 1 sec
Light Bar on
Section 6.1
Turned on
Light Bat off
Section 6.1
Turned off
11.1.3 BWC1 Bluetooth Status LED
Notification event
Event description
Action of notification
Power on notification
Section 4.2
Continuously turned on for 1 sec
BWC1 pairing
Section 8.1.1
Blinking
BWC1 connected
Section 8.2
Turned on
BWC1 disconnected
Section 8.2.2
Turned off
