Board Installation
Use the following steps to install the card in the frame:
1. Refer to the frame product manual to ensure that the frame is properly installed
according to instructions.
Warning
Heat and power distribution requirements within a frame may dictate
specific slot placement of cards. Cards with many heat-producing
components should be arranged to avoid areas of excess heat build-up,
particularly in fra mes usi ng convec tion cooling.
2. After selecting the desired frame installation slot, hold the card by the edges and
carefully align the card edges with the slots in the frame. Then, fully insert the card
into the frame until the rear connection plugs are properly seated on the midp lane and
rear modules.
3. Connect the input and output cables according to the diagram for the rear module
being used. The inputs are internally terminated with 75 Ohms. It is not necessary to
terminate unused out puts.
This completes the procedure for installing the card in the frame.
