Owner's manual

Important: Always read and follow the information box instructions. • 21
Specifications
Wheel Diameter Range
8 - 30 inches
Wheel Width Range
2 - 20 inches
Maximum Outside Tire Diameter
Up to 44 inches
Maximum Tire/Wheel Weight
160 pounds (68 Kg)
Mounting Shaft Diameter
User choice of 28mm or 40mm
Resolution (Round Off Mode)
0.25 ounce, position 1.40 degrees
Resolution (Non-Round Off Mode)
0.01 ounce, position 1.40 degrees
Balancing Display Increments
0.25 or 0.01 ounces
Electrical Requirements
220 V, 1 Ph, 60 Hz, 20 amp
220V, 3Ph, 20 amp
(use grounding type plug)
Footprint
60 inches x 60 inches
Shipping Weight
680 pounds (308 Kg)
Accessory Options
Features
• Automatic Data Entry for Offset and Diameter -
Manual Entry Backup on all Parameters
• Static-on-Screen™
• Four Fixed Function Keys, Seven Program Keys for
user Friendly Operation
• Direct Select™ Weight Placement Location
Dynamic (Standard): Clip-on Weights
Alloy: User Defined
Static
Patch (Tire Weight): Static Only
• Behind the Spoke Weight Placement
• Automatic Start When Hood is Lowered
• Single Spin Balancing - Dynamic and Static
• Easy-To-Read Position Indicators
• Laser Guided Operation™ Tape-A-Weight
®
Placement with Offset Arm
• Hood Safety Interlock System
• Extended Mounting Faceplate for Deeper Wheels
• Removable Center Shaft for Closed Center Wheels
• Match Balance (Optimization)
• Operator Memory for Two Different Users
• User Friendly Weight and Position Calibration
• No Bolt-down Installation
• Solid State Motor Control
• Automatic Positioning and Stopping (3D/3DV)
• MET Lab Listing
Contents Part Number
Basic Kit 8114335 (28mm) 8500997401 (40mm)
Small Cone
Medium Cone
Large Cone
Light Truck Back Cone
Rim Width Calipers
Wheel Weight Pliers
Hubnut
Small Pressure Cup & Rubber Lip
Cone Spring
Extended Kit 8114337 (28mm) 85009976 (40mm)
Basic Kit
Short Cone
Light Cone Kit
Faceplate Extension
Premium Kit 8114338 (28mm) 85009977 (40mm)
Extended Kit
Pin Plate System
Balancer Mate Storage Rack
